Operation Manual
Full-HD (3G/HD-SDI)
Mini-Broadcast POV Cameras
CV343, CV502, CV345, CV505 models
Marshall Electronics
2
MENU STRUCTURE
SETUP SUB MENU SUB MENU
ESC
DC IRIS
AUTO
ATW
PUSH
COLOR TEMPERATURE
RED GAIN
BLUE GAIN
BRIGHTNESS 0~20
AGC LIMIT 0~20
AUTO
MANUAL
FLICKERLESS
DSS (SENS-UP) OFF, x2~64
WDR
BLC
SPOT
ACE LOW, MIDDLE, HIGH
LEVEL
COLOR
ANTI-SAT.
AGC LEVEL
AGC MARGIN
DWELL TIME
COLOR
NIGHT
DAY/NIGHT
AUTO
LENS
WB
CONTROL
MANUAL
AE CONTROL
(EXPOSURE) SHUTTER
BACK LIGHT
BACK LIGHT
ECLIPSE
3
MENU STRUCTURE
SETUP SUB MENU SUB MENU
RANGE 10%, 20%, 30%
FILTER LOW, MIDDLE, HIGH
AUTO C OFF, HALF, FULL
AUDIO LEVEL 0~143
AUDIO AGC OFF, ON
AGC MAX 0~119
SAMPLE BITS 16, 20, 24, 32 BITS
COLOR LEVEL 0~20
SHARPNESS 0~20
MIRROR
FLIP
D-ZOOM 1.0X ~ 16.0X
AUTO
MANUAL
DNR OFF, LOW, MIDDLE, HIGH
MOTION
SHADING
GAMMA
FRAME RATE
CAM VERSION
CAM TITLE
PRIVACY
CAM ID 0~255
BAUDRATE
LANGUAGE
RESET
EXIT
DISPLAY
CONTROL
STABILIZER
AUDIO
CONTROL DEFOG
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
Press SET button to access the MAIN MENU.
Use the UP & DOWN buttons
to select the desired item.
Use the LEFT & RIGHT buttons
to change the sub-item.
Icon indicates “Press OSD Button” or “Enter Sub Menu”.
OSDJoystick and Button
SET
UP
DOWN
RIGHT
LEFT
4
CVBS
3G/HD-SDI
12VDC
RS-485
+ -
+ -
SDICVBS
12VDC RS-485
+ - + -
IRIS
SDI
IRIS
HDMI
POWER
I/O
CV502 CV343 I/O Cable
for CV345/505
Used to access the menu and confirm selection.
Used to move the cursor up.
Used to move the cursor down
Used to move the cursor to left and change the value.
Used to move the cursor to right and change the value.
CV345
ESC
ATW
AUTO
OFF
ON
ON
5
Select LENS using the UP or DOWN button.
You can change between ESC and DC IRIS using the LEFT or RIGHT button.
ESC: Manual IRIS Lens (Fixed IRIS lens)
LENS ESC, DC IRIS
DC IRIS: DC Auto IRIS Lens.
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
ATW
AUTO
OFF
ON
ON
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
DC IRIS
ATW
AUTO
OFF
ON
ON
Shutter will automatically control exposure if SHUTTER is set as AUTO.
IRIS will automatically control exposure.
6
Select WB CONTROL using the UP or DOWN button.
You can change between AUTO, ATW, PUSH, and MANUAL using the LEFT or RIGHT button.
AUTO: Controls the automatic adjustment of the light source's color
temperature to 3,000°K ~ 8,000°K.
WB CONTROL AUTO, ATW, PUSH, MANUAL
ATW: Continuously adjusts camera color balance in accordance with any
change in color temperature. Compensates for color temperature changes
within the range of 1,900°K to 11,000°K.
PUSH: Color temperature will be manually adjusted by pushing the OSD
button. Place the white paper in front of the camera when OSD button is
pressed to obtain the optimum result.
MANUAL: Select this to fine-tune White Balance manually.
You can adjust the blue and red tone level manually.
COLOR TEMP: Select color temperature from LOW, MIDDLE, or HIGH.
BLUE: Adjust the Blue tone of the image. (0~20)
RED: Adjust the Red tone of the image. (0~20)
WB CONTROL
COLOR TEMP LOW
BLUE 10
RED 10
RETURN
■Adjust White Balance first by using the AUTO or ATW mode before switching to MANUAL mode.
■ White Balance may not work properly under the following conditions. In this case, select the ATW mode.
- When the ambient illumination of the subject is dim.
- If the camera is directed towards a fluorescent light or is installed in place where illumination changes
dramatically, the White Balance operation may become unstable.
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
MANUAL
AUTO
OFF
ON
ON
Camera will raise up gain to the selected gain limit under dark conditions.
7
Select AE CONTROL using the UP or DOWN button.
You can select one sub-mode from BRIGHTNESS, AGC LIMIT, SHUTTER, and DSS using
the UP or DOWN button.
AE CONTROL
BRIGHTNESS: The brightness control function adjusts gain and iris to keep
a brightness level.
AGC LIMIT: This function controls the amplification/gain process automatically
if the illumination falls under the usable level.
DSS (Digital Shutter Speed): When luminance condition is low, DSS can adjust
the picture quality by maintaining the light level. Slow shutter speed limits to x64.
SHUTTER: This function control shutter speed.
AE CONTROL
BRIGHTNESS
AGC LIMIT
SHUTER
DSS
RETURN
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
MANUAL
AUTO
OFF
ON
ON
10
10
AUTO
OFF
SHUTTER
MODE
RETURN
NORMAL
MANUAL: Shutter speed will be fixed at the selected speed. (1/60~40,000)
AUTO: Shutter controls exposure automatically when IRIS is manual. (NORMAL/DEBLUR)
FLICKERLESS: This function will help to decrease video flickers due to a conflict with the
installed lighting frequency.
SHUTTER
SPEED
RETURN
1/90
BRIGHTNESS, AGC LIMIT
SHUTTER, DSS
8
BACK LIGHT WDR, BLC, SPOT
BACK LIGHT
WDR: Enable user to view both object and background more clearly when
background is too bright.
WDR-LEVEL:
Select the WDR level from LOW, MIDDLE, and HIGH
using the LEFT or RIGHT button.
BLC: Enable a back light compensation feature.
SPOT: Enable a user to select a desired area on a picture and view that
area more clearly when background is too bright.
AE HOR POS:
Move the SPOT area horizontally using the LEFT or RIGHT button.
AE VER POS:
Move the SPOT area vertically using the UP or DOWN button.
AE WIDTH:
Change the width of SPOT area using the LEFT or RIGHT button.
AE HEIGHT:
Change the height of SPOT area using the UP or DOWN button.
Select BACK LIGHT using the UP or DOWN button and enter using SEL button.
You can select one sub-mode from BACK LIGHT, ACE, and ECLIPSE using the UP or DOWN button.
BACK LIGHT
BACK LIGHT
ACE
ECLIPSE
RETURN
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
MANUAL
AUTO
OFF
ON
ON
SPOT
OFF
OFF
BACK LIGHT
AE HOR POS
AE VER POS
AE WIDTH
AE HEIGHT
RETURN
9
5
4
5
9
BACK LIGHT ACE, ECLIPSE
ACE
:Brightness correction of the dark image area.
Select the GAIN level from OFF, LOW, MIDDLE, and HIGH using the LEFT or RIGHT button.
ECLIPSE
:Highlight the bright area with a masking box with a selected color.
LEVEL:
Select the masking level from 0~20 using the LEFT or RIGHT button.
COLOR:
Select the color of masking from GRN, MAG, RED, BLUE, BLK, WHT, YEL,
and CYN using the LEFT or RIGHT button.
Select BACK LIGHT using the UP or DOWN button and enter using SEL button.
You can select one sub-mode from BACK LIGHT, ACE, and ECLIPSE using the UP or DOWN button.
Enable/Disable ECLIPSE, selecting from OFF or ON using the LEFT or RIGHT button.
BACK LIGHT
BACK LIGHT
ACE
ECLIPSE
RETURN
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
MANUAL
AUTO
OFF
ON
ON
SPOT
OFF
ON
BACK LIGHT
LEVEL
COLOR
RETURN
11
CYN
10
Select DAY / NIGHT using the UP or DOWN button.
You can select one sub-mode from AUTO, COLOR, and NIGHT using the UP or DOWN button.
DAY / NIGHT AUTO, COLOR, NIGHT
Select the AUTO mode using the LEFT or RIGHT button and enter into sub-menu using SEL button.
AUTO: The camera will stay in DAY in a normal environment, but will switch
to NIGHT mode when ambient illumination falls below this pre-set level.
ICR(IR Cut) filter is removed when it switches to Black/White.
ANTI-SAT.: Adjust the anti-saturation level manually.
This feature will reduce the saturation in which part of the
camera receiving the light affected by the IR or light in Night mode.
If the saturation is reduced the surroundings will be darker.
AGC LEVEL
:
Set the level of threshold for switching day to night. This level is same
as the exposure gain level.
AGC MARGIN: Set the margin between Day →Night switching level and Night →Day
switching level.
DWELL TIME: Select the dwell time between
Day →Night and Night →Day
change.
DAY / NIGHT
ANTI-SAT.
AGC LEVEL
AGC MARGIN
DWELL TIME
RETURN
MENU
LENS
WB CONTROL
AE CONTROL
BACK LIGHT
DAY / NIGHT
IMAGE STABILIZER
AUDIO MIC
IMAGE CONTROL
DISPLAY CONTROL
RESET
EXIT
ESC
MANUAL
AUTO
OFF
ON
ON
10
10
16
5
COLOR: The camera keeps color mode constantly.
NIGHT: The camera keeps Black/White mode constantly.
