HI-SPEED

USB 2.0

AUTOMATIC

SHARING

SWITCH

USER

MANUAL

Models 162005 & 162012

MAN-162005/162012-UM-0109-01

Shown: Model 162012,

4-Port

Thank you for purchasing the MANHATTAN®Hi-Speed USB 2.0 Automatic

Sharing Switch, Model 162005 (2-port) or Model 162012 (4-port).

Ideal when several users need to share a USB cable modem, printer,

digital camera, scanner, external storage drive or other perhipherals,

this handy device lets you use either its convenient access-on-demand

switching for activation with a single click of an onscreen button or

onboard switches for manually selecting an active computer.

With built-in automatic sharing capability, the Hi-Speed USB 2.0 Automatic

Sharing Switch detects and switches when print commands are executed.

Idle-timeout switching helps ensure that data is fully sent from the active

printer buffer to the printer before the connection is disengaged to await

the next print command.

Easy-to-follow instructions in this user manual help make installation of

the switch quick and simple, so you’ll also soon be enjoying the benets

of these additional features:

• Easy-to-read onboard and on-screen LED indicators monitor status

• Over-current protection and hot-swappable

• Compatible with all USB-equipped computers

• Plug and Play; Windows and Mac compatible — requires no external

power supply

• Lifetime Warranty

Hardware Installation/Connections

Before installing the switch, make sure all computers and peripherals to

be connected are turned off.

1. With Model 162012 (shown below), connect up to four computers to

Ports 1-4 on the switch; with Model 162005, connect the two computers

to Ports 1 & 2 on the switch (cables

included with both models).

2. Connect the device port on

the switch to the selected

USB device.

3. Power on the computer(s)

and the connected USB device.

Computer

port

Device

port

Select button/

LED indicator

Software Installation

The USB Sharing application on the included CD offers a convenient

on-screen option (PCs only) for switching the computer source that’s

directed to the connected peripheral device (instead of manually pressing

the Select buttons on the top panel of the switch itself).

1. Insert the included software

CD into your CD-ROM drive.

The language dialog box will

display. NOTE: If installation

doesn’t begin automatically,

open Windows Explorer,

navigate to your CD-ROM

drive and double-click the setup.exe le.

2. Select a language from the drop-down menu (English is the default)

and click “OK.”

3. When the InstallShield Wizard welcome screen displays, click “Next.”

4. When the Choose Destination Location screen displays, click “Next”

to continue with the default directory as C:\Program Files\USB Sharing.

If the drive letter designation where you would like the application to

be installed is different from “C,” browse the drive instead, then click

“Next” to conrm the change and continue.

5. When the Maintenance Complete screen displays, click “Finish.”

Close any open windows, then reboot your computer.

6. After the reboot, a USB Sharing

shortcut will appear on the desktop,

and an indicator icon will appear in

the lower-right corner (as shown in the

sample images in Operation below).

Software Uninstall

To completely remove the software application from your PC, rst insert

the installation CD into your CD-ROM drive. When the Choose Setup

Language screen displays, click “OK.” When the Conrm File Deletion

prompt displays, click “OK” to conrm, then click “Finish” to complete

the uninstallation procedure.

You can also uninstall the software from “Add or Remove Programs” in

the Control Panel. Click “Add or Remove”: The Choose Setup Language

screen will display. Click “OK.” When the Conrm File Deletion prompt

displays, click “OK” to conrm, then click “Finish.”

Operation

This switch draws its power from the computer(s). Any connected USB

device will link to the rst connected computer that’s on; that is, with

computers connected to Port 1 and Port 2 of the switch, the computer

connected to Port 1 will be “designated” as the active link by the switch

until the USB device is redirected to another connected computer.

USB

Sharing

This computer is connected to —

and is ready to use — the USB device.

To make this computer ready to use the

USB device, right-click the on-screen

indicator icon or press Ctrl/F11.

Signals will continue to be sent back and forth between your computer(s)

and USB devices such as external hard drives and printers whenever

they’re connected through the switch. During these transmissions, USB

auto-sharing can be confused, resulting in a red blinking indicator icon.

To control USB auto-sharing without any

“device busy” indications, press Ctrl/F11 to

display the “Enforce switching” prompt, then

click “Yes” to conrm any switching of ports.

NOTE: Even without the USB Sharing application installed (Mac, Linux),

switching access to the connected USB device from one computer to

another can be done manually by pressing the Select button on the top

of the switch that corresponds to the desired port. If the Select button/

LED is lit, the corresponding computer is already linked to the USB device.

(Only one LED will light at any given time.) A ashing LED indicates that

the corresponding port is processing a redirect command and is not yet

ready for activity. (Refer to the Read Me le on the CD for details.)

While the USB device is being used

by Computer A, switching to another

computer is not allowed.

This computer is currently using the

USB device.

To make this computer ready to use the

USB device, right-click the on-screen

indicator icon or press Ctrl/F11.

This computer is connected to —

and is ready to use — the USB device.

Specications

Standards and Certications

• USB 2.0, USB 1.1, USB 1.0

• FCC

• CE

• WEEE

General

• Transfer speeds: 1.5 / 12 / 480 Mbps

• Model 162005, 2-port: (2) LED indicators; (2) mechanical switches

• Model 162012, 4-port: (4) LED indicators; (4) mechanical switches

• Bus powered

Ports

• Model 162005, 2-port: (1) A-type; (2) B-type

• Model 162012, 4-port: (1) A-type; (4) B-type

Physical

• Dimensions:

- Model 162005, 2-port: 68 x 42 x 20 mm (2.7 x 1.6 x 0.78 in.);

39.6 g (1.4 oz.)

- Model 162012, 4-port: 73 x 85 x 20 mm (2.8 x 3.3 x 0.78 in.)

87.8 g (3.1 oz.)

• USB A-type to B-type cable length: 1.5 m (5 ft.)

• Housing: ABS plastic

System requirements

• USB-enabled PC or Mac system

• Windows 2000/XP/Vista or Mac OS 9 or above

• Available USB port

Power

• Supply current from USB: 500 mA

Package Contents

• Hi-Speed USB 2.0 Automatic Sharing Switch

• USB cables, user manual and software CD

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
