SOLO–KP
SOLO–KP LCD
COMPACT MULTI-APARTMENT GSM DOOR ENTRY UNIT
INSTALLATION MANUAL
Version: SOLO-KP SOLO-KP LCD EXT-Installation-Manual_V5_0 18012017.doc
Valid from SW release “SOLO_KP_EF_B_ON_PCK_20161022_v_3_3_1”.
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 2
Contents
1FOR YOUR SAFETY.............................................................................................................................................5
2INTRODUCTION...................................................................................................................................................6
3FEATURES AND APPLICATIONS.....................................................................................................................7
4START UP...............................................................................................................................................................8
5LED DISPLAY........................................................................................................................................................9
6CLEAR ALL PROGRAMMED DATA FROM SOLO-KP..............................................................................10
7CONNECTING DIAGRAM ................................................................................................................................11
8PROGRAMMING SOLO-KP .............................................................................................................................12
9THE SOLO-KP PARAMETERS.........................................................................................................................13
9.1 ALARM SUPPORT...........................................................................................................................................................13
9.2 OUTPUT MANAGEMENT ..............................................................................................................................................17
9.3 SECURITY LEVEL - SL...................................................................................................................................................19
9.4 PREPAID CARD CREDIT AND VALIDITY INFORMATION......................................................................................20
9.5 SET-UP PARAMETERS...................................................................................................................................................22
9.6 SMS MESSAGES EDITOR ..............................................................................................................................................25
9.7 INTERCOM.......................................................................................................................................................................26
9.8 TRADE BUTTON (OPTION)...........................................................................................................................................27
9.9 DIRECT ACCESS BY ENTERING PIN CODE...............................................................................................................28
9.10 DIRECT ACCESS BY ENTERING TEMPORARY ACCESS CODES –SPIN - VIA ILLUMINATED KEYPAD.......29
9.11 CALLER ID RECOGNITION (CLIP), CALLER-IN FUNCTION...................................................................................31
9.12 EVENT LOGING ..............................................................................................................................................................32
9.13 SPECIAL SMS COMMANDS ..........................................................................................................................................33
10 PRINT-OUT OF THE PARAMETERS..............................................................................................................35
10.1 RECEIVE ALL PARAMETERS (PALL) .........................................................................................................................35
10.2 CHECK SW REVISION (PSW)........................................................................................................................................35
10.3 CHECK SIGNAL QUALITY (PSQ) .................................................................................................................................35
10.4RECEIVE TELEPHONE NUMBERS (PTN)....................................................................................................................35
10.5 RECEIVE LINKS (PLN)...................................................................................................................................................35
10.6 RECEIVE INPUT PARAMETERS (PIN).........................................................................................................................35
10.7 RECEIVE INPUT FILTER VALUE (PID) .......................................................................................................................35
10.8 RECEIVE OUTPUT FILTER VALUE (POD)..................................................................................................................36
10.9 RECEIVE DELAY BEFORE DIAL VALUE (PDD)........................................................................................................36
10.10 RECEIVE ACCESS TELEPHONE NUMBERS (PSL).....................................................................................................36
10.11 RECEIVE OUTPUT PARAMETERS (POS) ....................................................................................................................36
10.12 RECEIVE ALL PROGRAMMED SMS MESSAGES (P#) ..............................................................................................36
10.13 RECEIVE SET UP PARAMETERS VALUE (PPA) ........................................................................................................36
10.14 RECEIVE CREDIT PARS PARAMETERS (PCREF)......................................................................................................36
10.15 RECEIVE ALL CLIP PARAMETERS (PCLP) ................................................................................................................37
10.16 RECEIVE INTERCOM CALL GROUPS PARAMATERS............................................................................................37
10.17 RECEIVE TRADE BUTTON PARAMETERS ................................................................................................................37
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 3
10.18 RECEIVE PIN ACCESS CODES (PPIN) .........................................................................................................................37
10.19 RECEIVE SPIN ACCESS CODES PARAMETERS (PSPIN)..........................................................................................38
10.20 STATE OF THE CREDIT FOR THE PREPAID CARD ..................................................................................................38
10.21 STATE OF THE OUTPUTS (PORC)................................................................................................................................38
10.22 MANUAL GSM MODULE RETARD (MRES)................................................................................................................38
10.23 RECEIVE STATUS OF INPUTS (INS)............................................................................................................................38
10.24 RECEIVE SOLO-KP LOG................................................................................................................................................38
11 CHANGING PARAMETERS USING THE SMS COMMANDS....................................................................39
12 DEFAULT SETTINGS ON SOLO-KP...............................................................................................................40
13 PARAMETERS PRINT-OUT COMMANDS....................................................................................................42
14 TECHNICAL SPECIFICATIONS......................................................................................................................43
15 CONTACTS ..........................................................................................................................................................44
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 4
Figures
Figure 1: SOLO-KP Connection diagram..........................................................................................11
Figure 2: Input Connection diagram..................................................................................................13
Figure 3: Output Connection diagram ...............................................................................................17
Tables
Table 1: IN, ID and DD parameters...................................................................................................14
Table 2: IN, ID, DD parameters example..........................................................................................14
Table 3: Remote alarm reporting parameters.....................................................................................15
Table 4: Remote alarm reporting example........................................................................................16
Table 5: DTMF control example .......................................................................................................16
Table 6: Output management parameters ..........................................................................................18
Table 7: Output management parameters example............................................................................18
Table 8: SL parameter........................................................................................................................19
Table 9: SL parameter example.........................................................................................................19
Table 10: Prepaid card validity parameters........................................................................................21
Table 11: Prepaid card validity parameters example.........................................................................21
Table 12: Set-up parameters. .............................................................................................................24
Table 13: Set-up parameters example................................................................................................24
Table 14: Message parameters...........................................................................................................25
Table 15: Message parameters example. ...........................................................................................25
Table 16: Intercom parameters. .........................................................................................................26
Table 17: Intercom parameters example............................................................................................27
Table 18: Trade button parameters. ...................................................................................................28
Table 19: Trade button example. .......................................................................................................28
Table 20: Entering PIN code parameters...........................................................................................29
Table 21: Entering PIN code example...............................................................................................29
Table 22: Entering SPIN access code parameters..............................................................................30
Table 23: Entering SPIN access codes example................................................................................30
Table 24: CLIP parameters................................................................................................................31
Table 25: CLIP parameters example..................................................................................................32
Table 26: LOG parameters.................................................................................................................33
Table 27: LOG parameters example..................................................................................................33
Table 28: SMS commands.................................................................................................................34
Table 29: SMS commands example...................................................................................................34
Table 30: SOLO-KP default settings.................................................................................................41
Table 31: SOLO-KP parameters print out commands.......................................................................42
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 5
1FOR YOUR SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete
user guide for further information.
SWITCH ON SAFELY
Do not switch the unit on when use of wireless phone is prohibited or when it may cause
interference or danger.
INTERFERENCE
All wireless phones and units may be susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the unit off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the unit at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the unit where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the
antenna unnecessarily.
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 6
2INTRODUCTION
SOLO-KP is a simple GSM intercom communication system for multi apartments, that is designed
to ensure low-cost, reliable and single box solution for intercom application. It is designed for
unlimited range, wire free GSM intercom and CLIP support.
In addition SOLO-KP supports alarm detection, stay-alive messages, credit detection etc…
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 7
3FEATURES AND APPLICATIONS
Features:
Built-in 4 band (2G) or 5 band (3G) GSM module
Keypad call support (up-to 200 apartments)
Keypad Access entry support (by 4 digit PIN codes –up to 2000 codes are possible)
Up to 100 temporary SPIN access codes
2 alarm inputs
2 outputs (relay supported)
Up to 500 telephone numbers for CLIP support (400 + 100)
Programming by USB cable with PC –with Easyset SW on PC
Programming by text commands (SMS commands)
Programming by Web server
Anti-tampering input
Applications:
Single box, wire free intercom solution
Remote gate opener –Caller ID recognition (CLIP)
Simple alarm support
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 8
4START UP
VERY
IMPORTANT
USE A MICRO SIM CARD (micro-SIM, see the picture)
WITH MEMORY FOR UP TO 250 CONTACTS!
Insert SIM card to be used for SOLO-KP in your personal mobile phone.
IMPORTANT
ERASE THE PIN CODE!
Insert SIM card in SOLO-KP device. The unit must be switched OFF when you insert the
SIM!
Connect inputs and outputs to SOLO-KP.
Connect the antenna to antenna connector.
Connect power cable to SOLO-KP device
Connect device to source power supply voltage.
Wait until LED3 display is turned ON (Yellow) and LED1 (Blue) starts flashing. This is set
in around 30 –45 seconds.
SOLO-KP unit is now ready to operate.
IMPORTANT
Before sending any SMS commands to SOLO-KP, the device must be in
normal operation mode!
NOTE
SOLO-KP device will “beep” in 15s interval until the device is not in normal
operation.
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 9
5LED DISPLAY
BLUE LED (LED1)
-Indicates the level of the GSM signal from 1 to 5 LED flashes (1 is weak signal, 5 is
excellent signal)
RED LED (LED2)
-When LED 2 is ON the unit has a problem with a GSM network connection or the GSM
part of the unit is out of order. In this case immediately call the service!
YELLOW LED (LED3)
-Short flashing indicates that the GSM module is ON, but it is not yet connected on the GSM
network. After connection, Yellow LED is flashing with short pulse ON and a long pulse
OFF.
SOLO-KP (LCD)
INSTALLATION MANUAL
Page 10
6CLEAR ALL PROGRAMMED DATA FROM SOLO-KP
This is highly recommended when a SIM card you are going to use for the SOLO-KP is not new
and it already has some data stored in the phone book memory.
By sending this SMS to SOLO-KP all programmed parameters and numbers are cleared:
;SDCLR;
After sending SMS you should wait at least 30 second for the command to be executed!
NOTE
By sending this command to the SOLO-KP all programmed data are erased from the
SIM card and from the memory inside the SOLO-KP device!
