Manitowoc CNF0201 Manuel utilisateur

Part Number 000015432 Rev02 5/21

Countertop Nugget

Ice Machines

CNF0201 & CNF0202

Technician’s Handbook

Engineered for Ease

Safety Notices

Read these precautions to prevent personal injury:

• Read this manual thoroughly before operating,

installing or performing maintenance on the

equipment. Failure to follow instructions in this

manual can cause property damage, injury or death.

• Routine adjustments and maintenance procedures

outlined in this manual are not covered by the

warranty.

• Proper installation, care and maintenance are essential

for maximum performance and trouble-free operation

of your equipment.

• Visit our website www.manitowocice.com for manual

updates, translations, or contact information for

service agents in your area.

• This equipment contains high voltage electricity and

refrigerant charge. Installation and repairs are to be

performed by properly trained technicians aware of

the dangers of dealing with high voltage electricity

and refrigerant under pressure. The technician

must also be certified in proper refrigerant handling

and servicing procedures. All lockout and tag out

procedures must be followed when working on this

equipment.

• This equipment is intended for indoor use only. Do not

install or operate this equipment in outdoor areas.

As you work on this equipment, be sure to pay close

attention to the safety notices in this handbook.

Disregarding the notices may lead to serious injury and/or

damage to the equipment.

nWarning

Follow these electrical requirements during installation

of this equipment.

• All field wiring must conform to all applicable

codes of the authority having jurisdiction. It is

the responsibility of the end user to provide the

disconnect means to satisfy local codes. Refer to

rating plate for proper voltage.

• This appliance must be grounded.

• This equipment must be positioned so that the plug

is accessible unless other means for disconnection

from the power supply (e.g., circuit breaker or

disconnect switch) is provided.

• Check all wiring connections, including factory

terminals, before operation. Connections can

become loose during shipment and installation.

nWarning

Follow these precautions to prevent personal injury

during installation of this equipment:

• Installation must comply with all applicable

equipment fire and health codes with the authority

having jurisdiction.

• To avoid instability the installation area must be

capable of supporting the combined weight of the

equipment and product. Additionally the equipment

must be level side to side and front to back.

• Remove all removable panels before lifting and

installing and use appropriate safety equipment

during installation and servicing. Two or more

people are required to lift or move this appliance to

prevent tipping and/or injury.

• Do not damage the refrigeration circuit when

installing, maintaining or servicing the unit.

• Connect to a potable water supply only.

• This equipment contains refrigerant charge.

nWarning

Follow these precautions to prevent personal injury

while operating or maintaining this equipment.

• Legs must be installed and the legs must be screwed

in completely.

• Some 50 Hz models may contain up to 150 grams

of R290 (propane) refrigerant. R290 (propane)

is flammable in concentrations of air between

approximately 2.1% and 9.5% by volume (LEL lower

explosion limit and UEL upper explosion limit). An

ignition source at a temperature higher than 470°C

is needed for a combustion to occur.

• Refer to nameplate to identify the type of refrigerant

in your equipment.

• Only trained and qualified personnel aware of the

dangers are allowed to work on the equipment.

• Read this manual thoroughly before operating,

installing or performing maintenance on the

equipment. Failure to follow instructions in this

manual can cause property damage, injury or death.

• Crush/Pinch Hazard. Keep hands clear of moving

components. Components can move without

warning unless power is disconnected and all

potential energy is removed.

• Moisture collecting on the floor will create a

slippery surface. Clean up any water on the floor

immediately to prevent a slip hazard.

nWarning

Follow these precautions to prevent personal injury

while operating or maintaining this equipment.

• Objects placed or dropped in the bin can affect

human health and safety. Locate and remove any

objects immediately.

• Never use sharp objects or tools to remove ice or

frost.

• Do not use mechanical devices or other means to

accelerate the defrosting process.

• When using cleaning fluids or chemicals, rubber

gloves and eye protection (and/or face shield) must

be worn.

DANGER

Do not operate equipment that has been misused,

abused, neglected, damaged, or altered/modified

from that of original manufactured specifications.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

concerning use of the appliance by a person

responsible for their safety. Do not allow children to

play with, clean or maintain this appliance without

proper supervision.

nWarning

Follow these precautions to prevent personal injury

during use and maintenance of this equipment:

• It is the responsibility of the equipment owner to

perform a Personal Protective Equipment Hazard

Assessment to ensure adequate protection during

maintenance procedures.

• Do Not Store Or Use Gasoline Or Other Flammable

Vapors Or Liquids In The Vicinity Of This Or Any

Other Appliance.

• Never use flammable oil soaked cloths or

combustible cleaning solutions for cleaning.

• All covers and access panels must be in place and

properly secured when operating this equipment.

• Risk of fire/shock. All minimum clearances must be

maintained. Do not obstruct vents or openings.

• Failure to disconnect power at the main power

supply disconnect could result in serious injury or

death. The power switch DOES NOT disconnect all

incoming power.

• All utility connections and fixtures must be

maintained in accordance with the authority having

jurisdiction.

• Turn off and lockout all utilities (gas, electric, water)

according to approved practices during maintenance

or servicing.

Table of Contents

Part Number 000015432 Rev02 5/21 9

General Information

Model Numbers............................... 13

Model/Serial Number Location ............... 13

Manitowoc Cleaner and Sanitizer............. 13

Legs........................................... 14

Touchless Sensing Option .................... 14

Ice Machine Warranty Information............ 14

Installation

Location of Ice Machine....................... 15

Ice Machine Clearance Requirements......... 16

Ice Machine Heat of Rejection ................ 16

Electrical Service.............................. 17

Circuit Ampacity .......................... 17

Ice Machine Head Section Water

SupplyandDrains ............................ 18

Potable Water Supply...................... 18

Potable Water Inlet Lines .................. 18

Drain Connections ........................ 19

Operation ..................................... 21

Ice Making Sequence of Operation ........... 21

CNF0201 - CNF0202 Nugget Machines ..... 21

Touch Pad Sequence of Operation ......... 23

Water Level Check......................... 23

Sequence of Operation Chart ............. 24

10 Part Number 000015432 Rev02 5/21

Maintenance

Manitowoc’s Cleaning Technology............ 26

Exterior Cleaning .......................... 28

Remedial Cleaning Procedure ................ 29

Heavily Scaled Procedure ..................... 32

Detailed Descaling/Sanitizing Procedure..... 34

Sanitizing Procedure.......................... 36

Component Disassembly for Descaling and

Sanitizing ..................................... 38

General Information ....................... 38

Cleaning the Condenser ................... 52

Removal from Service/Winterization ......... 53

General ................................... 53

Troubleshooting

Low Temperature Safety Thermostat ......... 55

SafeGuard Feature ............................ 56

SafeGuards ................................... 58

No Water.................................. 58

No Ice Production ......................... 59

Ice Machine Will Not Run Diagnostics......... 61

Refrigeration Diagnostics..................... 67

Before Beginning Service . . . . . . . . . . . . . . . . . . 67

Installation/Visual Inspection Checklist..... 67

Water System Checklist .................... 68

Ice Production/Quality Check .............. 69

Analyzing Discharge Pressure.............. 71

Analyzing Suction Pressure ................ 73
