Marshall Amplification MB450H Manuel utilisateur

Bass Amplification

Marshall is proud to present their outstanding new two channel MB Bass Series. Designed from the ground

up, these rugged amps and cabinets house incredible tone and a host of professional features.

The Marshall R&D team has worked relentlessly to produce a bass range that truly captures the essence of

the Marshall sound. Scoping the entire bass playing spectrum from beginner to professional, the MB Series

delivers everything from gain, worthy of the greatest rock player, to the purest crystal clean tones.

The clean thump of the

Modern channel and

the dirty roar of the

Classic channel, every

MB amp features two

channels.

Taking the sound of

the Classic channel

even further, the

MB60 and above use

an ECC83 pre-amp

valve to provide the

best possible tone.

The footswitchable

Blend allows you to

punch in your own

unique mix of both

channels, creating a

third hybrid sound

tailored to meet your

needs.

The flexible Voice Shift

provides three different

settings, shaping your

EQ from the classic

tone of vintage bass

through to an in-your-

face aggression.

AVariable Compressor

smoothes your sound

into a solid wall of low

frequencies while the

additional Limiter

prevents power amp

clipping.

Custom metal grills and

corners encapsulate

these r gged cabinets.

With a build that

matches its sound, the

MB Series is up for the

toughest of gigs.

Three extension

cabinets give you the

choice to create your

perfect set-up,

unlocking the full

power housed within.

MB15

t may be the smallest in the range, but the

MB15’s 1x8" speaker still packs a punch. Loaded

with pro features: two channels, Variable

Compressor, Emulated Line Out and Headphones

socket, ensures that this is not only the best

entry-level bass amp on the market, but is also

perfect to warm up with before a gig.

MB30

Taking the budding bass player a step further to hitting the

stage with aggression and growl, the MB30 combo is ready

to take on the competition with its 30 Watts (RMS) of power

and 1x10" speaker. Three position EQ Voice Shift, FX Loop

and footswitchable channels add to an already impressive

package.

MB4210

An amp with a monstrous sound that will still fit in your car at the end of the night.

The additional Blend Control straddles the channel divide and provides an extra level

of footswitchable tone control, while the combined Speakon & jack sockets complete

this totally professional package.

MB60

With a valve pre-amp at the heart of its Classic channel this 1x12" combo

packs a mighty bottom-end punch, making it ideal for the small gig or

rehearsal room. Dedicated channel EQ and the addition of a Gain Boost

switch further adds to your sonic arsenal.

MB15 0

Show them you mean business with 150 Watts (RMS) of sheer bass

power behind you. Housing a 1x15" speaker, this combo offers the tone,

features and versatility required by any professional bass player.

MB450H

Don’t be fooled, even in this compact form the MB450H houses a mass of power and

the full line up of MB professional features. ncredible tone and feel waits inside, choose

your combination of cabinets and unlock its full 450 Watts (RMS) of potential.

MB4410

For those wanting to leave a lasting impression, this top of the range combo

channels its immense power through 4x10" speakers and HF horn, leaving no

doubt to your presence. Totally professional, the MB4410 does not compromise.

MB cabinets

We listened to many bass players to provide you with the

most favoured extension cabinets — the MBC115 1x15",

MBC410 4x10" and the colossal MBC810 8x10".

Ruggedly built and ready for life on the road, these

cabinets compliment your choice of combo or head

perfectly.

MBC810

MBC410

MBC115

For more information about the MB Series and other Marshall products contact: Marshall Amplification plc, Denbigh Road, Bletchley, Milton Keynes MK1 1DQ.

Visit the official Marshall website: www.marshallamps.com or www.myspace.com/marshall_amps

Whilst the information contained herein is correct at time of publication, due to our policy of constant improvement and development, Marshall Amplification plc reserve the right to alter specifications without prior notice.

CATS-00113

Amplifier Feat res MB15 MB30 MB60 MB150

Power (RMS) 15 Watt 30 Watt 60 Watt 150 Watt

Speaker Configuration 1 x 8" 1 x 10" 1 x 12" 1 x 15"

HF Horn No No 

Limiter 

D Lineout Emulated Jack Emulated Jack XLR (Pre & Post) XLR (Pre & Post)

FX Loop No 

2 Channels 

Compressor 

ECC83 Preamp Valve No No 

Classic Boost No No 

Mid Voices 1333

Footswitch No 1 Way (optional) 1 Way (included) 1 Way (included)

Dimensions (mm) 390 x 380 x 240 440 x 410 x 260 535 x 505 x 325 580 x 585 x 355

Weight (kg) 12 14.8 23 30

Cabinet Feat res MBC115 MBC410 MBC810

Cabinet Type Bass Reflex Bass Reflex Bass Reflex

Speaker Configuration 1 x 15" 4 x 10" 8 x 10"

HF Horn 

HF Horn Switch 

mpedance 4 Ohms 4 Ohms 4 Ohms

Power (RMS) 300 Watt 600 Watt 1200 Watt

Power (Program) 600 Watt 1200 Watt 2400 Watt

Speakon Connector 111

Jack Connector 111

Dimensions (mm) 630 x 635 x 410 630 x 720 x 410 630 x 1250 x 410

Weight (kg) 32 42.5 70

Specification Tables

Amplifier Feat res MB4210 MB4410 MB450H

Power (RMS) @ 4 Ohms 300 Watt 300 Watt 300 Watt

Power (RMS) @ 2 Ohms 450 Watt* 450 Watt* 450 Watt

Speaker Configuration 2 x 10" 4 x 10" n/a

HF Horn n/a

Speakon Connector 222

Jack Speaker Connector 222

Limiter 

D Lineout XLR (Pre & Post) XLR (Pre & Post) XLR (Pre & Post)

FX Loop 

2 Channels 

Blend Control 

Compressor 

ECC83 Preamp Valve 

Classic Boost 

Mid Voices 333

Master Volume 

Footswitch 2 Way (included) 2 Way (included) 2 Way (included)

Dimensions (mm) 630 x 535 x 280 630 x 720 x 410 630 x 220 x 235

Weight (kg) 33 51 15

*with extension cabinet
