Marantz PM5005 Manuel utilisateur

Integrated Amplifier

PM5005

Owner’s Manual

You can print more than one page of a PDF onto a single sheet of paper.

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Features 6

High quality sound 6

High performance 6

Easy operation 7

Part names and functions 8

Front panel 8

Rear panel 10

Remote control unit 11

Connections

Connecting speakers 17

Speaker A/B connection 18

Bi-wiring connection 19

Connecting a playback device 20

Connecting a recording device 21

Connecting devices with remote control connectors 22

Performing operations by RC on this unit without visual contact 22

Remotely connecting Marantz audio devices 22

Connecting the power cord 23

Playback

Turning the power on 25

Selecting the speakers for audio output 26

Selecting the input source 26

Adjusting the volume 26

Turning off the sound temporarily (Muting) 26

Adjusting the tone 26

Playing CDs 27

Recording 28

Contents Connections Playback

Settings

Tips Appendix

Contents

Front panel Rear panel

Remote control

unit

Index

Settings

Setting the Auto Standby mode 30

Turning Auto Standby mode off 30

Turning Auto Standby mode on 30

Setting the remote signal receiving function 31

Disabling the remote signal receiving function of the remote

control unit 31

Enabling the remote signal receiving function of the remote

control unit 31

Setting remote control codes 32

Setting remote control codes for the remote control 33

Setting remote control codes for this unit 33

Tips

Tips 35

Troubleshooting 36

Appendix

Explanation of terms 40

Specifications 41

Index 43

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Thank you for purchasing this Marantz product.

To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide CD-ROM (Owner’s Manual) Safety Instructions

Power cord Remote control unit (RC002PMCD) R03/AAA batteries

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

R03/AAA batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

30°

Approx. 7 m

30°

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Features

High quality sound

0All-discrete current feedback amplifier

This unit uses a high-speed current feedback amplifier circuit for its

preamplifier and power amplifier so that signals from the Super Audio

CD player can be amplified with high fidelity. The high-speed current

feedback amplifier reproduces a natural sound space.

0High-power output

This unit features a slimline body, but comes with a large power supply

unit for dynamic music reproduction with high power.

0High quality audio design

This unit has a high quality audio design such as minimized signal path,

use of high sound quality parts, and large power circuit, which is

possible only in discrete audio components.

0Phono input connectors for connecting turntables

This unit is provided with a phono amplifier so that you can directly

connect a turntable and play records (Only the MM cartridge can be

used). (v p. 20)

0Two-sets of speaker output terminals

In addition to using two sets of speakers (Speakers A and Speakers B),

you can connect to bi-wiring speakers with separate input terminals for

high range and low range. (v p. 19)

The unit adopts screw terminals that can connect thick audio cables.

High performance

0Tone control function

This unit has a tone control function for adjustment of bass (low

frequency) and treble (high frequency) sound to produce your preferred

tone. (v p. 27)

0LOUDNESS function

This unit is provided with a LOUDNESS function that makes it easier to

hear music played back at a low volume level. (v p. 27)

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Easy operation

0Remote control compatible with CD players and network audio

players

The remote control provided with this unit can control Marantz CD

players and network audio players in addition to this unit. (v p. 12)

This unit can also switch between three remote control codes. When

using three units in the same area, you can set a different remote

control code for each unit to control them independently. (v p. 33)

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Part names and functions

Front panel

rteqw y

APower operation button (X)

This turns the power on/off. (v p. 25)

BPower indicator

This is lit as follows according to the power status:

0Power on : Off

0Standby : Red

0Power off : Off

0When the protection circuit is activated : Red (blinking)

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

r t ye

iuQ

CInput source select knob (INPUT SELECTOR)

This selects the input source. (v p. 26)

DInput indicators (v p. 26)

EMUTE indicator

This lights while the sound is muted. (v p. 26)

FVOLUME knob

These adjust the volume level. (v p. 26)

GHeadphones jack (PHONES)

Used to connect headphones.

Turn off speaker output when using headphones. (v p. 26)

NOTE

To prevent hearing loss, do not raise the volume level excessively when using

headphones.

HBASS control knob

This setting adjusts the volume level for the bass. (v p. 26)

ISOURCE DIRECT button/indicator

This turns SOURCE DIRECT mode on/off.

(v p. 27)

JTREBLE control knob

This setting adjusts the volume level for the treble. (v p. 26)

KSpeaker switching buttons/indicators (SPEAKERS A/B)

These select the speaker for audio output. (v p. 26)

LLOUDNESS button/indicator

This turns the LOUDNESS mode on/off.

(v p. 27)

MBALANCE control knob

This adjusts the balance of the volume output from the left and right

speakers. (v p. 26)

NRemote control sensor

This receives signals from the remote control unit. (v p. 5)

8, 0, b and c can be adjusted when 9 is off (SOURCE DIRECT mode is off).

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index

Rear panel

oitre Q

q w

y u

ASIGNAL GND jacks

Used to connect a turntable. (v p. 20)

BAC inlet (AC IN)

Used to connect the power cord. (v p. 23)

CTurntable input connectors (PHONO)

Used to connect a turntable. (v p. 20)

DTuner input connectors (TUNER)

Used to connect a tuner. (v p. 20)

ECD input connectors

Used to connect a CD player. (v p. 20)

FNetwork audio player input connectors (NETWORK)

Used to connect a network audio player.

(v p. 20)

GRecorder input/output connectors (RECORDER 1)

Used to connect the input/output connector of a recorder. (v p. 21)

HRecorder input/output connectors (RECORDER 2)

Used to connect the input/output connector of a recorder. (v p. 21)

ISpeaker terminals (SPEAKERS)

Used to connect speakers. (v p. 17)

JRemote control input/output connectors (REMOTE CONTROL)

Used to connect to a Marantz audio device that is compatible with the

remote control function. (v p. 22)

Contents Connections Playback

Settings

Tips Appendix

Front panel Rear panel

Remote control

unit

Index
