Meccanica SCOTTI CNC Table Manuel du propriétaire

CNC STEPPING PROGRAMMING MANUAL

Indexing revolving CNC Table :

-With STEPPING POSITION : Table with STEPPING MOTOR and

POSITION.

MUP TEC 160/600 I

MANUAL N° : MAN.IST.PASSO 01 REV.00

Meccanica SCOTTI S.r.l.

20040 Cornate D'Adda Milano - Italia - Via N. Sauro, 22

Telefoni : 039 / 69.21.56 - 039 / 60.60.140 Fax : 039 / 69.23.27

E-MAIL [email protected]

HOME PAGE www.meccanicascotti.com

MAIN RIGGING FOR INSTALLATION AND USE OF THE TABLE

WITH A OWN UNITY OF STEPPING CONTROL .

MODEL ..................... / I

CONNETTION CABLES AND IGNITION CNC.

1. Connect the connectors ILME C1 and C2 at the electrical case.

- C1 Motor drive connector, Proximity zero Table and locking and unlocking Table.

- C2 supply solenoid valve connector, locking and unlocking Table, feeding 220 V and " M "

Function of the Machine tool.

Connect to supply 220 V cable an electrical plug 220 V.

DON'T TURN ON THE POSITIONING.

3. Connect the idraulic gearcase to the Table coupler bayonett, and connect the nipple of the solenoid

valve to the gearcase.

4.Put an hydraulic connector the air-treatement group (YELLOW) of the gearcase for compressed-

air, fill with oil the lubrification bowl of the prussere gauge.

and then suppy with compressed air 4/6 Atm.

IMPORTANT: Supply the table gear-case pressurizer on the table gear-case for the “WATER TIGHT”

(pneumatic coupler tube ∅8 mm)

At this point turn on the positioning turning counter clockwise the " EMERGENCY KEY "

(RED).

6. Wait some second, while ther CNC positioning does his self-diagnostic and the display shows

" Mecc. SCOTTI ".

Now the positioning is ready to use in MANUAL and AUTOMATIC MODES or for

PROGRAMMING .

USER INSTRUCTIONS FOR CNC MECCANICA SCOTTI

DESCRIPTION :

- Dimension 335 x 315 x 235

- Weight about 19 Kg

- Operative temperature from 2° to 35° C

- Moisture from 20 % to 80 %

- Keyboard 20 keys

- LCD display 16 x 2 backlighted

- Power supply 220 V AC +/- 10 %

The Control allows 2 types of released functioning allowing, its use as indipendent system

(MANUAL WORKING) or as interfaced to the Machine tool (WORKING from PROGRAM).

MANUAL WORKING .

In manual made, all the function set by keyboard, are immediately performed everytime you push a

key of execution ( Î) .

In general (apart some cases) the command sintax is the following :

( X ) ( X ) ( X ) ( X ) ( X ) NUMERICAL VALUE (It appear on the second line on the display)

[ ( 2ND ) ] ( X ) FUNCTION CODE (It appear on the first line on the display)

( Î) EXECUTION KEY

To minimize keynumber, every key has a second function; if you push it after the key " 2ND ", it

performs the second function.

Example : - The key 5 pushed alone means 5.

- The key 5 push after the key " 2ND " means " DELAY ".

KEY MEANING :

1. Dividually pushed :

(1) = 1 (2) = 2 (3) = 3 (4) = 4

(5) = 5 (6) = 6 (7) = 7 (8) = 8

(9) = 9 (0) = 0

NEW OLD

(2nD) ( A ) = Key of " SECOND FUNCTION "

(Î) = Key of " EXECUTION "

(FCW) ( C ) = Key of " FORWARD CONTINUOS ROTATION "

(STP) ( D ) = Key of " POSITION DISPLAY / READ THE PROGRAM "

(OUT) ( E ) = Key of " OUTPUT ON "

(ANG) ( F ) = Key of " INCREMENTAL FORWARD DEGREES "

(PGM) (

) = Key of " SAVE "

(FPG) ( # ) = Key of " STOP PROGRAM "

(BAS) ( + ) = Key of " SECOND AXIS "

(ALT) ( −) = Key of " STOP "

2. The same keys pushed after the key (A) take the following meanings :

(2ND)(1) ( A ) ( 1 ) = GOTO ( Skip a program step )

(2nD)(2) ( A ) ( 2 ) = AVAILABLE for CUSTOMIZING

(2ND)(3) ( A ) ( 3 ) = FORWARD INDEXINGS

(2ND)(4) ( A ) ( 4 ) = BACKWARDS INDEXINGS

(2ND)(5) ( A ) ( 5 ) = DELAY ( Don't use )

(2ND)(6) ( A ) ( 6 ) = ROTATING SPEED ( From 1 at 500 )

(2ND)(7)

( A ) ( 7 ) = ABSOLUTE DEGREES

(2ND)(8)

( A ) ( 8 ) = SET of " ZERO PIECE "

(2ND)(9) ( A ) ( 9 ) = N°. REPETITION

(2ND)(2ND) ( A ) ( A ) = CANCEL VISUALIZATION

(2ND)( Î) ( A ) ( Î) = DON'T USED

(2ND)(FCW) ( A ) ( C ) = CONTINUE BACKWARDS ROTATION

(2ND)(STP) ( A ) ( D ) = READ the PROGRAM AGAIN

(2ND)(OUT) ( A ) ( E ) = OUTPUT OFF

(2ND)(ANG) ( A ) ( F ) = INCREMENTAL BACKWARDS DEGREES

(2ND)(PGM) ( A ) (

) = PROGRAM RUNNING

(2ND)(FPG) ( A ) ( # ) = DON'T USED

(2ND)(ALT) ( A ) ( −) = DON'T USED

*(0) (2ND)(7)

( 0 ) ( A ) ( 7 ) = RETURN to ZERO PIECE

(Angle value) (2ND)(7) (Angle value) (A) (7)= ABSOLUTE POSITIONING

(1) (2ND) (8) ( 1 ) ( A ) ( 8 ) = RESET TABLE AXIS ( Mechanical Zero ).

( 0 ) (2ND) ( 8 ) ( 0 ) ( A ) ( 8 ) = SET ZERO PIECE ( Rest Display ).

KEY MEANING :

1. Individually type:

(1) = 1 (2) = 2 (3) = 3 (4) = 4

(5) = 5 (6) = 6 (7) = 7 (8) = 8

(9) = 9 (0) = 0

NEW

(2nd) = Key of " SECOND FUNCTION "

(Î) = Key of " EXECUTION "

(FCW) = NOT USED

(STP) = Key of " POSITION DISPLAY / READ THE PROGRAM "

(OUT) = Key of " OUTPUT ON "

(ANG) = NOT USED

(PGM) = Key of " SAVE "

(FPG) = Key of " STOP PROGRAM "

(BAS) = Key of " SECOND AXIS "

(ALT) = Key of " STOP "

2. The same keys pushed after the key (2nd) take the following meanings :

(2nd)(0) = WAIT FOR START (WAIT M CODE or START TABLE)

(2nd)(1) = GOTO ( Skip a program step )

(2nd)(2) = NOT USED

(2nd)(3) = NOT USED

(2nd)(4) = NOT USED

(2nd)(5) = DELAY ( Don't use )

(2nd)(6) = ROTATING SPEED ( From 1 at 500 )

(2nd)(7)

= NOT USED

2(2nd)(8)

= SET of " ZERO PIECE " - CREATE ZERO PIECE (RESET DISPLAY)

2nd)(8)

= RESEARCH CAM ORIGIN TABLE MECHANICAL ZERO

ONLY IN 4 OUT Î

(2nd)(9) = N°. REPETITION

(2ND)(2ND) = CANCEL VISUALIZATION

(2ND)(STP) = READ the PROGRAM AGAIN

(2ND)(OUT) = OUTPUT OFF

(2ND)(ANG) = NOT USED

(2ND)(PGM) = PROGRAM RUNNING

For Example :

* If you want to carry out a rotation of 90 degrees and 12 hundredths degrees .

TYPE : ( 9 ) ( 0 ) ( 1 ) ( 2 ) = NUMERICAL VALUE

( ANG ) = FUNCTION (Forward degrees) - (2ND)(ANG) =Backword

degrees

(Î) = EXECUTION

* If you want return to zero piece or reach an angle in absolute .

TYPE : ( 0 ) = NUMERICAL VALUE

( 2ND ) ( 7 ) = Function ( Return to Zero Piece )

(Î) = EXECUTION

* If you want to carry out the reset of table axis (Mechanical Zero) .

TYPE : ( 1 ) = NUMERICAL VALUE

( 2ND ) ( 8 ) = RESET FUNCTION

(Î) = EXECUTION

* If you want to set " Zero Piece " position .

TYPE : ( 0 ) = NUMERICAL VALUE

( 2ND ) ( 8 ) = RETURN TO ZERO

(Î) = EXECUTION

* If you want to carry out a rotation like 1/127 of 360 degrees .

TYPE : ( 1 ) ( 2 ) ( 7 ) = NUMERICAL VALUE

( 2ND ) ( 3 ) = Function ( FORWARD DEGREES )

(Î) = EXECUTION

***** N. B. *****

The control will hold the current position, while the Table is turning, untill you turn off the power, in

this case you must reset the Table.

You can also loose teoric Zero position if you stop the machine by stop key (-) an indexed rotation

(degrees) (indexing) (return to zero) forward and backwards.

MANUAL MODE

The manual mode is active when appear on the display Mecc. SCOTTI or MANUAL MODE

EXAMPLE

•If you want to carry out a rotation of 90 degrees and 12 centesim of degree with the tilting axis :

Type ( 9 ) ( 0 ) ( 1 ) ( 2 ) = NUMERICAL VALUE

(BAS) = FUNCTION (TILTING DEGREE IN ABSOLUTE)

(Î) = EXECUTION

•If you want to SET THE ZERO PIECE RESETT TABLE

N.B. The zero piece can not be the mechanical zero and it can be carry out everywhere with the

function ( 1 ) ( 2nd) ( 8 )

Type ( 4 ) (OUT ) (Î) = MANUAL TILTING AXIS

( 2 ) = NUMERICAL VALUE

( 2nd) ( 8 ) = SET ZERO FUNCTION

(Î) = EXECUTION

***N.B.***

The control unit memorized the position until you take out the supply while the table is moving ; in

this case it is better to reset the mechanical zero.

You can lose the theorical position of the table also when you stop an indexing rotation

(DEGREE,INDEXING,RETURN TO ZERO) forward and backwards typing STOP (ALT).

•If you want to come back to the ZERO PIECE or to reach an absolute angle :

Type ( 0 ) = NUMERICAL VALUE

(BAS) = FUNCTION (RETURN TO ZERO)

(Î) = EXECUTION

•If you want to research the MECHANICAL ZERO TABLE

Type ( 4 ) (OUT) (Î) = MANUAL TILTING AXIS

( 1 ) = NUMERICAL VALUE

(2nd) ( 8 ) = FUNCTION OF ZERO RESEARCH

(Î) = EXECUTION

KEY and FUNCTION USEFUL IN MANUAL

STP

The “QUOTA VISUALISATION” key is very useful in manual way.

In manual way, after ever positioning it is possible to control the quota, that the table has reached,

pushing the STP key.

The same key STP pushed in EDIT, makes the program run increasing (for example from step N01 to

step N02), while pushing the “2nd STP” keys in EDIT, it makes the program run decreasing (for

example from step N02 to step N01”

2nd 2nd

When you push two time consequently the 2nd allow you to cancel a numerical value, a function or

what the display show.

ATTENTION ! the 2nd key do not permit a break in the program or a positioning.

The 2nd key is used in MANUAL and in EDIT with the same meaning.

ALT

The ALT key has only the function to stop a positioning or a function.

The ALT key is used in MANUAL, EDIT and in AUTOMATIC.

MAIN OPERATION TO RESTORE OR TO CREATE THE “ZERO PIECE”

•In order to restore or create “ZERO PIECE” in the circumference we suggest operate in this way :

Type the funciton :

( 4 ) (OUT) (Î) = MANUAL TILTING AXIS

( 4 ) (2nd) ( OUT ) (Î) = AUTOMATIC TILTING AXIS

Carry out “TILTING ZERO”

( 4 ) (OUT) (Î) = MANUAL TILTING AXIS

( 4 ) (2nd) ( OUT ) (Î) = MECHANICAL ZERO TILTING AXIS

Reset the tilting axis

( 1 ) ( 2nd) ( 8 ) = ZERO PIECE TILTING AXIS

ATTENTION ! you can lost ZERO PIECE when :

•Carry out the MECHANICAL ZERO TABLE

( 1 ) ( 2nd ) ( 8 ) ( Â)

•Break off the supply of 220V while the table is rotating.

•For particular reasons to check carefully when they happened.

ERROR MESSAGE

The control gives some messages about main malfunction that could happen. These messages appear

in full extention and they are :

1. " CHECKSUM ERROR " : Checksum error of memory if the buffered memory has lost some

file because of a BLACK-OUT or a storm, it is necessary to check the saved programs.

This error signal will inform the utilizer that the buffered RAM BATTERY is exhausted

(Duration about 4years) .

Check the EPROM and control that the bridge on the two pins is near the battery.

2. " BLACK OUT " : Positioning error. The error is caused by an electrical black out during the

motor rotation. In this case the motor loses its Zero reference.

It is necessary to remake the Zero positioning.

3. " LOCKING ERROR " : Table locking error.

If after a long period from the locking command, the piston has not reached the correct

position, it will appear " LOCKING ERROR " .

Check air pressure and the locking solenoid valve supply.

Check the good functioning of the locking/unlocking proximity.

Control that the table parameters are enable for the locking function.

4. " UNLOCKING ERROR " : Table locking error.

If after a long period from the locking command, the piston has not reached the correct

position, it will appear " UNLOCKING ERROR " .

Check air pressure and the locking solenoid valve supply.

Check the good functioning of the locking/unlocking proximity.

Control that the table parameters are enable for the unlocking function.

5. TABLE POSITIONING ERROR ON THE 360 DEGREE.

Check the load on the table that must correspond with the one indicated on the Load Table

Schema.

Check the militar connector it should be dry and all the wires are well welded.

Check the mechanical parts of the table that functioning well.

Check the oil in the worm screw and helical ring gear box.

Lubricate the table plateau through the 2 oiler

The driving card can be broken, control the switch on/off of the green LED, when the table

move.

6. ENCODER ERROR

The encoder show that the table is not in the programmed point.

See alarm point 5.

Check the good functioning of the encoder.

Check the encoder cable, probably there are some tug wires.

Connector pin.

7. THE TABLE GO ON ROTATING AFTER HAVING SET A MACRO INDEXING OF

THE CIRCUMFERENCE :

Check if you have insert the function of “ARC TO INDEX” ( 360 00 ) (2nd ) ( 2 ) ( Â) from

manual way.

Table des matières

Manuels Système de contrôle populaires d'autres marques

Pentair Pool Products

Pentair Pool Products Compool Manuel utilisateur

ComfortNET

ComfortNET CTK04 Manuel utilisateur

Fireye

Fireye InSight II 95DSS3 Manuel utilisateur

CAME

CAME G3000 Manuel utilisateur

Idemia

Idemia MorphoAccess VP MD Manuel utilisateur

Axis

Axis P1445-LE-3 Manuel utilisateur

HEIDENHAIN

HEIDENHAIN TNC 150 B Manuel utilisateur

CNC-Step

CNC-Step High-Z T-Series Manuel utilisateur

Doosan

Doosan DVF Series Manuel utilisateur

Honeywell

Honeywell KAP 140 Manuel utilisateur

Honeywell

Honeywell vk41 series Manuel utilisateur

AirBench

AirBench FPW Guide d'installation

Cypress

Cypress HHR-3160 Manuel utilisateur

CAME

CAME GLT40AOS Manuel utilisateur

Zonex

Zonex GEN II -VVT Guide de l'utilisateur

Altronics

Altronics K 9650 Manuel utilisateur

micro-trak

micro-trak RoadMaster Manuel utilisateur

micro-trak

micro-trak Calc-An-Acre II Manuel utilisateur
