MAXTOR ONETOUCHTM III





– User-congurable RAID solution

– Use RAID 0 for high performance

disk striping or RAID 1 for automatic

mirroring

– Up to 1.5TB storage capacity

– FireWire 800 for fast data transfer

– 924 chipset

– Pre-formatted for Mac; easily

formatted for Windows





Designed for creative professionals who

need the disk striping speed of RAID 0 for

intensive disk-access applications or the

security of RAID 1 for automatically mirror-

ing data, the Maxtor OneTouch III, Turbo

Edition provides an easy to use wizard

interface for conguring your system for

optimal performance.



With the most highly integrated storage,

backup, security and drive management

software on the market today, the Maxtor

OneTouch III, Turbo Edition is perfect for

creative professionals who need a high

performance, large capacity storage

solution. Faster throughput means faster

workow, and that means greater productivity

for creative professionals who work in

digital video, photography and graphic

arts. The user-congurable Maxtor RAID

solution streamlines performance to enable

multiple streaming without dropping

frames—critical in quality video editing.

The Maxtor OneTouch III, Turbo Edition

supports both Mac and Windows® platforms.

It arrives preformatted for the Mac and

includes the 924 chipset for ultimate Mac

performance. Plus when you need it most,

you can boot your Mac OS X directly from the

drive. And to keep things simple, a wizard

interface makes it quick and easy to format

for Windows.

Using Maxtor’s simple user interface, you

have the option to easily back up your entire

computer drive or selected les either

automatically or at the touch of a button.

The Maxtor DriveLock™ security feature

password-protects the contents of your

drive, helping to safeguard your les if the

drive is lost or stolen or against unauthor-

ized users.

The Maxtor OneTouch III, Turbo Edition is

ideal for anyone when:

– You demand the disk striping speed of

RAID 0 to enable multiple video streams

without dropping frames during high-end

video editing

– You need the safety of RAID 1 for auto-

matically mirroring your digital portfolio

– You want to easily congure your RAID

solution for maximum performance

or as an additional safeguard

– You need massive storage capacity for

your digital portfolio

– You produce professional digital video

and demand seamless, real-time access

to huge, data intensive les

– You create digital audio, music, 3D games,

graphic design, motion graphics, or

multimedia productions

Maxtor OneTouch III Turbo Edition—

RAID performance doesn’t get any

easier than this.

1TB/1.5TB



Capacity (model #)

RAID 0 / RAID 1

1TB (C01W010)

1.5TB (C01W015)

Hard drives:

(two) 3.5-inch ATA

RPM

7200 RPM

Integrated Interface

– FireWire® 800, IEEE 1394b, iLink: up to

800MB/sec data transfer rates

– FireWire 400, IEEE 1394a, iLink: up to

400MB/sec data transfer rates

– USB 2.0 and 1.1 - up to 480 MB/sec data

transfer rates

Cache Buffer

16MB

Platform

Mac and PC



Average seek time:

– ≤ 9.0 ms

Sustained transfer rate (maximum):

– FireWire 800–91MB/sec

– FireWire 400–43MB/sec

– USB 2.0–33MB/sec



– External hard drive

– EMC® Retrospect® Express HD backup

software

– 9 to 9 pin FireWire 800/1394/iLink cable

– External AC power adapter

– Installation CD with backup software and

User guide

– Quick start guide

– Maxtor 1-year limited warranty







All Maxtor products are backed by our leading service

and support staff.

Service includes:

– 24-hour on-line troubleshooting tools and email

– Maxtor’s commitment to total customer satisfaction

– Product support representatives available

Monday-Friday

To speak with a Maxtor product support representative:

In the U.S. and Canada, call 1-800-2MAXTOR

Mon.–Fri. from 8:00 a.m. to 5 p.m. (MST)

In Europe, call +353 1 204 1111

Mon.–Thur. from 8:30 a.m. to 5 p.m. (GMT) and

Fri. 8:30 a.m. to 4 p.m. (GMT)

In Australia, call 800-124-328

In Asia, call +65 6 481 6788

Mon.–Fri. from 7:00 a.m. to 3:00 p.m. (Singapore GMT +7)



Operating temperature:

– 5ºC to 35ºC (41ºF to 95 ºF)



– Dimensions: 5.4” 3.9” x 8.5”

(136 x 98 x 217 mm)

– Weight: 5.8 lbs (2.6 kg)



– Box dimensions: 6”H x 11”W x 8.5”

(152 x 279 x 216 mm)

– Box weight: 8.2 lbs (3.72 kg)

– Units per pallet: 80



Mac

– FireWire 800 requires Mac OS X 10.2.8 or

higher and FireWire 800 (9-pin) equipped-

computer

– Apple G4 processor or greater

– Mac OS X (10.2.8 or later): 128 MB (256

recommended) RAM or more as required

by operating system

– CD-ROM drive

– Internet connection (for system updates)

– FireWire 800 requires Windows® 2000 or

XP operating system and FireWire 800

(9-pin) equipped computer

– Pentium III, 500 MHz equivalent processor

or higher

– Windows 2000 Professional, XP Profes-

sional, or XP Home Edition

– 128MB (256 recommended) RAM or more

as required by operating system

– CD-ROM drive

– Internet connection (for system updates)

black

white

One gigabyte, or GB, equals one billion bytes when referring to hard drive capacity. One terabyte, or TB, equals 1,000 gigabytes when referring to hard drive

capacity.

Accessible capacity may vary depending on operating environment and formatting. Quantitative usage examples for various applications are for illustrative

purposes and

are based on the following assumptions: each hour of DVD-quality video is 2.1GB, each digital photo is 1MB, and each MP3 is 4 minutes long. Actual quantities will

vary based on various factors, including le size, le format, features and application software

of Seagate Technology LLC. Other trademarks are the property of their respective holders. Seagate Technology, 920 Disc Drive, Scotts Valley, CA 95066 U.S.A.
