Product Overview

The DHS Data Logging System for Dry Heat Sterilization is an all in one depyrogenation

solution that comes equipped with:

• HiTemp140-M12, High Temperature Data Logger

• 36 inch Glass Braided RTD depyrogenation probe with M12 connector and ﬂat probe tip

• ThermoVault Max, Extreme Temperature Thermal Barrier

DHS Data Logging System

Installation Guide

Installing the Interface cable

- IFC400 or IFC406

Refer to the “Quick Start Guide” included in the package.

Installing the software

Insert the Software USB stick in an open USB port. If the autorun does not appear, locate the

drive on the computer and double click on Autorun.exe. Follow the instructions provided in

the Wizard.

Device Operation

Connecting and Starting the data logger

- Once the software is installed and running, plug the interface cable into the docking

station.

- Connect the USB end of the interface cable into an open USB port on the computer.

- The device will appear in the Connected Devices list, highlight the desired data logger.

- For most applications, select “Custom Start” from the menu bar and choose the desired

start method, reading rate and other parameters appropriate for the data logging

application and click “Start”. (“Quick Start” applies the most recent custom start options,

“Batch Start” is used for managing multiple loggers at once, “Real Time Start” stores the

dataset as it records while connected to the logger.)

- The status of the device will change to “Running”, “Waiting to Start” or “Waiting to

Manual Start”, depending upon your start method.

- Disconnect the data logger from the interface cable and place it in the environment to

measure. Note: The device will stop recording data when the end of memory is reached or the device is

stopped. At this point the device cannot be restarted until it has been re-armed by the computer.

Downloading data from a data logger

- Place the logger into the docking station.

- Highlight the data logger in the Connected Devices list. Click “Stop” on the menu bar.

- Once the data logger is stopped, with the logger highlighted, click “Download”. You will

be prompted to name your report.

- Downloading will ofﬂoad and save all the recorded data to the PC.

www. .com information@itm.com1.800.561.8187

Product User Guide

Removing the Data Logger from the Thermal Barrier

1. Unscrew the lid of the thermal barrier.

3. Unscrew the HiTemp140-M12 data

logger, from the lid of the thermal barrier.

4. Slide the probe of the data logger out

from the lid of the thermal barrier.

2. Slide out the data logger and lid from

the barrier body.

www. .com information@itm.com1.800.561.8187

Product Maintenance

O-Rings

O-ring maintenance is a key factor when properly caring for the HiTemp140-M12. The

O-rings ensure a tight seal and prevent liquid from entering the inside of the device. Please

refer to the application note “O-Rings 101: Protecting Your Data”, found on the MadgeTech

website, for information on how to prevent O-ring failure.

Battery Replacement

Materials: ER1425S-HT Battery

1. Unscrew the bottom of the logger and remove the battery.

2. Place the new battery into the logger. Note the polarity of the battery.

3. Screw the cover back onto the logger.

Recalibration

The HiTemp140-M12 standard calibrations are two points at 50 1and 150 1and is

veriﬁed at 100 1.

Pricing:

Recalibration traceable to NIST $70.00

Recalibration only $40.00

Prices and speciﬁcations subject to change.

RMA Instructions

To send a device back in to MadgeTech, follow the instructions below to create an

RMA

(Return Merchandise Authorization) on the MadgeTech website:

1. Visit the Services tab select RMA Process.

2. When the web page opens, please sign in. If this is the ﬁrst time, select Click here to

button and ﬁll in all the blank ﬁelds.

3. Complete the applicable ﬁelds on the form including customer Billing and Shipping

information, even if they are the same. Please see the ﬁeld explanation below for a more

detailed description about questions asked in the Device Information section.

4. When all of the ﬁelds are complete, click Generate RMA.

5. Print out the conﬁrmation page that follows containing the RMA number and

MadgeTech’s address for shipping. A Return Merchandise Authorization must be

accompanied by a copy of the RMA paperwork and shipping is prepaid by the

customer. The RMA number should be clearly marked on the outside of the package.

6. Please ship the package via UPS, FedEx, TNT, or DHL to the address listed on the

conﬁrmation page. USPS will not ship MadgeTech data loggers.

7. A notiﬁcation email will be automatically sent when MadgeTech has received the RMA.

DHS Data Logging System

www. .com information@itm.com1.800.561.8187

Temperature Sensor 36 inch Glass Braided RTD depyrogenation probe

Temperature Resolution 0.0001 1, 0.01 °C (0.02 °F)

Temperature Accuracy ±1.2 °C (-200 °C to +400 °C)

Probe Measurement Range -200 °C to +400 °C

Connector Type M12 Female, 4 Pin

Reading Rate 4 readings per second up to 1 reading every 24 hours

Memory 43,690 readings

Start Modes • Software programmable immediate start

• Delay start up to 18 months in advance

Stop Modes Manual or Timed (speciﬁc date and time)

Trigger Settings

High & Low limits may be set. Once data meets or exceed sets limits, the device

will record to memory. Bi-level start and stop triggers can also be programmed.

Users can specify the number of readings to take after the device triggers.

Readings in Trigger

Settings Mode 18,724 readings

Real Time Recording May be used with PC to monitor and record data in real time

Password Protection An optional password may be programmed into the device to restrict access

to conﬁguration options. Data may be read out without the password.

Memory Wrap Around Yes

Battery Type 3.6V high-temperature lithium battery included; user replaceable

Battery Life 1 year typical (1 minute reading rate)

Calibration Digital calibration through software

Calibration Date Automatically recorded within device

Data Format Date and time stamped °C, °F, °R, K

Time Accuracy ±1 minute/month at 25 ºC

Computer Interface IFC400 or IFC406 USB docking station required; 125,000 baud

Operating System Compatibility XP SP3/Vista/Windows 7/Windows 8/Windows 10

Dimensions Body: 2.15 in x 0.97 in x 0.97 in (54.5 mm x 24.6 mm x 24.6 mm)

Probe: 0.10 in dia. x 36 in L (2.54 mm dia. x 76.2 mm L)

Materials Body: 316 Stainless Steel

Probe: Stainless Steel, Fiberglass, PEEK

Approvals CE

Battery Warning

WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE, FORCE OVER

DISCHARGE, CRUSH, PENETRATE, OR INCINERATE. BATTERY MAY LEAK OR EXPLODE IF HEATED ABOVE 150ºC (302ºF).

General Speciﬁcations

Product User Guide

www. .com information@itm.com1.800.561.8187

Speciﬁcations subject to change.

See MadgeTech’s terms and conditions

Operating Environment Refer to the Time vs. Temperature Chart

IP Rating Not Rated

Barrier Materials 316 Stainless Steel, PTFE, Silicone

Enclosure Dimensions 1.75 in OD x 9.6 in L (44.45 mm OD x 243.8 mm L)

Weight 3.0 lb (1350 g)

Thermal Barrier Speciﬁcations

DHS Data Logging System

www. .com information@itm.com1.800.561.8187

Ambient

Temperature

Maximum Exposure

Time (air)

-200 °C 128 minutes

-180 °C 137 minutes

-160 °C 148 minutes

-140 °C 163 minutes

-120 °C 183 minutes

-100 °C 213 minutes

-80 °C 263 minutes

-60 °C 368 minutes

-40 °C to +140 °C Indeﬁnitely

150 °C 601 minutes

160 °C 468 minutes

170 °C 396 minutes

180 °C 348 minutes

190 °C 313 minutes

200 °C 286 minutes

210 °C 265 minutes

220 °C 247 minutes

230 °C 233 minutes

240 °C 220 minutes

250 °C 209 minutes

260 °C 200 minutes

270 °C 192 minutes

280 °C 184 minutes

290 °C 178 minutes

300 °C 172 minutes

310 °C 166 minutes

320 °C 161 minutes

330 °C 157 minutes

340 °C 153 minutes

350 °C - 400 °C 60 minutes

Product User Guide

Time vs. Temperature Chart

www. .com information@itm.com1.800.561.8187

DOC-1322035-00 REV 1 2016.01.27

Listed speciﬁcations can be used to determine maximum allowable exposure times for the HiTemp140

with ThermoVault Max. The barrier extends the operating temperature of the logger up to, but

not exceeding, the measurement range. Please consult the measurement range of the probe for

temperatures above 250 °C (482 °F).

Both the data logger and ThermoVault Max must be at ambient temperature, approximately 25 °C (77

°F) before being placed in the extreme temperature environment. Immediately following exposure to

high temperature, the data logger should be removed from the ThermoVault Max, using appropriate

precautions, as it could be VERY hot. Failing to remove the data logger may allow heat trapped in the

ThermoVault Max to continue to heat the data logger to potentially unsafe levels.

The ThermoVault Max may take hours to fully cool down. Even if the exterior of the ThermoVault Max is

cool to the touch, the interior of the barrier and its contents may still be VERY hot.

The ThermoVault Max is primarily intended for use in dry air environments, but with the addition of the

TMAX Wet Seal Kit, the ThermoVault Max may also be used in liquids and steam environments.

If your application involves a ramp up to a temperature above 150 °C (302 °F) and/or any complex

temperature proﬁle that isn’t a constant process, please contact MadgeTech to determine whether the

HiTemp140 with ThermoVault Max is suitable for the application.

To determine if the HiTemp140 with ThermoVault Max is suitable for the application, please provide

MadgeTech with a detailed description of your process, including temperatures, durations, ramp times

and process media such as air, steam, oil or water. If MadgeTech is unable to deﬁnitively calculate the

suitability of our product for your application, a test unit outﬁtted with a high temperature indicator can

be provided.

Disclaimer & Terms of Use

www. .com information@itm.com1.800.561.8187
