Marantz SR-7001 Manuel utilisateur

The SR7001 features THX Select2 certification and 110 watts of continuous power per channel (yes, 110 watts from each of its seven

current-feedback amplifiers!). You can connect up to four HDMI equipped sources to the SR7001. The SR7001 comes complete with format

conversion which lets you watch older videos through the super-convenient HDMI format, and there’s also a Second Zone audio/video

output. You’ll also find Dolby Virtual Speaker so you can enjoy an immersive surround experience with the dialog clarity inherent in a

discrete center channel configuration with just two speakers. The SR7001 features Audyssey’s remarkable Auto Calibration that examines

your entire room to corrects for the acoustical problems that sometimes make those other seats (and you know which ones we mean, don’t

you?) just as rewarding as the ones directly in front of your display device’s screen. The SR7001 has an infrared input and two DC trigger

outputs so you can coordinate your entire system for convenient remote operation. We’ve housed the SR7001 in a new, compact chassis,

( less than 16”) that will fit more easily into even the tightest spaces. The SR7001 also comes with our industry leading three year warranty.

• 110 watts (into 8 ohms) x 7 ch Amps

• THX Select2 certification

• All discrete “Current Feedback” amplifier stages

• HDMI (V1.2) Repeating: 4-In / 1-Out

• 32bit DSP

• XM Ready with discrete IR commands

• Dolby Digital EX, Pro Logic IIx (Movie/Music/Game),

• DTS 96/24, ES (Discrete 6.1/Matrix6.1), Neo:6 (Cinema/Music)

• SRS Circle surround II

• Audyssey Auto Calibration

• Up-Conversion (w/TBC) to HDMI with 480I/480P converter

• Dual Component Video outputs

• 192 kHz/24-bit D/A converters for all channels

• HDCD® Decoder

• Dielectric Protected Binding Posts

• Speaker A/B switching

• 2nd Zone A/V output (Individual source) w/discrete commands

• Dolby Headphone

• Lip sync. control

• Assignable HD compatible component video

switching (4 in / 2 out)

• RS-232C terminal for system control

• Direct IR Flasher Input

• x2 DC Trigger outputs

• D-BUS (RC-5 In/Out) remote connection

• Front panel A/V/Optical inputs

• Learning/pre-programmed backlit remote with LCD

• 1 switched and 1 un-switched AC convenience outlets

• New shallow chassis < 16”

• Three year limited warranty

SR7001

THX SELECT2 SURROUND SOUND A/V RECEIVER

Life AmplifiedTM

Compatible

SR7001

*All specifications, dimensions and weights are subject to change without notice.

D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors

being made by retail dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.

IN/OUTPUTS (continued)

OTHER

Pre-Amplifier Out

Main Amplifier In

Multi-Channel In

Multi-Room Audio Out

Multi-Room Video Out

Multi-Room Speaker Out

Speaker A/B

External control (RS232C)

DC Triggers

D-Bus Remote (RC-5) In/Out

External IR In/Out

Front Panel A/V Inputs

Headphone Out

AC Outlets (Switched/Unswitched)

SPECIFICATIONS

AUDIO SECTION

Power Output (8 Ohm)

S/N Ratio

Freq. Response (Analog In)

Freq. Response (Dig In)

TUNER SECTION FM

Frequency Range

S/N Ratio (Mono/Stereo)

TUNER SECTION AM

Frequency Range

S/N Ratio

VIDEO SECTION

Video Freq. Response (Component)

Video Freq. Response (Composite, S-Video)

Signal to Noise

GENERAL

Color

Front Panel

Remote Control

Power Requirement

Power Consumption

Dimensions W" x H" x D" (Inches)

Weight (lbs)

FEATURES

MULTICHANNEL/SURROUND

Number of Channels

THX

DTS (ES, Discrete 6.1/ Matrix 6,1, Neo-6)

Dolby Digital EX

Dolby Pro Logic IIx

Circle Surround II

SOUND ENHANCEMENTS

HDCD Decoder

Current Feedback Topology

Discrete Amplification

Power Transformer

D/A Conversion

Digital Signal Processing

Video Off

Source Direct

Chassis

Variable X-over

Display Off

Video Up-conversion

Auto Calibration

XM-Ready

AM/FM tuner

Bass management

Lip-sync (digital audio delay)

Software Upgradable (RS232)

IN/OUTPUTS

VIDEO

HDMI In

Component In

S-Video In

Composite In

HDMI Out

Component Out

S-Video Out

Composite Out

AUDIO

Analog L&R In

Analog L&R Out

Digital Optical In

Digital Coaxial In

Digital Optical Out

Digital Coaxial Out

IEEE1394 connection

Select 2

•(+ 96/24)

•

•(All 7ch)

192kHz/24-Bit

TI 32-Bit

•

Metal

•

Up to HDMI (w/ TBC)

•(Audyssey MultiEQ)

•

4 (Assignable Inputs)

8ch

•

•(Composite)

•

2/2

1/0

•(+ Digital Opt.)

•(Dolby Headphone)

1/1

110W x 7

105db

8Hz - 100kHz (+/- 3 dB)

8Hz - 45kHz (+/- 3 dB)

87.5 - 108.0MHz

Mono/Stereo: 75/70 dB

520 - 1710kHz

50 dB

5Hz - 80MHz (- 1 dB)

5Hz - 8MHz (- 1 dB)

60dB

Black

Aluminum

Learning/Pre-coded with LCD RC8001SR

AC 120V/60Hz

750w

17 5/16" x 7 1/4" x 15 5/8"

33.1
