MANGOSLAB Nemonic MIP-001 Manuel utilisateur
Version 1.0 (for Web)
UNPACKING / 제품구성
UserManual
/사용설명서
nemonic
/네모닉
PaperCartridge
/용지카트리지
ACAdapter
/전원어댑터
USBCable
/USB케이블
0
PaperOutletSlot
/용지배출구
DispenserButton
/디스펜서버튼
StatusIndicatorLED
/상태표시LED
PowerButton
/전원버튼
ResetButton
/리셋버튼
CoverLever
/커버레버
USBConnector/USB커넥터
PowerConnector/전원커넥터
GENERAL DESCRIPTION / 각부 명칭 1
POWER ON / 전원연결
2
OPEN / 커버 열기 3
PREPARE PAPER / 용지 준비
AB
- DISPENSER BUTTON
- 디스펜서 버튼
memo
memo
Hold2seconds:Printlatestmemo
2초이상누르기:최근메모출력
Hold
2 sec
Pressonce:Dispensememo
한번누르기:빈메모지뽑기
4
5
AUTO CUTTER / 자동 커팅
5MOBILE APP / 모바일 앱
ANDROID APP iOS APP
For more information, please visit :
상세정보가필요하시면홈페이지를방문하세요.:
www.mangoslab.com
Search & Download :
‘nemonic’ or ‘mangoslab’ app
검색 및 다운로드 :
‘nemonic’ 또는 ‘mangoslab’ app
Bluetooth on
/ 블루투스 켜기
A
If you download and install 'nemonic Print Service Plugin' from Google
Play Store, you can print directly from apps that support 'Print' option.
구글�플레이스토어에서 '네모닉�프린트�서비스�플러그인'을�다운받아�설치하시면
인쇄�기능을�지원하는�다른�앱에서도�출력이�가능합니다.
nemonic Print Service Plugin app
5
Download nemonic Printer Driver & PC App :
네모닉 프린터 드라이버 및 PC 앱 다운로드 :
www.mangoslab.com/download
PC APP / PC 앱
DRIVER & APP
For more information, please visit :
상세정보가필요하시면홈페이지를방문하세요.:
www.mangoslab.com
B
Android 5.0(Lollipop) and later / iOS 9.0 and later / Windows 7 and later
iPhone 7, iPhone 7 Plus, iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus,
iPhone 5s, iPhone 5c, iPhone 5, iPhone SE, iPad Pro (12.9‒inch),
iPad Pro (9.7‒inch), iPad Air 2, iPad Air, iPad mini 4, iPad mini 3, iPad mini 2,
iPad mini, iPad (4th generation)
nemonic compatible iOS model list
nemonic app supports
STATUS INDICATOR LED INFORMATION
/ 상태표시 LED 정보
1~3min
x3
x2
x2
PrinterHeadOverheated
/프린터과열
CoverOpen/커버열림
NoPaper/용지없음
PaperJam/용지걸림
Readytoprint/출력대기상태
Bluetooth/블루투스통신
:On/항상켜짐
:Flashing/깜박임
Papercolorinformation/용지컬러표시
Hold
5 sec
Hold 5 seconds
/ 5초이상 누름
Power on / 전원 켬
FACTORY RESET / 공장 초기화
!
MAINTENANCE & CLEANING
/ 관리 및 청소
CAUTION!HOTSURFACE
/주의! 고온조심
CAUTION!:
Turnoffandunplugthepowercord
/ 주의! :전원을끄고코드를뽑으세요
Ethylalcohol/에틸알콜
Alcoholcottonswab
/알콜뭍힌면봉
PrinterHead
/프린터헤드
x2~3
Android is a trademark of Google Inc.
Microsoft, Windows and Windows Vista are trademarks/registered trademarks of
Microsoft Corporation in USA and other countries.
Bluetooth® Watermark and Logo is a registered trademark of Bluetooth SIG, Inc.,
MANGOSLAB Co., Ltd. indicates the logo and trademark under its corporations permission.
iPhone, iPad are trademarks of Apple Inc. in USA and other countries.
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution
THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
IMPORTANT NOTE : FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
IC Information to User
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any
interference, including interference that may cause undesired operation of the device
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d’en compromettre le fonctionnement.
This equipment may be operated in GB, FR, DE, IT, ES, PL, RO, NL, BE, GR, PT, CZ, HU, SE, AT,
BG, DK, FI, SK, IE, LT, HR, LV, SI, LU, EE, CY, MT
声明：此为B级产品， 在生活环境中, 该产品可能 会造成无线电干扰.
这种情况下， 可能需要用对其
干扰采取切实可行的措施. 仅适用于非热带气候条件.
해당�무선설비는�운용�중�전파�혼선�가능성이�있으므로�인명안전과�관련된�서비스는�할�수�없습니다.
이�기기는�가정용 (B급) 전자파적합기기로서�주로�가정에서�사용하는�것을�목적으로�하며, 모든
지역에서�사용할�수�있습니다.
•
•
•
•
•
•
•
•
•
•
인증받은자의�상호
기자재의�명칭(모델명)
인증번호
제조년월
제조자/제조국가
고객센터
망고슬래브�주식회사
특정소출력�무선기기
(무선데이터통신시스템용�무선기기)
MSIP-CMM-MGJ-MIP-001
별도표시
망고슬래브�주식회사/한국
1577-6670
Product title Wireless data communications system wireless device
(Model name) (MIP-001)
Manufacturer/Country MANGOSLAB Co., Ltd. / Korea
고객센터 : 1577-6670
Product inquiry or Customer service:
MANGOSLAB Co., Ltd. (www.mangoslab.com)
support@mangoslab.com
Specifications
Product certifications and Customer service information
Method
Printing Width/Resolution
Paper
Connectivity
Power
Weight
Operating Temperature
FVIN
Direct Thermal Printing
72mm/203dpi (576 dots)
nemonic Thermal Paper
USB 2.0, Bluetooth v4.1
(Frequency range : 2.40~2.48GHz)
Input : AC100~240V, 50~60Hz, 2.0A
Output : 24V 2.0A (DC Symbol : )
530g
5~45˚C (30~80% Humidity) / TMA : 45˚C
v1.05
