S Model QuietQube®Ice Machines

with CVD®Technology

Installation Training

³Compressor, Condenser,

Accumulator and HPCV are Outside

³Line Set is:

³High Pressure Liquid Line

³Low Pressure Suction Line

³Evaporator, Receiver and Harvest Valve in

Head Section

No Interconnecting Control Wiring!

Overview

Typical QuietQube System

Installation

Model Numbers

This training covers the following models:

CVD1085

SD1072C

SY1074C

CVD2075

SD2072C

SY2074C

CVD1885

SD1872C

SY1874C

CVD1485

SD1472C

SY1474C

CVD1285

SD1272C

SY1274C

CVD0885

SD0872C

SY0874C

CVD0675

SD0672C

SY0674C

CVD Condensing UnitIce Machine Head Section

Important Information

Prior to Installation

WARNING

PERSONNEL INJURY POTENTIAL

Do not operate equipment that has been misused,

abused, neglected, damaged, or altered/modified

from that of original manufactured specifications.

WARNING

Prior to installation make sure that all bin adapters

and ice deflectors

When using a non-Manitowoc ice storage system

with Manitowoc ice machines, contact the

manufacturer to assure their ice deflector is

compatible with Manitowoc ice machines.

³Read Installation, Use & Care Manual

S Model QuietQube ice machines cannot

be stacked.

Failure to follow installation guidelines may

affect warranty coverage.

Manitowoc remote systems are only

approved and warranted as a complete

new package. Warranty on the

refrigeration system will be void if a new

ice machine head section is connected to

pre-existing (used) tubing or condensing

units or vice versa.

Verify Components

³Bin

³Adapters

³Kits

³Location

Next verify that you have all the correct components

for the ice machine that is being installed

Installation Requirements

The location selected for the ice machine must meet the following criteria. If

any of these criteria are not met, select another location.

³Must have open site (gravity) drain available (see Water Supply and Drain

Requirements).

³Must have a grounded, polarized electrical power supply on a dedicated

electrical circuit (only appliance on circuit). If GFCI (ground fault circuit

interrupter) is required by your local electrical code, it must be breaker type,

not outlet type.

³Must have cold water supply line available at Ice Machine (see Water Supply

and Drain Requirements).

³Clearance and air temperatures must be met.

Head Section

Clearances

Top 5” (12.7 cm) is recommended for efficient operation and removal of top

cover/servicing.

Sides 5” (12.7 cm) is recommended for efficient operation and servicing.

There is no minimum clearance required.

Back 3” (7.6 cm) required when routing electrical inlet, water inlet and

refrigeration tubing out of the top of the unit.

5” (12.7 cm) required when routing all connections out the back.

³The air temperature must be at least 35°F (1.6°C), but must not

exceed 110°F (43.4°C).

³The location must be free of airborne and other contaminants.

³The location must not be near heat-generating equipment or in

direct sunlight.

³The location must not obstruct airflow through or around the ice

machine.

Location of Condensing Unit

³The air temperature must be at least -20°F (-28.9°C) but must

not exceed 130°F (54.4°C).

³CVD675/CVD1185/CVD2075 Only - The air temperature must

be at least -20°F (-28.9°C) but must not exceed 120°F (48.9°C).

³CVD1486 Only- The air temperature must be at least 50°F

(10°C) but must not exceed 110°F (43°C).

³The location must not allow exhaust fan heat and/or grease to

enter the condenser.

³The location must not obstruct airflow through or around the

condensing unit.

Condensing Unit Clearances

CVD675/CVD885/CVD1085/CVD1185/CVD2075

Top/Sides

There is no minimum clearance required, although 6” (15.2 cm)

is recommended for efficient operation and servicing only.

Front/Back

48” (122 cm)

CVD1285/CVD1485/CVD1885

Top/Sides

There is no minimum clearance required, although 6” (15.2 cm)

is recommended for efficient operation and servicing only.

Front

24” (61 cm)

Back

48” (122 cm)

CVD1486 ONLY

Top - 5” (12.7 cm) is required for efficient operation and

servicing.

Front/Back/Sides - 12” (30.5 cm)
