Matrix UV Series Manuel utilisateur
azonprinter.com MATRIX GETTING STARTED
To ensure correct and safe usage with a full understanding of this product’s performance please be sure to read through this
manual completely and store it in a safe location
Unauthorized copying or transferal in whole or in part of this manual is prohibited
The contents of this operation manual and the specifications of this product are subject to
change without notice
The operation manual and the product have been prepared and tested as much as possible if you find any misprint or error
please inform us
Azonprinter d.o.o. assumes no responsibility for any direct or indirect loss or damage which may occur through use of this
product regardless of any failure to perform on the part of this product
Azonprinter d.o.o. assumes no responsibility for any direct or indirect loss or damage which may occur with respect to any
article made using this product
ABOUT MANUAL
azonprinter.com MATRIX GETTING STARTED
NAVIGATION
ABOUT MANUAL PAGE 2
ABOUT PRINTER PAGE 4
GENERAL INFORMATION [ MATRIX UV ] PAGE 5
GENERAL INFORMATION [ MATRIX UV PRO ] PAGE 6
GENERAL INFORMATION [ MATRIX UV PRO L ] PAGE 7
PRINT SPEED [ MATRIX UV ] PAGE 8
SAFETY FEATURES & REGULATORY COMPLIANCE PAGE 10
SITE PREPARATION GUIDE [ MATRIX UV ] PAGE 11
SITE PREPARATION GUIDE [ MATRIX UV PRO ] PAGE 12
SITE PREPARATION GUIDE [ MATRIX UV PRO L ] PAGE 13
SITE PREPARATION GUIDE [ ALL ] PAGE 14
IN THE BOX.... [ ALL ] PAGE 18
GETTING TO KNOW YOUR PRINTER [ ALL ] PAGE 21
LCD TOUCH DISPLAY [ ALL ] PAGE 25
PRINTER CONTROL PANEL PAGE 29
PRINTER CONTROL PANEL INDICATOR PAGE 31
INK PAGE 32
INK BOTTLE LABEL PAGE 33
SETTING UP YOUR PRINTER PAGE 34
POWER ON PROCEDURE PAGE 51
POWER OFF PROCEDURE PAGE 53
azonprinter.com MATRIX GETTING STARTED
AZON MATRIX represents only wide-format UV-
curable inkjet flatbed printer on the market with
the ability to print up to 200mm in height. With
optional S, M and L bed sizes; 700 mm x 1900 mm
/ 700 mm x 2500 mm / 1200 mm x 3300 mm
which are handling heavy materials up to 100 kg
for indoor, outdoor and industrial applications.
Prints directly onto any type of material like PET,
ABS, polycarbonate, TPU, wood, stone, glass,
canvas, ceramic, aluminum, and leather. Azon
MATRIX represents an ideal solution for gaining
profit from lower running costs. Capable of
robust industrial printing demands including
heavy, rigid materials and high-quality volume
printing requirements (USB drives, smartphone
cases, lighters, pens etc.) Azon MATRIX is
covering a wide variety of business printing
applications. With long-lasting, highly energy-
efficient UV LED lamp curing system instantly and
efficiently adheres ink to any kind of substrates.
Its robust bed, smart vacuum table, Full-featured
Azon RIP software and UV TurboJet ink
technology ensure a perfect result on each and
every print.
ABOUT PRINTER
azonprinter.com MATRIX GETTING STARTED
GENERAL INFORMATION
M A TR I X
UV
Maximum print size Maximum substrate width 580mm
Maximum substrate length 1200 mm
Maximum substrate height 200 mm
Print Pies inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWVV, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable] ,Cartridges system 220ml
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 7 and above
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1330 mm
Length 2120 mm
Height 1120 mm
Weight 350 kg
azonprinter.com MATRIX GETTING STARTED
GENERAL INFORMATION
M A TR I X
U V P R O
Maximum print size Maximum substrate width 580mm
Maximum substrate length 1200 mm
Maximum substrate height 200 mm
Print Pies inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWVV, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable] ,Cartridges system 220ml
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 7 and above
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1330 mm
Length 2120 mm
Height 1120 mm
Weight 450 kg
azonprinter.com MATRIX GETTING STARTED
GENERAL INFORMATION
M A TR I X
U V P R O L
Maximum print size Maximum substrate width 1070 mm
Maximum substrate length 2450 mm
Maximum substrate height 200 mm
Print Pies inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWVV, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable] ,Cartridges system 220ml
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 7 and above
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1860 mm
Length 3200 mm
Height 1120 mm
Weight 710 kg
azonprinter.com MATRIX GETTING STARTED
UNIDIRECTIONAL
NAME RESOLUTION DIRECTION LAYER TYPE SUBSTRATE TIME
[min/sec] m2/h Ink
FAST 720x360
Unidirectional Color Layer Generic 10:00 4,3 3,36ml
Unidirectional Whitre Layer Generic Not
Supported N/A N/A
Unidirectional White+Color
Inline Generic Not
Supported N/A N/A
SPEED 720x720
Unidirectional Color Layer Generic 22:40 1,9 5,72ml
Unidirectional Whitre Layer Generic 22:40 1,9 1,68ml
Unidirectional White+Color
Inline Generic 31:50 1,3 7,36ml
STANDARD 1440x720
Unidirectional Color Layer Generic 35:10 1,2 7,51ml
Unidirectional Whitre Layer Generic 35:10 1,2 3,36ml
Unidirectional White+Color
Inline Generic 70:10 0,6 10,83ml
QUALITY 1440x1440
Unidirectional Color Layer Generic 67:10 0,6 10,23ml
Unidirectional Whitre Layer Generic 67:10 0,6 6,71ml
Unidirectional White+Color
Inline Generic 153:04 0,2 16,87ml
HIGH
QUALITY 2880x1440
Unidirectional Color Layer Generic 67:10 0,6 16,58ml
Unidirectional Whitre Layer Generic 67:10 0,6 13,42ml
PRINT
SPEED
MATRIX UV
Data was taken when printing maximum print area 580 mm X 1200 mm [7076 cm2]
Ink consumption is calculated by printing 580 mm x 1200mm black square [RGB]
azonprinter.com MATRIX GETTING STARTED
BIDIRECTIONAL
PRINT
SPEED
NAME RESOLUTION DIRECTION LAYER TYPE SUBSTRATE TIME
[min/sec] m2/h Ink
FAST 720x360
Bidirectional Color Layer Generic 06:10 6,8 3,36ml
Bidirectional Whitre Layer Generic Not
Supported N/A N/A
Bidirectional White+Color
Inline Generic Not
Supported N/A N/A
SPEED 720x720
Bidirectional Color Layer Generic 13:20 3,2 5,72ml
Bidirectional Whitre Layer Generic 13:20 3,2 1,68ml
Bidirectional White+Color
Inline Generic 18:20 2,3 7,36ml
STANDARD 1440x720
Bidirectional Color Layer Generic 19:50 2,1 7,51ml
Bidirectional Whitre Layer Generic 19:50 2,1 3,36ml
Bidirectional White+Color
Inline Generic 40:00 1,1 10,83ml
QUALITY 1440x1440
Bidirectional Color Layer Generic 38:10 1,1 10,23ml
Bidirectional Whitre Layer Generic 38:10 1,1 6,71ml
Bidirectional White+Color
Inline Generic 98:50 0,4 16,87ml
HIGH
QUALITY 2880x1440
Bidirectional Color Layer Generic 38:10 1,1 16,58ml
Bidirectional Whitre Layer Generic 38:10 1,1 13,42ml
MATRIX UV
Data was taken when printing maximum print area 580 mm X 1200 mm [7076 cm2]
Ink consumption is calculated by printing 580 mm x 1200mm black square [RGB]
azonprinter.com MATRIX GETTING STARTED
Keep all inks, cleaners and primers out of reach of children
Use promoters in a well-ventilated area
Store inks in a cool dark and dry location
Dispose of all expired and uncured inks in accordance to
local and state laws
All UV inks have a shelf life expiration dates are specified on
each ink cartridge and must be disposed of properly after
expiration
Always wear provided safety glasses and nitrile gloves
whenever there is the possibility of exposure to uncured inks
SAFETY FEATURES & REGULATORY COMPLIANCE
Keep your printer out of direct sunlight which will interfere
with performance of the printer and the UV inks
Always keep the protective UV lid down during operation UV
light can be harmful with direct exposure to skin and eyes
Do not touch the print table or print head while the
printer is in use
Keep hair jewelry and loose clothing away from moving parts
Do not attempt to repair your printer unless the guide
specifically says to do so
Only certified Azon service technicians should disassemble
repair or access internal components
When performing maintenance always unplug the power
cord from the electrical outlet
Only use Azon UV Inks and cleaners with your printer
azonprinter.com MATRIX GETTING STARTED
