Maxtor NAS 6000 Manuel utilisateur

Installation Guide

Getting Started with

MaxAttach NAS 6000

Rack Mount

Base Unit Systems

ii 000001630

MaxAttach NAS 6000 Getting Started

10/16/01 -- Revision 2.0.03

MaxAttach NAS 6000 Getting Started

Document Revision Information

MaxAttach™ and MaxNeighborhood™ are trademarks of Maxtor Corporation. Other product names, company names,

and logos are trademarks or registered trademarks of their respective owners.

Specifications Subject to Change

Specifications are subject to change without notice. Maxtor reserves the right to revise this publication and to make

changes in the content hereof without the obligation of Maxtor to notify any person of such revision or changes.

Next Business Day on site service for your NAS 6000 and wish to ensure that your service is activated. If you have not

already received a service activation contract from Maxtor, please contact 1-800-4MAXTOR or visit our web site at

www.MaxAttach.com. Should you have any questions about activating your MaxAttach NAS 6000, please do not

hesitate to contact us. Thank You

Worldwide Customer Support

Technical support is available worldwide.

Document Title: Getting Started with MaxAttach NAS 6000 Rack Mount Base Unit Systems

Part Number: 000001630

Corporation: Maxtor Corporation

Product Name: MaxAttach NAS 6000

Operating System: Microsoft Windows-Powered Max Operating System Version 2.0

O/S Name Revision: Max O/S 2.0

Manual Release Date: 10/16/01

Manual Revision: Revision 2.0.03

Change History: First release

United States 1-800-4MAXTOR www.maxattach.com

United Kingdom, France, Italy, Spain, Portugal, and

Denmark

+353 1 204 11 11 (Ireland) EuroNSG@Maxtor.com

Germany +49 (0) 89 96241919 EuroNSG@Maxtor.com

Japan 03-3235-5690 MaxAttach@novelplan.co.jp

Asia Pacific +852-2585-4500 ApacNSG@Maxtor.com

Revision 2.0.03 - 10/16/01 1000001630

MaxAttach NAS 6000

Getting Started with Base Only

Systems

System Applicability

Use this document for MaxAttach NAS 6000 rack-mountable Base Unit only systems. For

more information, see:

nGetting Started for MaxAttach NAS 6000 Base Unit Only Systems - PN: 000001630, or

nChapter #3 - Getting Started for Base Only Systems in the MaxAttach NAS 6000

Installation and Configuration Guide - PN: 000001577.

Documents for Other MaxAttach NAS 6000 Systems

For other MaxAttach NAS 6000 systems, see any of the following:

nCabinet Mounted Systems

nthe printed Quick Start Card for MaxAttach NAS 6000 - PN: 000001530, or

nGetting Started for MaxAttach NAS 6000 Cabinet Mounted Systems - PN:

000001629, or

nChapter #2 - Getting Started for Cabinet Systems in the MaxAttach NAS 6000

Installation and Configuration Guide - PN: 000001577.

nRack-Mountable Base Units plus Expansion Unit/s

nGetting Started for MaxAttach NAS 6000 Base Plus Systems - PN: 000001631, or

nChapter #4 - Getting Started for Base Plus Systems in the MaxAttach NAS 6000

Installation and Configuration Guide - PN: 000001577.

nSystems Installed in Chatsworth 48” Cabinet Racks

nGetting Started for 48” Cabinet Rack Systems - PN: 000001632, or

nChapter #5 - Getting Started with 48” Cabinet Racks in the MaxAttach NAS 6000

Installation and Configuration Guide - PN: 000001577.

nSystems Installed in Chatsworth 84” Cabinet Racks

nGetting Started for 84” Cabinet Rack Systems - PN: 000001634, or

nChapter #6 - Getting Started with 84” Cabinet Racks in the MaxAttach NAS 6000

Installation and Configuration Guide - PN: 000001577.

Getting Started with Base Only Systems 2000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

Documents for Other MaxAttach NAS 6000 Systems

10/16/01 -- Revision 2.0.03

nDefault Disk Array Configuration for MaxAttach NAS 6000 Expansion Units

nChapter #7 - Getting Started with Disk Array Default Configuration in the Maxtor

MaxAttach NAS 6000 Installation and Configuration Guide.

Thank You

Thank you for purchasing this MaxAttach NAS 6000. The MaxAttach comes with the

Microsoft Windows-Powered Max Operating System Version 2.0 installed.

1: Box Contents

The MaxAttach NAS 6000 Base Unit comes as a rack-mountable unit and your shipping

box contains the components listed below:

Hardware

nBase Unit with the following installed components:

nTwo power supply modules

n12 hard disk drive carrier assemblies

nOne gigabit network interface card (NIC) with copper wire connections

nOne gigabit NIC with fiber optic connections

nRack Hardware

nNecessary fasteners to mount the Base Unit in the user supplied rack.

nCables

nTwo AC power cords

nOne Environmental Monitoring Unit (EMU) to CPU I/O Panel Male/Female

(M/F) Serial Cable

Paper Documentation

nGetting Started for MaxAttach NAS 6000 Base Unit Only Systems (also in PDF)

nMaxAttach NAS 6000 End User License Agreement (EULA) (also in PDF)

nMaxAttach NAS 6000 Release Notes (paper only)

Software and Electronic Documentation

nA MaxAttach NAS 6000 Installation and Documentation CD containing:

nMaxNeighborhood Discovery and Setup Wizard

Getting Started with Base Only Systems 3000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

2: Required Installation Environment

10/16/01 -- Revision 2.0.03

nElectronic system documentation (all as Adobe Acrobat PDF files unless

otherwise noted) consisting of:

• Quick Start Card for MaxAttach NAS 6000

• Getting Started for MaxAttach NAS 6000 Cabinet Systems

• Getting Started for MaxAttach NAS 6000 Rack Mount Base

Only Systems

• Getting Started for MaxAttach NAS 6000 Rack Mount Base

Plus Systems

• Getting Started for 48” Cabinet Rack Systems

• Getting Started for 84” Cabinet Rack Systems

• MaxAttach NAS 6000 Installation and Configuration Guide

• MaxAttach NAS 6000 Administration Guide

• Help Files for Microsoft Windows-Powered Max Operating

System Version 2.0.

NOTE

This standalone help file system is a compiled Microsoft HTML Help file with a CHM file

extension. It is specifically designed to display HTML help in Microsoft's HTML Help

viewer. This viewer window uses components of the Internet Explorer browser and

ActiveX technology. It cannot be viewed in Netscape Navigator, Macintosh, or UNIX due

to their lack of support for ActiveX.

2: Required Installation Environment

Your MaxAttach needs the following environmental conditions for installation:

nAn operating space with adequate ventilation, absence of dust, no standing water, and

sufficient electrical power.

nA space of at least 36” - 90cm behind the cabinet to allow access to the inner

equipment shelves in the event of a service call.

nAdequate ground and cable routing space around the rack.

3: Necessary Equipment for Installation

The following user-supplied equipment is required for a rack-mount system:

Getting Started with Base Only Systems 4000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

4: Record Unit Information

10/16/01 -- Revision 2.0.03

nRack

nA standard 19” rack with at least 4U of space for the Base Unit. If the addition

of Expansion Units is anticipated, leave an additional 4U above the Base Unit

for each Expansion Unit, up to a total of 8U empty for future needs.

nFloor fastening hardware.

nEarthquake hardware or similar securing systems.

nAC Power Strips or Power Blocks

nTwo AC Power Strip with at least three connectors per strip.

nCords should be long enough to reach two different AC power sources.

nUse of a UPS is recommended.

nNIC cables

nOne NIC cable for each primary NIC card used.

nOne NIC cable for the administration network link mounted on the CPU (if

used).

nNetwork

nA network connection into your network for each NIC cable.

nA client administration workstation to install and administer your MaxAttach NAS

6000 with the following minimum system requirements:

nMicrosoft Windows operating system 95, 98, NT with Service Pack 5 or

higher, 2000, or ME

nInternet Explorer (IE) version 5.01 or newer. Other browsers such as Netscape

are not supported.

• IE version 5.5 is required for advanced security features

such as the Log Out tab on the Navigation Bar.

nA 10/100 Mbps Ethernet NIC card

nA CD-ROM drive

nTCP/IP enabled

4: Record Unit Information

Please record the following information from the identification panels on the back of each

enclosure and on the inside of the cabinet:

nModel number

nSerial number of each base and expansion enclosure

nType and quantity of hard disk drives.

Getting Started with Base Only Systems 5000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

5: Rack Mount Your Maxtor MaxAttach NAS 6000 Base Unit

10/16/01 -- Revision 2.0.03

For more information, see Re-Seat All Hard Disk Drive Carrier Assemblies on page

5: Rack Mount Your Maxtor MaxAttach NAS 6000 Base Unit

In this procedure, you will install your rack, install the MaxAttach NAS 6000 Base Unit,

install a necessary EMU cable, and connect the Base Unit Power Cords to the

user-supplied power strips.

1. Securely install your rack in the server location.

nIf you use an existing rack, a space of 4U per MaxAttach equipment shelf is

required.

2. Mount the MaxAttach Base Unit enclosure at the bottom of the rack.

nRecommend that you leave 4U to 8U above the Base Unit to allow future

Expansion Units.

nUp to two Expansion units can be added; each requires 4U of space and must

be added above the Base Unit.

NOTE

All left and right directions in the procedure below are when viewed from the BACK

PANEL.

6: Install the EMU Cable

In this section, you will connect the Base Unit CPU Serial Port 1 to the Environmental

Management Unit (EMU) EXT 1 port.

1. Install the Base Unit EMU Cable.

nShort Male/Male (M/M) serial cable

nStart at EMU left side EXT1 port

2. Connect to CPU I/O Panel Serial Port 1.

Getting Started with Base Only Systems 6000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

7: Connect Network Cables and AC Power Cords

10/16/01 -- Revision 2.0.03

7: Connect Network Cables and AC Power Cords

In this section, you will connect your NICs to your network with user-supplied NIC

cables. You will also connect the AC power cords to the equipment shelves and connect

them to user-supplied AC power strips.

Network Connections

1. Connect the appropriate NIC cables.

nBetween each NIC and the network.

nAt least one network connection is required.

nYou can also add a network connection from the CPU I/O panel network port

to your network for administrative functions.

AC Power Connections

2. On the Base Unit back panel, make sure all the power supply ON/OFF rocker

switches are in the OFF or “O” position.

nThere are two back panel switches on the Base Unit.

3. On the Base Unit back panel, connect each AC power cord.

nTwo AC power cords are required for each Base Unit.

4. Route the AC power cords to user-supplied AC power strips and connect.

5. Connect each AC power strip cord to local AC power source.

nRecommend that each AC power strip be on a separate circuit.

nRecommend that an UPS power back up system be used to provide additional

system safety.

Getting Started with Base Only Systems 7000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

8: Re-Seat All Hard Disk Drive Carrier Assemblies

10/16/01 -- Revision 2.0.03

8: Re-Seat All Hard Disk Drive Carrier Assemblies

Shipping vibration may have disconnected individual hard drives from their back plane

connectors. One drive at a time, pull the drive out of its Drive Bay, record its size and serial

number information, and replace it in its as-shipped Drive Bay location.

CAUTION

REPLACE IN ORIGINAL DRIVE BAY: Be sure to replace the drive in its original as-shipped

Drive Bay. If you mix the drives and Drive Bays up, you will probably have to reconfigure

the disk RAID arrays.

1. For each drive, push down on the Ejector Tab, and then lift up on the Ejector Lever.

nThe drive releases from its Drive Bay connector.

2. Pull the drive out of its Drive Bay.

nThis is a good time to record the drive type and serial number.

3. Replace the drive in its Drive Bay until it begins to engage the connector.

4. Make sure the Ejector Lever is free of the Ejector Tab and place your fingers on

either side of the drive LEDs and press gently into the bay.

5. Lower the Ejector Lever to latch the drive into place and then lock the Ejector Lever

on the Ejector Tab.

6. Repeat until all hard disk drive carrier assemblies have been re-seated.

9: Power Up Your Maxtor MaxAttach NAS 6000

1. Turn the back panel rocker switches to “ON” or “|”.

nThere are two rocker switches on the Base Unit Back Panel.

nThere is no required starting order.

2. Press the front panel soft rocker switch in the lower right hand corner to start the

units.

nYou will receive front panel indications that the system is booting.

nIt takes about 4.5 minutes to fully boot.

3. System LEDs will show normal boot status.

Getting Started with Base Only Systems 8000001630

MaxAttach NAS 6000 Getting Started

Getting Started with Base Only Systems

9: Power Up Your Maxtor MaxAttach NAS 6000

10/16/01 -- Revision 2.0.03

nGreen System Status LEDs: When fully booted, the system power-on

(middle) LED will be green.

nBlue System Error Status LED: The blue upper system status and the lower

drive status LEDs should be dark.

nGreen Drive Activity LEDs: The green disk drive activity LEDs will indicate

when the system has reached a steady status.

nAmber Drive Unavailable LEDs: The amber disk drive unavailable LEDS

should be off.

nGreen Power Supply LEDs: Each power supply has a green LED on the left

for correct DC voltage status and another green LED on the right for correct

AC voltage status.

4. The Status LCD panel will show normal system operation for system starting, disk

normal, and local area network normal.

5. When activity stops, the system has completely booted.

6. Go to your client administrative workstation.

Autres manuels pour NAS 6000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Maxtor Serveur de stockage réseau

Maxtor

Maxtor MaxAttach NAS 3000 Manuel utilisateur

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor STM310004SDAB0G-RK - Maxtor Shared Storage II NAS... Manuel utilisateur

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor MaxAttach NAS 4000 Manuel utilisateur

Maxtor

Maxtor NAS 6000 Mode d’emploi

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor MaxAttach NAS 3000 Manuel utilisateur

Maxtor

Maxtor MaxAttach NAS 4100 Manuel technique

Maxtor

Maxtor NS-349S Manuel utilisateur

Maxtor

Maxtor MaxAttach NAS 6000 Manuel technique

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Maxtor

Maxtor Maxtor Central Axis Manuel utilisateur

Manuels Serveur de stockage réseau populaires d'autres marques

HP NetStorage 6000 Manuel utilisateur

Seagate

Seagate U10 ST320423A Manuel utilisateur

Synology

Synology RackStation RS816 Manuel

D-Link

D-Link ShareCenter Pro DNS-1200-05 Manuel utilisateur

Avid Technology

Avid Technology VideoRAID ST Guide de sécurité

Western Digital

Western Digital My Cloud Home Duo Manuel utilisateur

PrimeArray

PrimeArray 4xxx Manuel utilisateur

Buffalo

Buffalo TeraStation WSS WSH5010N6 Manuel utilisateur

Planex

Planex MZK-NAS01SG Manuel utilisateur

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuel utilisateur

Synology

Synology RS2212+ Manuel utilisateur

Allnet

Allnet ALL69000 Manuel utilisateur

Adaptec

Adaptec 5325301580 Manuel utilisateur

Motorola

Motorola EXORdisk II Manuel utilisateur

Sony

Sony XDAAI1PK Manuel utilisateur

Cisco

Cisco Linksys NAS200 Instructions d'utilisation d'origine

Sans Digital

Sans Digital MR4UT6G Manuel utilisateur

AIC

AIC FB128-LX Manuel utilisateur
