MAXTEK 62207 Manuel utilisateur
USER GUIDE
Deckless Bluetooth Car Stereo
MODEL NUMBER: 62207
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Deckless Bluetooth Car Stereo
Deckless Bluetooth Car Stereo
62207
UK/N.IRELAND HELPLINE NO 01270 508538
REP.IRELAND HELPLINE NO 1800 995 036
Web Support www.quesh.co.uk
UK/N.IRELAND HELPLINE NO 01270 508538
REP.IRELAND HELPLINE NO 1800 995 036
Web Support www.quesh.co.uk
36
Contents
1. Welcome Section
2. General Information & Safety Instructions
3. Installation
4. Wiring Connections
5. Fascia Controls
6. Remote Control
7. Basic Operation
8. Radio Operation
9. USB & SD Operation
10. AUX In, RCA Out
11. Bluetooth Operation
12. FAQ
13. Specications
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Welcome Section
Congratulations!
You have made an excellent choice with the purchase of this quality
MAXTEK®product.
By doing so you now have the assurance and peace of mind which
comes from purchasing a product that has been manufactured to
the highest standards of performance and safety, supported by the
high quality standards of Quesh.
We want you to be completely satised with your purchase so this
MAXTEK®product is backed by a comprehensive manufacturer’s
3 year warranty and outstanding after sales service through our
dedicated helpline.
We hope you enjoy using this product for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty, please telephone our helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you
have a satisfactory proof of purchase (keep your receipt safe).
This does not affect your statutory rights. However be aware that the
warranty will become null and void if the product is found to have
been deliberately damaged, misused and/or disassembled.
1
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
General information &
Safety Instructions
This remote control is powered by 1 x ‘CR-2025’ lithium battery.
Do not dispose of batteries in your household waste.
Please contact your local authority for details on safe disposal.
• Never throw batteries into a re or expose to excessive heat sources.
• If batteries are swallowed, please seek immediate medical attention.
• Always ensure correct +/- battery polarity when installing batteries.
• Do not recharge non-rechargeable batteries.
Electrical and electronic equipment (WEEE) contains materials, parts and
substances, which can be dangerous to the environment and harmful to
human health if the waste of electrical and electronic equipment (WEEE) is not
disposed of correctly.
Equipment, which is marked with the WEEE logo
(as shown on the left), should not be thrown away with your household waste.
Contact your local authority waste disposal department, as they will be able to
provide details of the recycling options available in your area.
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
2
Please Note:
Mark the polarity of the existing speaker wires before disconnecting battery.
1. After removing the old radio and mounting
sleeve, insert supplied mounting sleeve
into opening.
2. Bend the tabs on the mounting sleeve to
keep the mounting sleeve firmly in place.
3. Attach the wires from the unit to the
existing wires. See wiring connections
diagram. Insert radio into dashboard
then apply the trim frame to the
outside of radio.
DIN Front Mount
Installation
WARNING!
Disconnect negative battery terminal from battery before starting installation.
Consult the vehicle owner’s manual for proper instructions.
3
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Supplied Parts
2 Keys
1 Faceplate Case (not shown)
1 1/8” Stereo Cable
1 Remote control
4
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Make sure that you have a good earth connection. A good earth connection will eliminate most electrical
noise problems. A good earth connection requires a tight connection to the vehicle's metal chassis.
The area around the earth connection should be clean, bare metal without rust, paint, plastic, dust, or dirt
for a good electrical connection.
Please Note:
Follow the above wiring diagram to install the
head unit with new or existing speakers.
This unit is designed for use with four (4) speakers
with an impedance between 4 Ohms to 8 Ohms.
An impedance load of less than 4 Ohms could
damage the unit.
Never bridge or combine the speaker wire
outputs. When not using four speakers, use
electrical tape to tape the ends of the un-used
speaker outputs to prevent a short circuit.
Never connect the negative speaker terminals to
earth connection
.
Wiring Connection
Connector A
1. Rear right speaker(+)/Purple
3. Front right speaker(+)/Grey
5. Front left speaker(+)/White
2. Rear right speaker(-)/Purple-Black
4. Front right speaker(-)/Grey-Black
6. Front left speaker(-)/White-Black
7. Rear left speaker(+)/Green
8. Rear left speaker(-)/Green-Black
Connector B
1. -
2. -
3. -
4. Battery 12V (+)/Yellow
5. Antenna power/Blue-White
6. -
7. ACC+/Red
8. Ground/Black
ISO-connector
A
B
RCA OUT
left=white
right=red
Antenna
socket
5
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Fascia Controls
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Mode Select / TA /Answer Button
Sound Select / VOLume +/- / AF
Next Track / Fast Forward Button
Remote Control Receiver
LCD Screen
USB Slot
Release Panel Button
Auto Preset Scan / Reject Button
Power On / Off / Mute
Band Switch / PTY
Previous Track / Backwards Button
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Number 1 / Play / Pause
Number 2 / Introduction
Number 3 / Repeat
Number 4 / Random
Number 5 / Folder Down
Number 6 / Folder Up
AUX Input Port
Microphone receiver
SD Card slot
Reset Button
6
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Remote Control
Operating the remote control
• Aim at the face panel of the CD receiver, the maximum distance at which signals can be received
is about 6 metres.
• Make sure that the signal path is not obstructed.
Battery Safety
• Take care when fitting batteries, observing the polarity marking on the battery and the product.
• Never dispose of batteries in fire. Risk of explosion.
• Never attempt to recharge non-rechargeable batteries.
• Seek immediate medical advice if you believe a cell has been swallowed.
• Keep batteries away from children.
• Remove batteries from a product if it is not to be used for a period of time.
Replacing the batteries
Follow the 3 steps below:
1. Remove the cover from the back of the remote control.
2. Insert a CR-2025 Lithium battery.
3. Replace the cover on the back of the remote control.
1. Power On / off
2. Mute Sound Button
3. Stations Tune / Seek / Track Down
4. Band Switch
5. TA Control
6. Radio Memory 1-6
7. Mode Select
8. Sound +
9. Time Clock Display
10. Sound Select Key
11. Stations Tune / Seek / Track Up
12. Sound -
13. Auto Preset Scan
14. AF Control
15. PTY Control
MUTE
SEL
CLK
BND APS
PTYAFTA
1 2 3
6
5
4
MODE
1
2
3
4
5
6
7
8
9
11
12
13
14
15
10
7
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Basic Operation
Tuning the unit On / Off
Press POWER button to turn the unit on. Press
again to turn the unit off.
Mode Selection
Press the MODE button repeatedly to cycle through
different play modes.
Loudness Control
Press the VOL dial repeatedly until the display
shows “LOUD ON” or “LOUD OFF”. Rotate the
VOL dial to adjust. When “LOUD ON” is shown on
the display indicates that loudness function is on.
Mute Control
Press the MUTE button to activate the mute
function. Press the button again to cancel.
Volume
Rotate the VOL dial to adjust the volume level. Turn
the VOL dial clockwise to increase the volume, and
vice versa. The larger the number of volume, the
louder the volume level.
Bass
Press the VOL dial repeatedly until the display
shows “BAS”. Rotate the VOL dial to adjust. When
DSP is ON, bass control is not available.
Treble
Press SEL dial repeatedly until the display shows
“TRE”. Rotate the VOL dial to adjust. When DSP is
ON, treble control is not available.
Balance
Press VOL dial repeatedly until the display shows
“BAL”, then Rotate the VOL dial to adjust the
balance between the left & right speakers. When
“L=R” is shown on the screen, it indicates that the
balance is 0.
Fader
Press VOL dial repeatedly until the display shows
“FAD”, Rotate the VOL dial to adjust the balance
between the front & rear speakers. When “F=R” is
shown on the screen, it indicates that the fader is 0.
Preset Equalizer Function
Press VOL dial until the display shows “EQ” ,then
rotate the VOL dial to choose the EQ sound effects.
The Sequence of equalizer setting will be as follows:
FLAT-ROCK-POP-CLASS
Press VOL dial to confirm.
Beep Function
Press VOL dial repeatedly until the “BEEP” shown
on the screen. Rotate the VOL dial to choose
“BEEP OFF” or “BEEP ON”. “BEEP OFF” means
beep function is inactive. “BEEP ON” means a beep
sound will be heard when any button pressed.
Clock
Press the CLK button on the remote, the clock will
show on the display. Press and hold the VOL button
for 3 seconds will also show the clock. The clock
will be automatically set by the RDS signal from the
main radio stations.
Reset
Turn the unit off with the ‘ON/OFF’ button. Press and
hold ‘MOD’ & ‘BND’ for 3 seconds. A message will
appear on the display to confirm the unit has reset.
Menu Cycle:
Press VOL then press VOL again to cycle to the next option.
Bass > Treb > Bal > FAD > Loud > EQ > Stereo/Mono > LOC > Beep
8
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Radio Operation
Choose Radio Band
Press the BND Button anytime to access the radio
function. The unit comes with five bands, three FM
Bands (FM1, FM2, and FM3) and two AM Bands
(AM1, and AM2). Each of the five bands can store
up to six preset stations, for a total of 30 preset
memory stations.
Radio Tune / Seek Function
In radio mode, press the Seek +/- button to
automatically seek the next strong and clear radio
station. Press and hold the Seek +/- button until
the screen shows MANUAL. At this time, you can
manually fine tune your desired frequency. Wait until
the MANUAL disappears in order to perform auto
seek again.
Press and hold the SEEK |<< or >>| button for 2
seconds and the radio will seek the next strong
and clear frequency station. Repeat to seek more
stations in your listening area with a strong signal.
Mono / Stereo Reception Control
In FM radio mode, Press VOL button repeatedly
until the display shows ‘MONO’ or “STEREO”.
Rotate the VOL dial to choose the reception control,
the word “MONO” shown on the screen indicating
the mono reception is received and “STEREO” for
stereo.
Save Your Preset Stations
There are six numbered preset buttons which
can store and recall stations for each band. While
listening to a radio station you would like to save
as a pre-set, press and hold one of the buttons
numbered 1-6 until the preset station number is
shown. The button you pressed is now the pre-set
button for that station.
Automatic Scan & Store
While listening to the FM or AM Radio, press and
hold the F/PS Button for 3 seconds. The receiver
will automatically scan and save to the presets the
strongest radio station signals available to you in
your area.
Scan Saved Stations
Press the F/PS button once to perform the preset
scanning function. In FM or AM mode, press the F/
PS button and the stations stored in the FM band
preset will be scanned. The scan will pause on each
preset for 6 seconds before moving on to the next.
To stop and listen to a preset of your choice press
the SEL dial.
Local / DX
Press VOL Button repeatedly until the display shown
“LOC”. Rotate the VOL button to choose,
“LOC ON“ or “LOC OFF”. When “LOC ON” is shown
on the display, this means local reception is turned
on. When “LOC OFF” is shown on the display, this
means distant reception is turned on.
Local and distance reception settings can facilitate
the radio reception, depending on the location in
which the radio is being used.
Table des matières
