MAJORITY PEMBROKE Manuel

PEM-NET-DAB-BLK

MAJORITY

PEMBROKE

Internet & Digital Radio

Instrucons Guide

What’s In The Box?�� 1

Controls And Funcons��2

Navigaon Controls �� 6

Instrucons Guide ��7

Basic Operaon �� 7

Internet Radio �� 10

Pre-seng your favourite internet staons ��11

Media Centre �� 12

FM Radio �� 14

DAB / DAB+ Digital Radio �� 15

Informaon Centre �� 17

Connecons �� 18

Bluetooth �� 19

Conguraon Sengs �� 20

Date&Time: Date and me opons �� 21

Alarm Sengs ��22

Seng the Alarm ��23

Other Funcons ��26

Addional Seng Opons ��28

Troubleshoong �� 29

Specicaons ��30

Warranty ��30

Safety Informaon�� 31

Contents

Watch video tutorials and register

your product for a FREE 3-year warranty

at www.majorityradios.co.uk

3YEAR

WARRANTY

What’s In The Box?

1. Pembroke Internet Radio

2. Remote Control

3. DC-in power supply cable

4. Instruction guide

Box Contents

3 4 5

6 7 8 9 10 11

Controls And Funcons

Front View / Control Buttons

1. Display Screen 2. Volume Adjustment Dial

3. Standby

4. Mode

5. Home

6. Dimmer

7. Favourite

8. Alarm

9. Previous

10. Sleep

11. Next

12. Navigation/Select Dial

212

13 14 15 16 17

13. ON/OFF Switch

14. DC power input

15. Line Out

16. Aux In

17. USB Charging Port

Back View / Connections

Controls And Funcons

Remote Control

Controls And Funcons

EQ AlarmSleepDimmer

FAV FAV+

HOMEMODE

VOL+

VOL-

ABC DEF

JKLGHI MNO

TUVPQRS WXYZ

EQ AlarmSleepDimmer

FAV FAV+

HOMEMODE

VOL+

VOL-

ABC DEF

JKLGHI MNO

TUVPQRS WXYZ

111

1. Power On/O

Switch the unit between on and

Standby mode

2. Dimmer

Switch between two dimmer

settings

3. Equaliser

Adjust the sound to dierent

media options for the best sound

4. Skip forward button

Skip forward through tracks in CD

mode

5. Skip backward button

Skip backwards through tracks in

CD mode

6. MODE button

Scroll through available audio

modes on display screen

7. Scroll up

8. < back button/scroll left

Go back to previous display

screen or options available. Also

use to scroll left

9. Vol - button

10. Preset recall

When in the audio mode view

favourite stations that have been

set

11. MUTE button

Stop/start audio sounding

Controls And Funcons

12. Sleep button

Select repeatedly until desired

sleep timer set on top right of

display

13. Alarm button

Select to view and create alarm

options

14. Stop button

15. Pause/Play

16. HOME button

View main display screen

17. > forward button/scroll

right

Use to go to next option/screen

or scroll right.

18. Select button

Select chosen option

19. Scroll down

20. Vol + button

21. Keypad

Type numbers and letters

22. Add as a favourite/preset

When on the desired station,

press to set as a favourite. Use the

select OK button to choose preset

number

Navigation Controls

Controls And Funcons

Standby button: This should be used to turn your radio on

and o. The Standby screen will display the time, date and any

settings set such as alarms.

To turn o standby, press the Standby button to be taken to the

home screen, or last function that you were using before putting

into standby.

Select Dial/Volume: Rotate the dial clockwise or anticlockwise

to scroll through choices and press down the dial to conrm

selections.

Change the volume when you are on the radio station playing

screen. The volume will not be altered when you are navigating

around the radio as it will begin to function as the Select dial.

Home button: Select the Home button to browse through your

audio options such as Local Radio, Internet Radio, Media Centre,

Information Centre, AUX, Conguration Settings.

Use the Home button to cancel out of settings being made.

Dimmer: Select Dimmer to choose between the two default

options. Alter dimmer’s brightness in Conguration settings.

< and > buttons: Buttons used to alter settings. Use the

‘previous’ button to go back a step.

Instrucons Guide

Basic Operation

Starting up your internet radio

Plug the adaptor connector into the back of the system labelled

‘DC in’ (Ref. 14) and turn the power on from the mains. Switch

the button at the back of the radio to ‘ON’ (Ref. 13) to display a

‘Welcome’ screen.

Ensure the antenna is extended as far as possible. This will

enable you to get the best signal you can.

After the Welcome screen, you will be able to select your chosen

language by scrolling with the Select Dial (Ref. 12). Select your

language by pressing down the Select Dial.

If this is the rst time of using your radio, you will get the option

to set up your WiFi to stream Internet Radio with the message

“Would you like to congure network now?”. If you select YES,

your radio will begin to scan for nearby networks to connect to.

If you select NO then you can set this up later in conguration

settings.

Manual WiFi Set-up

If you select YES, you will be able to select your chosen WiFi

network and enter WiFi password in the next display screen.

Type letters/numbers by scrolling with the select dial (Ref.)

until the correct digit is displayed and click ‘>’ to go to the next

digit. Once nished, press down the select dial to conrm

Wireless Network (WPS PBC)

When at the “Would you like to congure network now?” stage,

if you select “YES (WPS)” your radio will begin to search for WiFi

connections.

Whilst this has been selected you will have 120 seconds to click

the WPS button on your WiFi modem. This will connect your WiFi

to your radio without manually writing in the passcode.

Instrucons Guide

Enable ‘Check Network when

Power On’?

NOYES

00:00

Would you like to congure

Network now?

Yes (WPS) NOYES

00:00

Please press the WPS button on

the router within 120 Secs.

00:00

Enable ‘Check Network when

Power On’?

NOYES

00:00

Would you like to

congure network now?

00:00

Yes (WPS) NOYES

00:00

Enter Password

1/1

00:00

Move OKInput

Scanning for

Wireless Network...

00:00
