AV Surround Receiver

SR5015

Owner’s Manual

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 8

Inserting the batteries 9

Operating range of the remote control unit 9

Features 10

High quality sound 10

High performance 11

Easy operation 15

Part names and functions 16

Front panel 16

Display 19

Rear panel 21

Remote control unit 25

Connections

Speaker installation 29

Connecting speakers 36

Before connecting speakers 36

Speaker configuration and “Amp Assign” settings 40

Connecting 5.1-channel speakers 41

Connecting 7.1-channel speakers 42

Connecting 5.1-channel speakers: Bi-amp connection of front

speaker 48

Connecting 5.1-channel speakers: Second pair of front speaker 49

Connecting multi-zone speakers 50

Connecting a TV 52

Connection 1 : TV equipped with an HDMI connector and

compatible with the ARC (Audio Return Channel) / eARC

(Enhanced Audio Return Channel) 53

Connection 2 : TV equipped with an HDMI connector and

incompatible with the ARC (Audio Return Channel) / eARC

(Enhanced Audio Return Channel) 54

Connection 3 : TV equipped without an HDMI connector 55

Connecting a playback device 56

Connecting a set-top box (Satellite tuner/cable TV) 57

Connecting a DVD player or Blu-ray Disc player 58

Connecting a player device compatible with the 8K 59

Connecting a video camcorder or game console 60

Connecting a turntable 61

Connecting a USB memory device to the USB port 62

Connecting FM/AM antennas 63

Connecting to a home network (LAN) 65

Wired LAN 65

Wireless LAN 66

Connecting an external control device 67

REMOTE CONTROL jacks 67

DC OUT jack 68

Connecting the power cord 69

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Playback

Basic operation 71

Turning the power on 71

Selecting the input source 71

Adjusting the volume 72

Turning off the sound temporarily (Muting) 72

Playback a DVD player/Blu-ray Disc player 72

Playing a USB memory device 73

Playing files stored on USB memory devices 74

Listening to music on a Bluetooth device 77

Playing music from Bluetooth device 78

Pairing with other Bluetooth devices 79

Reconnecting to this unit from a Bluetooth device 80

Listening to audio on Bluetooth headphones 81

Listening to audio on Bluetooth headphones 82

Reconnecting to a Bluetooth headphones 83

Disconnecting Bluetooth headphones 83

Listening to FM/AM broadcasts 84

Listening to FM/AM broadcasts 85

Tuning in by entering the frequency (Direct Tune) 86

Changing the tune mode (Tune Mode) 87

Tuning in to stations and presetting them automatically (Auto

Preset Memory) 87

Presetting the current broadcast station (Preset Memory) 88

Listening to preset stations 88

Specify a name for the preset broadcast station (Preset Name) 89

Skipping preset broadcast stations (Preset Skip) 90

Cancelling Preset Skip 91

Listening to Internet Radio 92

Listening to Internet Radio 93

Playing back files stored on a PC or NAS 94

Playing back files stored on a PC or NAS 95

Getting the HEOS App 98

HEOS Account 99

Playing from streaming music services 100

Listening to the same music in multiple rooms 103

AirPlay function 107

Playing songs from your iPhone, iPod touch or iPad 108

Playing iTunes music with this unit 108

Play a song from your iPhone, iPod touch or iPad on multiple

synced devices (AirPlay 2) 109

Spotify Connect function 110

Playing Spotify music with this unit 110

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Convenience functions 111

Adding to HEOS Favorites 112

Playing back HEOS Favorites 112

Deleting a HEOS Favorites 113

Adjusting the volume of each channel to match the input source

(Channel Level Adjust) 114

Adjusting the tone (Tone) 115

Displaying your desired video during audio playback (Video

Select) 116

Adjusting the picture quality for your viewing environment (Picture

Mode) 117

Playing the same music in all zones (All Zone Stereo) 118

Changing the speaker settings to match the listening environment

(Speaker Preset) 119

Selecting a sound mode 120

Selecting a sound mode 121

Direct playback 122

Pure Direct playback 122

Auto surround playback 123

Description of sound mode types 124

Sound mode that can be selected for each input signal 128

HDMI Control function 132

Setting procedure 132

Smart Menu function 133

Sleep timer function 135

Using the sleep timer 136

Smart select function 137

Calling up the settings 138

Changing the settings 139

Panel lock function 140

Disabling all key button operations 140

Disabling all button operations except VOLUME 140

Canceling the Panel lock function 141

Remote lock function 142

Disabling the sensor function of the remote control unit 142

Enabling the remote sensor function 142

Web control function 143

Controlling the unit from a web control 143

Playback in ZONE2 (Another room) 145

Connecting ZONE2 145

Playback in ZONE2 147

Settings

Menu map 149

Menu operations 153

Audio 154

Center Level Adjust 154

Subwoofer Level Adjust 154

Surround Parameter 155

M-DAX 158

Audio Delay 159

Volume 160

Audyssey®161

Graphic EQ 163

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Video 165

Picture Adjust 165

HDMI Setup 167

Output Settings 172

On Screen Display 176

Screen Saver 177

4K/8K Signal Format 177

HDCP Setup 179

TV Format 179

Inputs 180

Input Assign 180

Source Rename 183

Hide Sources 183

Source Level 183

Speakers 184

Audyssey® Setup 184

Procedure for speaker settings (Audyssey® Setup) 186

Error messages 192

Retrieving Audyssey® Setup settings 193

Manual Setup 194

Amp Assign 194

Speaker Config. 195

Distances 200

Levels 201

Crossovers 202

Bass 203

Front Speaker 204

Speaker Preset 204

Network 205

Information 205

Connection 205

Wi-Fi Setup 206

Settings 208

Network Control 210

Friendly Name 210

Diagnostics 211

AirPlay 211

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

HEOS Account 212

You have not signed in 212

You have already signed in 212

General 213

Language 213

ECO 213

Bluetooth Transmitter 217

ZONE2 Setup 218

Zone Rename 219

Smart Select Names 219

Trigger Out 220

Front Display 220

Firmware 221

Information 224

Usage Data 226

Save & Load 226

Setup Lock 227

Reset 227

Limiting the operating zone with the remote control 228

Tips

Tips 230

Troubleshooting 232

Power does not turn on / Power is turned off 233

Operations cannot be performed through the remote control unit 234

Display on this unit shows nothing 234

No sound comes out 235

Desired sound does not come out 236

Sound is interrupted or noise occurs 239

No video is shown on the TV 240

The menu screen is not displayed on the TV 242

The color of the menu screen and operations content displayed

on the television is different from normal 242

AirPlay cannot be played back 243

USB memory devices cannot be played back 244

Bluetooth cannot be played back 245

The Internet radio cannot be played back 247

Music files on PC or NAS cannot be played back 248

Various online services cannot be played 249

The HDMI Control function does not work 249

Cannot connect to a wireless LAN network 250

Update/upgrade error messages 251

Resetting factory settings 252

Resetting network settings 253

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Appendix

About HDMI 254

Video conversion function 258

Playing back a USB memory devices 260

Playing back a Bluetooth device 261

Playing back a file saved on a PC or NAS 262

Playing back Internet Radio 263

Personal memory plus function 263

Last function memory 263

Explanation of terms 264

Trademark information 273

Specifications 275

Index 280

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Marantz product.

To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Cable labelsWarranty

(for USA/for CANADA)

Notes on radio

Safety Instructions

Quick Start Guide

Sound calibration

microphone stand

Sound calibration

microphone

AM loop antennaFM indoor antennaPower cord

External antennas for

Bluetooth/wireless

connectivity

R03/AAA batteriesRemote control unit

(RC042SR)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

30°

Approx. 23 ft/7 m

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Features

High quality sound

0Powerful 7-Channel Discrete Amplifier

Featuring discrete high-current power amplifiers on all channels, this

unit delivers 100 W of power per channel (8 Ω/ohms, 20 Hz - 20 kHz,

T.H.D.: 0.08 %, 2ch drive). With low impedance driver capability, it

offers operational stability with a wide range of speakers for balanced,

quality sound.

Auto Eco Mode adjusts power output to speakers based on volume

level and on-screen eco meter, providing power consumption reduction

in real-time without sacrificing superb Marantz sound.

0Current feedback amplifier

This unit uses a high-speed current feedback amplifier circuit for its

preamplifier so that signals from a Blu-ray Disc player and other

equipment that support high-definition audio formats can be amplified

with high fidelity. The high-speed current feedback amplifier also

reproduces a natural sound space.

0Dolby Atmos (v p. 265)

This unit is equipped with a decoder that supports Dolby Atmos audio

format. The placement or movement of sound is accurately reproduced

by the addition of overhead speakers, enabling you to experience an

incredibly natural and realistic surround sound field.

0Speaker Virtualizer (v p. 157)

Speaker Virtualizer enables you to access a more immersive

entertainment experience from traditional channel based speaker

layouts through digital signal processing including Dolby Atmos height

virtualization and surround virtualization.

0Speaker Virtualizer is not for use when both height speakers and surround

speakers are connected.

0Height Virtualization may be applied when surround speakers are connected.

0DTS:X (v p. 268)

This unit is equipped with the DTS:X decoder technology. DTS:X brings

the home theater experience to new heights with its immersive object

based audio technology which removes the bounds of channels. The

flexibility of objects allows for sound to be scaled large or small and

moved around the room with greater accuracy than ever before leading

to a richer immersive audio experience.

0DTS Virtual:X (v p. 268)

DTS Virtual:X technology features DTS’s proprietary virtual height and

virtual surround processing to deliver an immersive sound experience

from any type of input source (stereo to 7.1.4 channel) and speaker

configuration.

0DTS Virtual:X is not for use when Height speakers are connected.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Marantz Récepteur stéréo

Marantz

Marantz SR5008 Manuel utilisateur

Marantz

Marantz 2230B Manuel utilisateur

Marantz

Marantz SR4003 Manuel utilisateur

Marantz

Marantz NR1510 Manuel utilisateur

Marantz

Marantz SR9600U Manuel utilisateur

Marantz

Marantz 541110480028M Guide de configuration

Marantz

Marantz SR5300 Manuel utilisateur

Marantz

Marantz SR6013 Manuel utilisateur

Marantz

Marantz PS3001 Manuel utilisateur

Marantz

Marantz ZR6001 Manuel utilisateur

Marantz

Marantz SR4120 Manuel utilisateur

Marantz

Marantz SR4500 Manuel utilisateur

Marantz

Marantz SR6009/U1B Manuel utilisateur

Marantz

Marantz 2285B Manuel utilisateur

Marantz

Marantz 2285 Manuel utilisateur

Marantz

Marantz SR-4001 Manuel utilisateur

Marantz

Marantz 2250B Manuel utilisateur

Marantz

Marantz SR5200 K2G Manuel utilisateur

Marantz

Marantz SR5011OM Manuel utilisateur

Marantz

Marantz SR6012 Manuel utilisateur

Marantz

Marantz SR6015 Manuel utilisateur

Marantz

Marantz SR-4001 Manuel utilisateur

Marantz

Marantz NR1200 Manuel utilisateur

Marantz

Marantz SR4023 Manuel utilisateur

Manuels Récepteur stéréo populaires d'autres marques

Kenwood

Kenwood KMDX92 Manuel utilisateur

Yamaha

Yamaha RX-830 Manuel utilisateur

Pioneer

Pioneer AVH-Z7250BT Manuel utilisateur

Yamaha

Yamaha RX-750 Manuel utilisateur

Denon

Denon AVR-1311 Manuel utilisateur

Denon

Denon AVR-S760H Manuel utilisateur

Denon

Denon AVR-X7200W Manuel utilisateur

Pioneer

Pioneer SC-LX904 Manuel

Sony

Sony XAV-1500 Manuel utilisateur

Radio Shack

Radio Shack DX-399 Manuel utilisateur

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver Manuel utilisateur

Pioneer

Pioneer SX-1000TA Manuel utilisateur

Yamaha

Yamaha MusicCast TSR-5B3D Manuel utilisateur

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver Manuel utilisateur

Sony

Sony STR-DG500 - Multi Channel Av Receiver Manuel utilisateur

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Manuel utilisateur

Pioneer

Pioneer SX-838 Manuel utilisateur

Sherwood

Sherwood S-2660CP Manuel technique
