UNIVERSAL

POWER

ADAPTER

USER

MANUAL

Models 100960

& 100977

MAN-100960/100977-UM-0509-03

Shown: NEMA version, Model 100977

Thank you for purchasing the MANHATTAN®Universal

Power Adapter, Model 100960 (Europlug) or Model 100977

(NEMA).

With 10 Watts and 6 adjustable output levels, this handy

adapter provides a single, convenient AC source for most

any portable device.

Before using the power adapter for the rst time, read the

information in this manual so you’re familiar with the various

components. Proper usage and connections will help

prevent inadvertent damage to attached electrical devices.

Once you’re ready to use this adapter, you’ll enjoy the

benets of these additional features:

• Convenient, single AC power source for notebook

computers and other portable devices

• Convertible DC plug tips that ensure proper polarization

and t

• Overload, overcurrent and overheat protection

• Lightweight and compact design easily stores for travel

• Lifetime Warranty

Package Contents:

• Universal Power Adapter

• 6 DC plug tips

1. Set the voltage

selector (right) to

the position which is

appropriate for use

with the device to

be connected to the

power adapter.

Typically, a sticker

like the one shown

below can be found

on the device,

indicating the

voltage required for

operation. If there is

not an exact match

in voltage among the

6 voltage options,

choose the one

designated for the

next lowest voltage;

for example, the

9.5 V DC rating on

the sticker would

indicate that the

9 V setting be used.

2. Choose whichever of the 6 included DC plug tips ts the

power adapter input jack on the device to be powered.

Typically, there is a diagram next to the jack indicating

how the DC plug tip needs to be connected to the power

adapter cable so the electrical polarity matches.

• If the diagram shows the positive sign (+) on the right,

insert the DC plug tip into the cable so that the “TIP”

side of the plug tip points to the “+” side of the cable.

• If the diagram shows the negative sign (–) on the right,

insert the DC plug tip into the cable so that the “TIP”

side of the plug tip points to the “–” side of the cable.

–

+–

–

DC plug tip

Power adapter

cable

TIP

DC plug tip

Power adapter

cable

TIP

SPECIFICATIONS

Standards and Certications

• CE EN60950

• EMC EN55014

General

• Europlug CEE 7/16, ungrounded (Model 100960);

NEMA 1-15, ungrounded (Model 100977)

• AC input:

Model 100960: 100 – 240 V; 50 – 60 Hz

Model 100977: 100 – 140 V; 50 – 60 Hz

• DC output: 3 – 12 V; maximum 1200 mA; 10 W

• Voltage/current settings (output current 220 V / 110 V):

3 V - 1.2 A 4.5 V - 1.2 A

5 V - 1.2 A 6 V - 1 A

9 V - 1 A 12 V - 0.9 A

Physical, Model 100960

• Dimensions: 92.8 x 54.4 x 93.8 mm (3.6 x 2.1 x 3.7 in.)

• Weight: 165 g (5.8 oz.)

• Cable: 1.5 m (5 ft.)

Physical, Model 100977

• Dimensions: 80.6 x 84.2 x 34 mm (3.1 x 3.3 x 1.3 in.)

• Weight: 190 g (6.7 oz.)

• Cable: 1.67 m (5.5 ft.)

All products mentioned are trademarks

or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
