TOP AND CONSOLE PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

02−09 Printed in U.S.A. (MP) (eeb) Part No. W10247616 Rev. A

GAS DRYER

TOP AND CONSOLE PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10200966

Perf. Tips Sheet

W10156734

Tech, Sheet

W10201175

Guide, Use & Care

W10201170

Guide,

Quick Start

W10110298

Console Assembly

W10222206

Assembly,

User Interface

W10051124

Cover,

UI−Assembly

W10051126

Knob, Assembly

W10111621

Control Electronic

7 3395683 Connector

(Motor)

8 8572039 Seal, UI

9 8563853 Bracket, Machine

Controller

W10003770

Screw

11 3347243 Connector,

6−Circuit Assembly

W10110295

Bracket, Console

W10111848

Top

User Interface

15 337686 Screw, 8−18 x 1/2

W10112673

Clip, console

W10111056

Harness, Wiring

Main

20 3391018 Tie, Cable

21 3936144 Connector

22 94613 Terminal

23 3394427 Clip, Harness

24 3403498 Connector,

3−Position

(Gas Valve)

W10131402

Screw (3)

W10219695

Seal, top(LH)

W10219694

Seal, top(RH)

CABINET PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

CABINET PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

W10007520

Clip, Ground

2 8544753 Bracket, Burner

3 3390631 Screw, 10−16 x 3/8

4 8558833 Plate, Cover

Terminal Block

5 8564012 Switch, Assembly

6 344020 Cord, Power

W10183827

Cabinet

8 3392100 Foot, Dryer

279810 Foot − Optional

(Extended Length

Package Of 2)

(Not Included)

9 660658 Clamp, Motor (2)

10 3387374 Spring, Idler

11 3389420 Retainer, Idler

W10001340

Nut, Fly Wheel

13 8547160 Pulley Assembly

W10201446

Bracket−Gas Pipe

W10111867

Filler

16 8539892 Wire,Motor

(To Belt Switch)

W10153170

Badge

W10167613

Wire−Belt Switch

(To Protector)

19 3394083 Clip,

Front Panel (2)

20 8564010 Switch & Actuator

Assembly

21 8579717 Assembly,

Hinge (2)

W10183818

Cover, gas valve

23 8564011 Bracket, Switch

24 8576626 Fly−Wheel

26 3393657 Restrainer, Belt

W10136932

Motor, Assembly

60 HZ.

28 8558830 Panel, Rear

W10139247

Pulley, Blower

W10136934

Belt, Drive

31 8578560 Hole, Plug

(Cabinet Base)

32 8547158 Bracket, Motor

W10111905

Door Catch

Assembly

W10002600

Screw,

6−20 x 1 1/4

35 8568303 Locator,

Snap Down (2)

W10215725

Cover, door switch

37 3400805 Screw, 8−18 x.375

W10144494

Plug−Hole

W10215728

Seal−Door

40 342055 Screw, 8−18 x 18

W10201785

Door Switch

Assembly

43 8576625 Lock, Top Front

W10044490

Seal, Front Panel

45 8564457 Plug, Front Panel

46 238088 Hinge Top (2)

W10111879

Door, Inner

W10226482

Seal, foam

W10111876

Door, Outer

W10136930

Pulley,

Drum Motor

W10236201

Panel, Front

W10111906

Strike & Plate

Assembly

W10111888

Plug, Strike

BULKHEAD PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

BULKHEAD PARTS

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8575324 Shaft, R.H. Thread

2 8577274 Thermistor,

Blower Housing

3 90767 Screw, 8−18 x 3/8

4 3394986 Spring, Lint

Screen Door

5 8544757 Air Duct Assembly

6 697813 Seal, Outlet

Housing

7 8573068 Seal,

Blower Cover

8 3934666 Nut,3/8 x 16(R.H.)

9 8544742 Belt−Blower

10 8557244 Bulkhead Front

W10219342

Screw, 11−16 x 3/4

12 487909 Screw, 8−15 x 1/2

13 8544721 Seal, Lint Duct

14 3394984 Door, Lint

Screen

15 8544755 Exhaust Pipe

W10001120

Nut, 3/8−16 (L.H.)

17 8557234 Bulkhead, Rear

18 3387459 Washer, Support

19 8575325 Shaft, L.H. Thread

20 690997 Ring, Tri

21 8536973 Roller, Support

22 8539889 Harness,

Flame Switch

23 3394985 Outlet Housing

Assembly

24 8544741 Bracket,

Blower Housing (2)

25 8557269 Complete Drum

Assembly

W10178353

Lint Screen

W10116344

Seal, Drum

28 693995 Screw

29 3387223 Electrode, Sensor

30 3402841 Lens, Drum

Light

31 3406124 Bulb, Light

32 8544737 Wheel, Blower

33 3977373 Bracket, Light

W10168632

Socket, Assembly

35 8573713 Thermal Cut−Off

36 3391912 Thermostat,

High−Limit

37 8544735 Housing, Blower

38 8544786 Lint Duct Assembly

39 8573824 Funnel, Burner

40 338906 Sensor, Radiant

41 8544719 Cover, Blower

(Includes No.7)

42 3387230 Screw,

10−16 x 13/16

43 8544739 Pulley, Blower

44 8563860 Baffle, Drum

45 3350424 Screw

46 8544718 Duct−Inlet Blower

47 8544723 Grill, Outlet

48 3390719 Thermal Fuse

49 8573070 Clip,

Lint Duct

50 353424 Hous−3

CKT.093 RCP

51 97787 Screw,11−16x.750

W10111028

Gas Harness

BA−154A

USE WITH TYPE 1 − NATURAL

AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES

8557891 BURNER ASSEMBLY

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8557891 Burner Assembly

60 Hz.

(Type 1)

(White Rodgers)

2 8573010 Tube, Burner

3 694298 Bracket, Ignitor

4 686590 Ignitor

5 3393909 Screw & Washer

(8−32 x 7/8)

6 343641 Screw, 10−16 x 1/2

7 8544751 Base, Burner

8 3387057 Screw,

8−18 x 3/8

9 Orifice, Burner

15418 Type 1

15422 Type 4 (Butane)

229742 Type 4 (Propane)

10 8573071 Valve, Gas

60 Hz. (Complete)

(Includes Pipe &

Illus. #7).

11 694421 Screw,

8−32 x 1/2 (2)

12 8182790 Bracket, Coil

13 694540 Coil, 60 Hz.

(2 Terminal)

(Main)

14 694539 Coil, 60 Hz.

(Split)

(3 Terminal)

(Pilot Position)

15 694424 Leak, Limiter

16 694423 Screw, Regulator

Adjustment

17 694422 Spring, Regulator

Following Parts Not Illustrated

8576846 Conversion Kit

(Type (1)

to Type (4) LPG).

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

OPTIONAL PARTS (NOT INCLUDED)

For Model: MGDB400VQ0

(White Color Coordinated)

W10247616

Illus. Part

No. No. DESCRIPTION

ACCESSORY PARTS

80047 Kit,

Dryer Repair

8522199 Kit, Dryer

Vent Testing

346764 Kit, Hold−Down

(Gas Dryer Mobile

Home Installation)

PAINT, TOUCH−UP (1/2oz.)

72017 White

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

350938 Primer, Gray

PAINT, BULK (1 qt.)

799344 White (Uncut)
