Passive CCTV Hub Plus (500134)
Installation Guide
P/N: 94-000690-A, SE-000690-A

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 2
Copyright Notice :
Copyright © 2010 MuxLab Inc. All rights reserved.
Printed in Canada. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise without prior written permission of the author.
Trademarks :
MuxLab is a registered trademark of MuxLab Inc.

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 3
Table of Contents
1. Overview ...................................................................................................................4
1.1. Description........................................................................................................4
1.2. Features.............................................................................................................4
2. Technical Specifications...........................................................................................5
3. Installation Procedure..............................................................................................6
3.1. Parts List ...........................................................................................................6
3.2. Product Overview .............................................................................................6
3.3. Pre-Installation Checklist .................................................................................7
3.4. Physical Installation..........................................................................................8
3.5. Installation Procedure .......................................................................................9
4. Troubleshooting......................................................................................................18
5. Distance Tables.......................................................................................................19
6. Product Warranty Policy.......................................................................................21

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 4
1.
Overview
1.1. Description
The Passive CCTV Hub Plus (500134) allows video, remote power and PTZ
control to be transmitted via one Cat5e/6 cable, thus eliminating the need to
install multiple cables for more efficient cabling in the security video
environment. The hub features a detachable, factory-installed, 16-channel
power cable assembly that allows the hub to be connected to a 16-channel
CCTV power supply for greater ease of installation. In order to connect
remote power to the hub, the 16-channel power cable assembly included with
the hub must be used.
The Passive CCTV Hub Plus works in conjunction with MuxLab’s 500000,
500009, 500015, 500022, 500023, 500024, 500029, 500120, 500122 and
500130. The product features a port switch to set the unit to Power-Thru or
Pass-Thru mode.
1.2. Features
•Port switch to set unit to Pass-Thru Mode (500022) or Power-Thru Mode
(500024/500029)
•Includes 16-channel power cable assembly (packaged seperately)
•Pin configuration chart on unit
•Space efficient, rack-mountable

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 5
2.
Technical Specifications
Specifications
Environment Composite video; NTSC, PAL, SECAM
Devices CCTV cameras, DVRs, monitors, switchers, multiplexers and other CCTV equip.
Transmission Transparent to the user.
Video
Bandwidth DC to 8 MHz.
Maximum Input 1.1Vp-p
Insertion Loss Less than 2 dB per pair over the frequency range from DC to 8 MHz
Return Loss Greater than 15 dB over the frequency range from DC to 8 MHz
Common Mode Rejection Greater than 40 dB @ 8 MHz
Max. Distance - Color Cat 3 –1,200 ft (365m); Cat5e/6 – 2,200 ft. (670m)*
*Shorter distances will result with DVR equipment. Typically 1,000 to 1,500 ft
Max. Distance - B&W Cat 3 –1,500 ft (457m); Cat5e/6 – 2,500 ft (762m)
Remote Power
Switch Mode Pass-Thru Mode (500022) Power-Thru Mode (500024/500029)
Number of twisted pairs Two (2) Three (3)
Max. Distance @ 24VAC*
*Based on 10% voltage drop at
camera. Longer distances may
be achieved @ 28 VAC.
5 VA: 350 ft (107m) 10 VA: 175 ft
(53m)
20 VA: 90 ft (30m) 30 VA: 60 ft (20m)
5 VA: 518 ft (170m) 10 VA: 259 ft (85
m)
20 VA: 130 ft (43 m) 30 VA: 86 ft (28 m)
Maximum Input Voltage 50 Volts (AC RMS/DC). Recommended Class II PSU with fuse protection per port
Maximum Current Rating 4.5A (AC RMS/DC)
2-Wire PTZ Control (i.e. RS-422, Manchester/Bi-Phase, half duplex RS485) – Pass-Thru Mode (500022)
Wiring Remote 2-wire PTZ control supported via one (1) twisted pair.
Maximum Distance Up to 4,000 ft (1.2 km) depending on the PTZ camera vendor**
**Please consult your CCTV equipment vendor for more detailed performance
specifications.
Maximum Power Rating 50 Volts (AC RMS/DC); 3A (AC RMS/DC)
Mechanical & Environmental
Cable – UTP 24 AWG or lower solid copper twisted pair wire impedance: 100 ohms at 1 MHz
Maximum capacitance: 20 pf/foot. Attenuation: 6.6 dB/1000 ft at 1 MHz
Cable – Coax Impedance: 75 Ωat 1 MHz. (RG59/U). Max. 25 ft. of coax allowed end to end.
Connectors Video (Model 500130): Sixteen (16) BNC-F
Power: Sixteen (16) 2-pole screw terminals.
Control: Sixteen (16) 2-pole screw terminals.
16-channel factory-installed 24” (61cm) detachable 4-pole connector power
cable assembly included.
Combined signals: Sixteen (16) RJ45 jacks
Port Configuration Switch Sets each port to Pass-Thru Mode (500022) or Power-Thru Mode (500024/500029)
RJ45 Pin Configuration* Signal 500022 Mode 500024/500029 Mode
*Reverse polarity sensitive Power A (+) 1, 3 1, 3, 5
Power B (-) 2, 6 2, 4, 6
Control (+) 4 Not used
Control (-) 5 Not used
Video BNC Center (Tip) 7 [T] opposite to 500000 7 [T] opposite to 500000
Video BNC Ground (Ring) 8 [R] opposite to 500000 8 [R] opposite to 500000
Temperature Operating: 0° to 55°C. Storage:-20° to 85°C. Humidity: up to 95%
Enclosure Black, anodized aluminum
Dimensions 19” (48.26 cm) W x 1.75” (4.4 cm) H x 2.0” ( 5.1 cm) D
Weight 2.6 lbs. (1.2kgs)
Warranty Lifetime
Order Information 500134 Passive CCTV Hub Plus

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 6
3.
Installation Procedure
3.1. Parts List
The Passive CCTV Hub Plus comes with the following parts. Please verify
that all pieces are present before proceeding.
•Base Unit (Factory configuration: Power-Thru Mode (500022)
•16-channel power cable assembly.
•Installation Guide
3.2. Product Overview
The external connections of the Passive CCTV Hub Plus are detailed in the
following diagrams. Please familiarize yourself with them before installing the
unit.
Figure 1: Front panel
Figure 2: Rear panel

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 7
3.3. Pre-Installation Checklist
The Passive CCTV Hub Plus provides a centralized sixteen (16) port CCTV
copper twisted pair cabling solution.
1. The Passive CCTV Hub Plus is used in a CCTV installation to manage the
video, power and control connections between the CCTV cameras and the
head-end. The hub features a 16-channel power cable assembly that
facilitates the connection between a 16-channel CCTV power supply and
the hub.
2. The hub features a switch at each port to select between Pass-Thru Mode
(500022 compatible) or Power-Thru Mode (500024/500029 compatible)
depending on the cabling configuration.
3. The Passive CCTV Hub Plus works in conjunction with MuxLab’s other
CCTV products including the 500000, 500009, 500015, 500022, 500023,
500024, 500029, 500120, 500122 and 500130. The passive CCTV Baluns
are connected at the CCTV camera.
4. The Passive CCTV Hub Plus works with CCTV cameras that have built-in
twisted pair baluns. It may be necessary to reverse the polarity of the wires
first. Distance performance may vary.

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 8
3.4. Physical Installation
The Passive CCTV Hub Plus is a 1U, 19” rackmount unit. The factory default
switch settings of each port is Pass-Thru Mode (500022).
1. Select the final destination for the product in the relay rack and install the
unit using standard rackmount screws.
Figure 3: Rack-mount installation

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 9
3.5. Installation Procedure
The Passive CCTV Hub Plus (500134) features BNC connectors on the video
portion of the device, thereby allowing it to be connected directly to the DVR
via coaxial cable. In order to install the product in this configuration, please
follow the steps below:
1. Install the Passive CCTV Hub Plus in its final location. Please verify that
the distance between the rack and cameras are within MuxLab
specifications.
2. Connect a MuxLab passive CCTV Balun (MuxLab p/n 500000, 500009,
500022, 500023, 500024 or 500029) to each CCTV camera video output.
Please refer to the appropriate CCTV balun installation guide for details.
3. Connect one Cat5 cable from each camera to one of the modular RJ45
ports on the front of the Passive CCTV Hub Plus (fig 5). Please ensure that
EIA 568 wiring and straight-through polarity is respected between the
CCTV balun and the rack. The use of other Cat5 connection hardware
such as patch panels and 110 blocks may be used.
Figure 4: Camera connection

© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
P
a
g
e 10
Port Switch Settings:
4. For each camera port, determine whether video, power and/or control is to
be transmitted via the same Cat5 cable. If only video is to be transmitted,
then the Power/Control terminals and port switch may be disregarded.
5. In order to transmit video on one (1) twisted pair, remote power on two (2)
twisted pairs and control on one (1) twisted pair, set the port switch to
Pass-Thru Mode (500022) using a small flathead screwdriver, as shown in
fig 6. Ensure that there is a CCTV Pass-Thru Balun (500022) at the
camera.
Figure 5: Port Setting – Pass-Thru Mode (500022)
6. In order to transmit video on one (1) twisted pair and remote power on
three (3) twisted pairs, set the port switch to Power-Thru Mode
(500024/500029) using a small flathead screwdriver (fig 7). Ensure that
there is a CCTV Power-Thru Balun (500024 or 500029) at the camera.
Figure 6: Port Setting – Power-Thru Mode (500024/500029)
