COMPACT MULTI-APARTMENT GSM DOOR ENTRY UNIT
USER MANUAL
SOLO-KP (LCD)
USER MANUAL
Page 1
Contents
1FOR YOUR SAFETY.............................................................................................................................................3
2INTRODUCTION...................................................................................................................................................4
3SOLO-KP (LCD)-LCD, SOLO-KP (LCD)-40 FEATURES AND APPLICATIONS.......................................5
4START UP...............................................................................................................................................................6
5LED INDICATION.................................................................................................................................................7
6CONNECTION DIAGRAM ..................................................................................................................................8
7SOLO-KP (LCD) MANAGEMENT......................................................................................................................9
8SOLO-KP (LCD) FUNCTIONS WITH PROGRAMMING INSTRUCTIONS..............................................10
8.1 WEB SERVER - LOG IN..................................................................................................................................................10
8.2 WEB SERVER –ADDING UNITS TO USER PROFILE................................................................................................11
8.3 WEB SERVER-UNIT MANAGEMENT ..........................................................................................................................13
8.4 INTERCOM CONFIGURATION .....................................................................................................................................14
8.5 KEYPAD PIN ENTRY –ACCESS...................................................................................................................................16
8.6 WIEGAND ACCESS.........................................................................................................................................................17
8.7 CALLER ID ACCESS.......................................................................................................................................................20
8.8 OUTPUTS SETTINGS......................................................................................................................................................21
8.9 SOLO-KP (LCD) WIEGAND OUTPUT INTEGRATION...............................................................................................23
8.10 TIMER-TIMED CONTROLLED OUTPUT .....................................................................................................................24
8.11 SERVICE BUTTON..........................................................................................................................................................26
8.12 ADMINISTRATION.........................................................................................................................................................28
8.13 EVENT LOGING ..............................................................................................................................................................30
8.14 MISCELLANEOUS ..........................................................................................................................................................31
9CONTACTS ..........................................................................................................................................................32
SOLO-KP (LCD)
USER MANUAL
Page 2
Figures
Figure 1: SOLO-KP (LCD) Connection diagram................................................................................8
Figure 2: WEB Server-Sign In page..................................................................................................10
Figure 3: WEB Server-Main page select ADD mode........................................................................11
Figure 4: WEB Server-Main page adding SOLO-KP (LCD) units...................................................12
Figure 5: WEB Server-Unit management window............................................................................13
Figure 6: WEB Server-Intercom settings...........................................................................................14
Figure 7: WEB Server-Keypad PIN Access: Permanent PIN codes. ................................................16
Figure 8: WEB Server-Keypad PIN Access: Temporary PIN codes.................................................16
Figure 9: WEB Server-Wiegand interface support............................................................................17
Figure 10: WEB Server-Adding Wiegand devices with permanent use............................................18
Figure 11: WEB Server-Adding Wiegand devices with temporary use............................................19
Figure 12: WEB Server-Caller ID Access.........................................................................................20
Figure 13: WEB Server-Output setting..............................................................................................21
Figure 14: WEB Server-Wiegand Output settings.............................................................................23
Figure 15: WEB Server-Timer setting →Day mode. ........................................................................24
Figure 16: WEB Server-Timer setting →Week mode.......................................................................24
Figure 17: WEB Server-Service button settings (Call mode)............................................................26
Figure 18: WEB Server-Service button settings (Direct access).......................................................27
Figure 19: WEB Server-Notification numbers. .................................................................................28
Figure 20: WEB Server-Input alarm configuration. ..........................................................................28
Figure 21: WEB Server-Log events...................................................................................................30
Figure 22: WEB Server-Misc. ...........................................................................................................31
SOLO-KP (LCD)
USER MANUAL
Page 3
1FOR YOUR SAFETY
SWITCH ON SAFELY
Do not switch the unit on when use of wireless phone is prohibited or when it may cause
interference or danger.
INTERFERENCE
All wireless phones and units may be susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the unit off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the unit at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the unit where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the
antenna unnecessarily.
SOLO-KP (LCD)
USER MANUAL
Page 4
2INTRODUCTION
SOLO-KP (SOLO-KP LCD) is a simple but powerful GSM intercom communication system
designed to ensure low-cost, simple to install/use, reliable and single box solution for intercom
application. It is designed for unlimited range, wire free GSM intercom, pin code access, caller ID
control and Wiegand access support.
SOLO-KP and SOLO-KP LCD units are built for multi-apartment solutions.
Optional SOLO-KP (LCD) supports alarm detection, stay-alive messages, credit detection etc…
SOLO-KP (LCD)
USER MANUAL
Page 5
3SOLO-KP (LCD)-LCD, SOLO-KP (LCD)-40 FEATURES
and APPLICATIONS
Features:
Built-in 4 (2G) or 5 (3G) band GSM module
Keypad call support (up-to 200 or 1000 apartments)
LCD screen for user called (only valid in SOLO-KP LCD)
Keypad Access entry support (up-to 2000 PIN codes)
Caller ID numbers control (up-to 500 or 2100 caller ID numbers)
Up to 100 temporary SPIN access codes
Input Wiegand receiver (up-to 2000 receivers)
2 outputs (relay supported)
Programming with PC via “USB to Mini USB cable” connected to the unit
Programming by SMS commands
Programming by WEB server
Applications:
Single box, wire free intercom solution
Remote gate opener –Caller ID number recognition
Simple (Wiegand) access system
IMPORTANT
Major difference between SOLO-KP and SOLO-KP LCD is
absence of LCD screen in SOLO-KP unit
SOLO-KP (LCD)
USER MANUAL
Page 6
4START UP
SOLO-KP (LCD) unit accepts a standard GSM SIM cards from any network.
VERY
IMPORTANT
USE A MICRO SIM CARD
WARNING
DO NOT Insert or remove the SIM card while the unit is powered ON!!
IMPORTANT
Before inserting SIM card to unit make sure the PIN code is
removed!!
Insert SIM card in SOLO-KP (LCD) unit.
Connect power cable to SOLO-KP (LCD) unit (YOU MUST POWER THE SOLO-KP
(LCD) UNIT WITH THE POWER SUPPLY INCLUDED. Do not power with any other
power supply.
Power up the unit.
Wait until LED1 (Blue) starts flashing. This is set in around 30 –45 seconds.
SOLO-KP (LCD) unit is now ready to operate.
NOTE
SOLO-KP (LCD) will “beep” in 15s intervals until the unit reaches normal operation.
SOLO-KP (LCD)
USER MANUAL
Page 7
5LED INDICATION
Blue LED (LED1)
-Indicates the level of the GSM signal from 1 to 5 LED flashes (1 is weak signal, 5 is
excellent signal)
Red LED (LED2)
-GSM module Activity
Yellow LED (LED3)
-Short flashing indicates that the GSM module is ON, but it is not yet connected on the GSM
network. After connection, yellow led is flashing with short pulse (0,5s) ON and a long
pulse OFF (5s).
SOLO-KP (LCD)
USER MANUAL
Page 8
6CONNECTION DIAGRAM
Before connection the SOLO-KP (LCD) please take a look at connection diagram.
Figure 1: SOLO-KP (LCD) Connection diagram.
IMPORTANT
DO NOT USE Power out (12V AUX) for electric lock driving! Use
separatepowersource fordoor electriclock!
SOLO-KP (LCD)
USER MANUAL
Page 9
7SOLO-KP (LCD) MANAGEMENT
Unit supports different types of management (programming):
Unit can be programmed directly by USB connection, with the use of configuration software
running on PC (EasySet).
Unit can be programmed remotely by using WEB server access.
Unit can be programmed remotely by SMS commands (Optional).
