Construction and maintenance of APS system in telescopic lance
Telescopic lance is a piece of equipment of sprayer VX, with the folded length of 60cm, and after
ejection of the inside lance it extends to 108 cm.
To get the correct length of the lance, loosen the sleeve R103, pull out the inside lance "A" to the
desired length and then tighten the sleeve so that the lance could not fold again.
Telescopic lance is provided with a special antidust system APS. The system protects the
telescopic lance system against contamination.
In order to maintain the system, unscrew the sleeve and take out the inside lance pipe by pulling it
out. Lubricate with silicone grease all the elements on the inside lance pipe 'A”: R106, R107, R108
and R109. When it’s done, put back the pipe 'A” inside the outer lance pipe ”B” and screw in the
Construction and maintenance of the feeding valve
integrated with handle
Feeding valve integrated with handle consists of many elements which ensure proper operation of
the sprayer. Its main advantages are:
Ergonomic design fitted to the shape of the hand
Comfortable to use trigger button
A
dditional filter inside the lance giving protection against polluting GB
Two systems of work - intermittent and continuous
Two systems of work give us the ability to work:
Intermittent - the possibility of a temporary spray obtained by pressing the trigger
button R44. The moment the button is released the spraying stops.
Continuous - possibility of continuous spraying without necessity of pressing the trigger
button R44 during spraying. It is obtained by pressing and moving forward the trigger button R44
till it is blocked. To unblock the button, press it and move backward until the brass element is at
the end of the button hole.
Maintenance is described in the section "Equipment maintenance"
