MARELUX SOFT Lite Manuel utilisateur
2
Contents
Package Contents ------------------------------------------ 3
Product Features ------------------------------------------ 4
ldentification of Parts ------------------------------------------ 5
Battery Installation ------------------------------------- 6
Dock Installation
⚫ AOI UCS-Q1 ------------------------------------------- 7
⚫ IKelite DS-160 --------------------------------------------- 8
⚫ INON S2000 ------------------------------------------ 9
⚫ INON Z240 ------------------------------------------ 10
⚫ INON Z330 ------------------------------------------ 11
⚫ Retra ----------------------------------------------- 12
⚫ Sea & Sea YS-D3 --------------------------------------- 13
⚫ Sea & Sea YS-D2 --------------------------------------- 14
⚫ Seacam 150/160 ------------------------------------------ 15
SOFT Lite Installation ------------------------------------------- 16
Usage -------------------------------------------------- 17
Warranty ---------------------------------------------- 18
Maintenance And Storage -------------------------------------- 19
3
Package Contents
SOFT Lite Main Body
Mounting Ball * 1 Allen Wrench * 1
Oring * 2
（one thick and the other thin）
protective cover * 1
Screw *2
4
Product Features
Use with strobe to narrow down the beam coverage
Length : 155mm
Weight : 600g (on land) Neutral buoyancy underwater.
Depth Rating : -100m
Focal Length (Underwater)：130mm
Beam Spot Adjustment Range：3~50mm
Beam light switchable between white and red colors with adjustable luminance
（SOFT-LITE XR/XW only has single-color light）and adjustable delay shutoff
time of beam light.
Use one 21700 Lithium battery which can support 6 hours of continuous use.
(You can use 18650 battery by using a battery adapter)
5
Identification of Parts
(1) Power Switch
(2) Beam Spot Adjustment Knob
（1）
（2）
6
Battery Installation
This product requires one
21700 Lithium battery
Remove the battery end cap by
rotating it counter clockwise
then insert the battery in the
direction shown in the figure.
Attach the battery end cap by rotating it clockwise.
7
Dock Installation
AOI UCS-Q1
（1） （2）
Align the bulge (1) of [the dock for
AOI UCS-Q1 ] to the slot (2) of the
strobe.
Tighten the screw to secure
the dock onto the strobe.
8
IKelite DS-160
(1）
Remove the shroud (1) from
the strobe then attach the ring
and the dock to the strobe.
Tighten the screw to secure
the dock onto the strobe.
9
INON S2000
（2）
（1）
Align the bulge(1) of
[the dock for INON
S2000 ] to the slot(2)
of the strobe.
（2）
（1）
Tighten the screw to
secure the dock onto
the strobe.
10
INON Z240
（2）
（1）
Tighten the screw to secure the
dock onto the strobe.
Attach the dock to the strobe so
that the notch(1) of the dock aligns
to the gear(2) of the strobe.
