MaXLine®III

SATA/PATA HARD DRIVE

250GB 300GB

REFERENCE STORAGE

AND DATA PROTECTION

3.5" ATA DRIVES foR 24x7

PowER-on APPlIcATIonS

HIGHlIGHTS

•Large capacity up to 300GB

•7200 RPM

•SATA 1.5Gb, SATA 3.0 Gb and

PATA interfaces

•16MB cache buffer

•SATA II features

•Native command queuing for

2X improved random read

performance over previous

generation MaXLine

•12.5 rad/sec2rotational

vibration

•RoHS compliant

ExcEPTIonAl RElIABIlITy

•5-year warranty

•Rated to 1 million hours

MTTF* at low I/O duty cycles

•S.M.A.R.T. features

Large capacity, highly reliable hard drives for reference

storage and data protection applications

MaXLine III provides the capacity, reliability, and features required for

mainstream reference storage and data protection applications. With

MaXLine III, IT managers can confidently deploy faster, more efficient

alternatives to traditional backups, as well as point-in-time copies,

snapshot clones and remote replication. Businesses can cost effectively

keep more reference data on-line to enhance business decisions and

support processes. The third-generation MaXLine drives offer up to 300GB

storage capacity and has been designed to meet a Mean Time To Failure

(MTTF) of 1 million hours* in low I/O duty cycle nearline applications.

Offered with a five-year limited warranty, MaXLine III drives are available

in either parallel or serial ATA interfaces.

Maxtor MaxCommand™

technology

• Native command queuing

• Adaptive cache algorithms

• Support for increased cache

size—16MB

• Read streaming performance

SATA II features

• Native command queuing

• Hot plug

• Staggered spin-up

• Presence detect

• Identify device

• Set Features

• Asynchronous recovery

RoHS Compliant

Maxtor supports the EU

directive for Restriction of

Hazardous Substances (RoHS)†.

RoHS compliant versions of

MaXLine III are available.

Best-fit enterprise applications

• Reference storage

• Email archive

• Data warehousing

• Point-in-time copy

• Snapshot clones

• Remote replication

• Disk-to-disk-to-tape

• Video security

†Directive 2002/95/EC of the European Parliament and of the Council of 27 January, 2003.

For purposes of measuring drive capacity, a megabyte (MB) means 1,000,000 bytes, a gigabyte (GB) means 1,000,000,000 bytes. Total accessible capacity varies depending on

operating environment. Seek times are at nominal conditions and include settling. Specifications subject to change without notice. Seek performance developed utilizing tech-

nology licensed from Convolve, Inc.

* MTTF refers to the estimated mean time to failure based upon a statistical sample.

Maxtor Corporation. All other trademarks are the property of their respective owner. Printed in the USA. Maxtor Corporation, 500 McCarthy Boulevard, Milpitas, CA, 95035.

DS-ML3-7/06-CL

SPECIFICATIONS

250GB 300GB

Formatted Capacity (GB) 250 300

Bytes per Sector 512

Interface

Parallel ATA/133

SATA 150

SATA 300

Disk Drive Configurtions

Disks 3 3

Heads 5 6

Bytes per Sector/Block 512

Performance Specifications

Spindle Speed (RPM) 7200

Seek Time:

Average Read (ms) 9.0

Track-to-Track Read/Write (ms) 0.8

Average Rotational Latency (ms) 4.17

Full Stroke (ms) <17

Transfer Rate:

Parallel ATA Maximum 133

Burst Transfer Rate (MB/s)

Serial ATA (MB/s) 150

Buffer (Cache) Size (MB) 16

Reliability Specifications

MTTF (Mean Time To Failure) 1,000,000

at low duty cycle

Contact Start Stop (CSS) Cycles 50,000

Data Error Rate per Bits Read

Recoverable <10 per 1012

Nonrecoverable <1 per 1015

Limited Warranty (years) 5

250GB 300GB

Operating

Temperature (˚C) 5–55

Non-Condensing Humidity (%) 5 to 95

Shock 2 msec 60

(Linear half sine G)

read & write

Rotational Shock (rad/sec2, 2ms) 2000

Random Vibration 0.86

10–2000 Hz (GRMS)

Rotational Vibration 12.5

10–2000 Hz (rad/sec2)

Altitude (ft)

-650 to 10,000

Acoustics, Idle (bels) 2.7

Non-Operating

Temperature (˚C) -40 to 71

Non-Condensing Humidity (%) 5 to 95

Shock 2 msec 300

(Linear half sign G)

Vibration 7– 800 Hz (GRMS) 3

Altitude (ft)

-650 to 40,000

Power Specifications

Voltage Requirements 5V+/-5% 12V+/-10%

Idle Mode (W) SATA: 6.7

PATA: 6.3

Physical Dimensions

Width max (mm) 101.6

Length max (mm) 147

Height max (mm) 26.1

Weight typical (grams) 630

ORDER INFORMATION

Capacity 250GB 300GB

Model SATA 3Gb, 16MB cache 7V250F0 7V300F0

SATA 1.5Gb, 16MB cache 7L250S0 7L300S0

ATA/133, 16MB cache 7L250R0 7L300R0

For support or information, call us at 1-800-2Maxtor or visit us at www.maxtor.com

All Maxtor products are backed by our leading service and support staff.

Service includes:

• 24-hour on-line troubleshooting tools and email

• Maxtor’s commitment to total customer satisfaction

• Product support representatives available Monday-Friday

To speak with a Maxtor product support representative:

In the U.S. and Canada, call 1-800-2MAXTOR,

Mon.–Fri. from 8:00 a.m. to 5 p.m. (MST).

In Europe, call +353 1 204 1111

Mon.–Thur. from 8:30 a.m. to 5 p.m. (GMT)

and Fri. 8:30 a.m. to 4 p.m. (GMT)

In Australia, call 800-124-328

In Asia, call +65 6 481 6788

Mon.–Fri. from 7:00 a.m. to 3:00 p.m. (Singapore GMT +7)
