Maytag MDG-30 Fast Dry Guide de configuration

ADC Part No. 113069

011899JEV/cj

WARNING: For your safety the

information in this manual must be

followed to minimize the risk of fire or

explosion or to prevent property damage,

personal injury or death.

Do not store or use gasoline or other flammable

vapor and liquids in the vicinity of this or any

other appliance.

WHAT DO YOU DO IF YOU SMELL GAS

* Do not try to light any appliance.

* Do not touch any electrical switch; do not use

any phone in your building.

* Clear the room, building or area of all

occupants.

* Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.

* If you cannot reach your gas supplier, call the

fire department.

Installation and service must be performed by a

qualified installer, service agency or the gas

supplier.

AVERTISSEMENT: Assurez-vous de bien

suivre les instructions données dans cette

notice pour réduire au minimum le risque

dincendie ou dexplosion ou pour éviter tout

dommage matériel, toute blessure ou la mort.

Ne pas entreposer ni utiliser dessence ni

dautres vapeurs ou liquides inflammables dans

le voisinage de cet appareil ou de tout autre

appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR

DE GAZ:

* Ne pas tenter dallumer dappareil.

* Ne touchez à aucun interrupteur. Ne pas

vous servir des téléphones se trouvant dans

le bâtiment où vous vous trouvez..

* Évacuez la pièce, le bâtiment ou la zone.

* Appelez immédiatement votre fournisseur de

gaz depuis un voisin. Suivez les instructions

du fournisseur.

* Si vous ne pouvez rejoindre le fournisseur

de gaz, appelez le service des incendies.

Linstallation et lentretien doivent être assurés

par un installateur ou un service dentretien

qualifié ou par le fournisseur de gaz.

MDG-30 Fast Dry

Installation and Operator’s Manual

For replacement parts, contact the distributor from which the dryer

was purchased or

MAYTAG Co.

403 West Fourth Street North

Newton, Iowa 50208

(515) 792-7000

(Super MP Coin/OPL, DT 30)

Retain This Manual In A Safe Place For Future Reference

For replacement parts, contact the distributor from which the dryer was purchased or contact:

MAYTAG Co.

403 West Fourth Street North

Newton, Iowa 50208

(515) 787-7000

The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are a composite of the

various dryer models. Be sure to check the description of the parts thoroughly before ordering.

' $7( 2)

38 5 &+$6 (

02'(/

12

',675,%87256

1$0(

6 H ULD O 1 XPEH UV

MDG-30 Fast Dry

IMPORTANT NOTE TO PURCHASER

Information must be obtained from your local gas supplier on the instructions

to be followed if the user smells gas. These instructions must be posted in a

prominent location near the dryer.

Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will

provide many years of safe, efficient, and trouble-free operation.

ONLY properly trained and competent technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual

included with the dryer.

The following FOR YOUR SAFETY caution must be posted near the dryer in a prominent location.

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors or liquids

in the vicinity of this or any other

appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser dessence

ni dautres vapeurs ou liquides

inflammables dans le voisinage de cet

appareil ou de yout autre appareil.

We have tried to make this manual as complete as possible and hope you will find it useful. Manufacturer reserves the right

to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change

or discontinue models.

Important

For your convenience, log the following information:

IMPORTANT

YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS

SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE

REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUST-

ING, INSTALLATION, or TESTING OFANY EQUIPMENT per OSHA (Occupational

Safety and HealthAdministration) STANDARDS.

CHILDREN SHOULD NOT BE ALLOWED TO PLAY ON OR NEAR THE DRYERS.

WARNING

CHILDREN SHOULD BE SUPERVISED IF NEAR DRYERS IN OPERATION.

DRYERS SHOULD NEVER BE LEFT UNATTENDEDWHILE IN OPERATION.

CAUTION

FOR YOUR SAFETY

DO NOT DRY MOPHEADS IN THE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRYCLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices

ever be disabled.

Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.

«Attention: Lor des opérations dentretien

des commandes étiqueter tous fils avant

de les déconnecter. Toute erreur de

câblage peut étre une source de danger et

de panne.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY or FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and

specified in the installation and operator's manual included with the dryer.

Dryers must not be installed or stored in an area where it will be exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER and SCREEN

IN PLACE, EVEN IFAN EXTERNALLINT COLLECTION SYSTEM IS USED.

WARNING

Table of Contents

SECTION I

IMPORTANT INFORMATION ............................................................................... 3

A. RECEIVING and HANDLING ....................................................................................................... 3

B. SAFETY PRECAUTIONS .............................................................................................................. 4

SECTION II

SPECIFICATIONS .................................................................................................... 6

SECTION III

INSTALLATION PROCEDURES ........................................................................... 8

A. UNPACKING and SETTING UP ................................................................................................... 8

B. LOCATION REQUIREMENTS ...................................................................................................... 9

C. DRYER ENCLOSURE REQUIREMENTS ................................................................................... 10

D. FRESHAIR SUPPLY .................................................................................................................... 11

E. EXHAUST REQUIREMENTS ..................................................................................................... 12

F. ELECTRICALINFORMATION ................................................................................................... 18

G. GAS INFORMATION .................................................................................................................. 23

H. PREPARATION FOR OPERATION............................................................................................. 27

I. PREOPERATIONALTESTS ........................................................................................................ 28

J. PREOPERATIONALINSTRUCTIONS ....................................................................................... 29

K. SHUT DOWN INSTRUCTIONS ................................................................................................. 32

SECTION IV

SERVICE AND PARTS INFORMATION .............................................................33

A. SERVICE ...................................................................................................................................... 33

B. PARTS........................................................................................................................................... 33

SECTION V

WARRANTY INFORMATION ...............................................................................34

A. RETURNING WARRANTY CARDS ........................................................................................... 34

B. WARRANTY ................................................................................................................................34

SECTION VI

ROUTINE MAINTENANCE ...................................................................................35

A. CLEANING .................................................................................................................................. 35

B. ADJUSTMENTS ........................................................................................................................... 36

C. LUBRICATION............................................................................................................................. 36

SECTION VII

TROUBLESHOOTING ............................................................................................37

SECTION VIII

TECHNICAL INFORMATION ...............................................................................44

A. DATALABEL ................................................................................................................................ 44

SECTION IX

PROCEDURE FOR FUNCTIONAL CHECK REPLACEMENT COMPONENTS ........... 46

SECTION I

IMPORTANT INFORMATION

A. RECEIVING and HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or

optional box) as a means of preventing damage in transit. Upon delivery, the dryer, packaging and wooden skid

should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect further before

delivering carrier leaves.

Dryers damaged in shipment:

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker's receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers which were not damaged in a

damaged shipment should be accepted, but the number received and the number refused must be noted on

the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier's freight terminal immediately and file a claim. The freight company considers this concealed

damage. This type of freight claim is very difficult to get paid and becomes extremely difficult when more

than a day or two passes after the freight was delivered. It is your responsibility to file freight claims. Dryer

and parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

The manufacturer assumes no responsibility for freight claims or damages.

6. If you need assistance in handling the situation, please contact the manufacturer's traffic manager at (508)

678-9000.

IMPORTANT: The dryer must be transported and handled in an upright position at all times.

B. SAFETY PRECAUTIONS

WARNING: For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING: The dryer must never be operated with any of the back guards, outer tops, or

service panels removed.

PERSONALINJURY or FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser or user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALL occupants.

e. IMMEDIATELY call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryers must be exhausted to the outdoors.

6. Although the MDG-30 Fast Dry is a very versatile machine, there are some articles that, due to fabric

composition or cleaning method, should not be dried in it.

WARNING: Dry only water-washed fabrics. DO NOT dry articles spotted or washed in dry cleaning

solvents, a combustible detergent, or "all purpose" cleaner.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,

or wax.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry mop heads. Contamination by wax or flammable solvent will create a

fire hazard.

WARNING:DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage

plastics or rubber and also may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust duct

work, and area around the back of the dryer. The frequency of inspection and cleaning can best be

determined from experience at each location.

WARNING: The collection of lint in the burner area and exhaust duct work can create a potential fire

hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the CANADIAN

ELECTRICAL CODES PARTS 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE: Failure to do so will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or heat safety

circuit, ever be disabled.

WARNING:PERSONALINJURY or FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articles left in the dryer after the drying and cooling cycles have been complete can create

a fire hazard.

12. READ and FOLLOW ALL CAUTION and DIRECTION LABELS ATTACHED TO THE DRYER.

WARNING:YOU MUST DISCONNECT and LOCKOUTTHE ELECTRIC SUPPLYand

THE GAS SUPPLYBEFOREANYCOVERS or GUARDSARE REMOVED

FROM THE MACHINE TOALLOWACCESS FOR CLEANING

, ADJUSTING, INSTALLATION, or TESTING OFANY EQUIPMENT per

OSHA (Occupational Safety and HealthAdministration) STANDARDS.

0$;,080&$3$&,7<





'5< :(,*+7

OEVNJ

%$6.(77

80%/(5

',$0(7(5  FP

%$6.(77

80%/(5

'(37+  FP

%$6.(77

80%/(5

02725 +3 NZ

+3 NZ

'22523(1,1*



'

,$0(7(5

  FP

%$6.(792/80( FXIW FXP

$3352;:(,*+78

1&5$7('

 OEV NJ

$3352;:(,*+7&

5$7('

 OEV NJ

'5<(563(5758&. 

'5<(563(5758&. 

92/7$*($9$,/$%/( Y¡Y¡+]

+($7,1387 EWXKU NFDOKU

EWXKU NFDOKU

$,5)/2: FIP FPP

FIP FPP

,1/(76,=( 137 FP

(;+$867'8&7287/(7 'LD FP

6KDGHGDUHDVDUHLQPHWULFHTXLYDOHQWV

Super 30

SECTION II

SPECIFICATIONS

A. SPECIFICATIONS

* Specifications noted are for 60 Hz dryer models ONLY.

** Specifications noted are for 50 Hz dryer models ONLY.

NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or

obligation.

Gas

Autres manuels pour MDG-30 Fast Dry

Ce manuel convient aux modèles suivants

Autres manuels Maytag Séchoir

Maytag

Maytag MEDE900VJ - Performance 7.5 cu. Ft. Steam Electric... Manuel utilisateur

Maytag

Maytag Bravos W10260037A Manuel utilisateur

Maytag

Maytag MDE17MN Manuel utilisateur

Maytag

Maytag LDGA300AGE Manuel

Maytag

Maytag MEDZ600TE - Epic Z Front Load Electric Dryer Manuel utilisateur

Maytag

Maytag MDE20PDAGW Manuel utilisateur

Maytag

Maytag MGDX5SPAW Manuel utilisateur

Maytag

Maytag MDE17MN Manuel utilisateur

Maytag

Maytag MEDE300V Manuel de la liste des pièces

Maytag

Maytag MGD5900TW1 Manuel utilisateur

Maytag

Maytag YMEDB400VQ0 Manuel utilisateur

Maytag

Maytag MD8058 Manuel utilisateur

Maytag

Maytag MGDE500VW - Performance Series Front Load Steam Gas... Manuel utilisateur

Maytag

Maytag LD9206 Manuel utilisateur

Maytag

Maytag MEDE900VJ1 Manuel utilisateur

Maytag

Maytag MDE20MN Manuel utilisateur

Maytag

Maytag W10057351A Manuel utilisateur

Maytag

Maytag BRAVOS MEDB200VQ0 Manuel utilisateur

Maytag

Maytag MGD5707TQ1 Manuel utilisateur

Maytag

Maytag MGDC700VW - Centennial Gas Dryer Manuel utilisateur

Maytag

Maytag MLG-30PDA Manuel utilisateur

Maytag

Maytag YMED9600SQ0 Manuel utilisateur

Maytag

Maytag MEDZ400TQ1 Manuel utilisateur

Maytag

Maytag NEPTUNE MD55 Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
