DiamondMax®Plus 8

ATA HARD DRIVE

40GB

PERFORMANCE

HIGHLIGHTS

•3.5-inch 7200 RPM

mainstream performance

hard drive

•Designed for mainstream

commercial and consumer

performance PC Users

FEATURES

Industry leading design,

optimized to meet the needs

of entry level and value

applications:

•Supports today’s favorite

capacity –40GB

•ATA/133, the fastest and

latest IDE interface

•FDB (fluid dynamic bearing)

motor for quiet operation

•Low height to improve

airflow and cooling

•Low weight to reduce

shipping costs

•Improved reliability with:

–Shock Protection System™

–Data Protection System™

•RoHS compliant version

available

Mainstream Performance for Desktop Systems

Maxtor hard drive leadership continues with the DiamondMax®Plus 8

drive, the industry’s first single-head, single-platter, 7200 RPM product.

DiamondMax Plus 8 drives provide 40GB capacity. Combining perform-

ance and value, the drive is a perfect combination for the mainstream

consumer or commercial user.

Maxtor-developed Ultra ATA Interface

DiamondMax Plus 8 drives use the

Ultra ATA/133 interface, the fastest

desktop interface, with data transfer

rates of 133 MB/sec.

Fluid Dynamic Bearing (FDB) Motors

DiamondMax Plus 8 drives are

equipped with FDB motors.

This technology allows the drive

to operate with very low sound

output for performance users who

are concerned about acoustics.

RoHS Compliant

Maxtor supports the EU directive

for Restriction of Hazardous

Substances (RoHS)†. RoHS compli-

ant versions of DiamondMax Plus 8

are available.

Delivering Reliability

DiamondMax Plus 8 drives deliver

high reliability and data integrity

using the Maxtor-developed Shock

Protection System (SPS) and Data

Protection System (DPS). SPS and DPS

give the drive enhanced protection

against operating and non-operating

shock to minimize costly drive returns.

When your application requires

excellent performance at mainstream

capacities, select DiamondMax Plus 8

drives from Maxtor.

†Directive 2002/95/EC of the European Parliament and of the Council of 27 January, 2003.

Performance Specifications

Rotational Speed 7200 RPM

Buffer Size 2MB

Max External Transfer Rate (MB/sec) 133

Average Seek (ms) <10

Average Latency (ms) 4.17

Drive Configuration

Bytes per Sector/Block 512

Logical CHS 16,383/16/63

Reliability Specifications

Head Load/Unload (min) 100,000

Component Design Line (min) 5 years

Data Errors (non-recoverable) <1 per 10E 15 bits read

Annualized Return Rate (ARR) <1%

Power Requirements

Mode 5V 12V

Seek (mA) 562 440

Idle (mA) 396 440

Standby (mA) 65 35

Environmental Limits

Acoustics FDB motor

Idle (sound power: bel) 2.7

Seek (sound power: bel) 2.8

Temperature

Operating (°C)* 5 to 60

Non-operating (°C) -40 to 71

Shock

Operating Mechanical Shock 2ms (G) 60

Non-operating Mechanical Shock 2ms (G) 300

Physical Dimensions

Height (max mm) 17.5

Width (typical mm) 101.6

Length (max mm) 146.1

Weight (LB/g) 1.12/510

*See product manual for operating temperature

Specifications subject to change without notice. For purposes of measuring drive storage capacity, 1 GB means 1 billion bytes. Total accessible capacity varies

depending on operating environment. Seek times and acoustics are average values. Seek performance developed utilizing technology licensed from Convolve, Inc.

ty of their respective owner. Printed in the USA. Maxtor Corporation, 500 McCarthy Boulevard, Milpitas, CA, 95035. DS-DiamondMaxPlus8-4/05-CL.

For support or information, call us at 1-800-2Maxtor or visit us at www.maxtor.com

All Maxtor products are backed by our leading service and support staff.

Service includes:

•Advance replacement in 2 business days

•24-hour on-line troubleshooting tools and e-mail

•Maxtor’s commitment to total customer satisfaction

•Product support representatives available Monday-Friday

To speak with a Maxtor product support representative in the U.S. and Canada,

call 1-800-2MAXTOR, Mon.-Fri. from 5 a.m. to 5 p.m (PST).

In Europe, call +353 1 204 1111 Mon.-Thur. from 8:30 a.m. to 5 p.m (GMT)

and Fri. 8:30 a.m. to 4 p.m. (GMT).

In Australia, call +61 2 9369 3662. In Japan, call 00531653616, And in Singapore, call

65-6852-0220 or 1-800-481-6788.

ORDER INFORMATION

Capacity 40GB

Model ATA/133 2MB buffer 6E040L0

RoHS Compliant Version

Model ATA/133 2MB buffer 6K040L0
