Marantz PM5003 Manuel utilisateur

Looking for Marantz quality in a modestly powered integrated stereo amplifier? The PM5003 may be just

what you need. Great in a starter system for a music aficionado or for a "second system" in summer homes,

dens, or dorms, this gem delivers the sonic excellence Marantz is known for in an attractive, easy-to-use

package. Value priced as a first amp for many with performance that may well make it the last amp for some.

• Sophisticated new aluminum/reinforced resin front panel

• Current feedback amplifier circuit

• Discrete-component amplifier

• Input buffer circuit for High S/N & Ch. Separation

• Source Direct switch

• MM phono input

• Active Filter type Tone Control, Loudness

• 5 line-level inputs

• 2 Record outputs

• Transparent screw-type A/B speaker terminals

• Triple command code sets

• IR flasher input

• Detachable AC cord, Standby Mode

• 2 switched/1 unswitched outlets

• System remote controller

PM5003

Integrated Amplifier

Life AmplifiedTM

PM5003

Integrated Amplifier

Life AmplifiedTM

*All specifications, dimensions and weights are subject to change without notice.

D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors

being made by retail dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.

Flasher In: 1

1/1

2/1

0.01% (20Hz - 20kHz, 8 ohms)

PHONO (MM): 2.2mV/47k ohms, LINE: 200mV/20k ohms

10Hz – 50kHz +0dB, -1dB

PHONO(MM): 83dB (5 mV input), LINE: 87dB (500 mV input) (IHF-A, 1W, 8 ohms)

40W (8 ohms), 55W (4 ohms) (20Hz - 20kHz)

•

Transparent Screw type x2 pair

Bass (100Hz): +/- 10dB, Treble (10kHz): +/- 10dB

•

Black

Aluminum/Glass-reinforced resin

Marantz System Remote Controller

AC120V 60Hz

110W (UL60065)

17 5/16" x 4 1/8" x 14 9/16"

14.8

IN/OUTPUTS

AUDIO

Main In/Pre Out

Bridge Mono Mode/Bi-Amp Mode

Headphone Out

Phono Input

Analog L&R In

Analog L&R Out

OTHER

External control

D-Bus Remote (RC-5) In/Out

AC Outlets (Switched/Unswitched)

SPECIFICATIONS

THD

Input Sensitivity/Impedance

Frequency Response

S/N Ratio

Number of Channels

Output Power

HDAM

Power Transformer

Current Feedback Amplifier

Speaker Terminal

Tone Control

Source Direct

Speaker A/B

GENERAL

Color

Front Panel

Remote Control

Power Requirement

Power Consumption

Dimensions W x H x D (Inches)

Weight (lbs)
