MacroAir Technologies Airelite Manuel utilisateur

1 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

2 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

3 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

TABLE OF CONTENTS

Page4-Caution&Safety

Page5-FanClearance&Placement

Page6-FanComponents

Page7-RigidMount&Components

Page8-UniversalMount&Components

Page9-FanLevelingforRigidMount

Page11-FanMounting

Page12-SpanMount

Page15-TrussMount

Page16-GlulamRigidMount

Page20-I-beamUniversalMount

Page22-GlulamUniversalMount

Page27-Electrical&SafetyCableInstallation

Page28-Wire&SafetyCableRouting

Page29-RemoteOverview

Page30-RemoteInstallation

Page33-GuyWireInstallation

Page34-GuyWireInstallation

Page35-GuyWireTightening

Page37-BladeInstallation

Page38-Blade&SafetyLinkAssembly

Page40-TechnicalSupport

4 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

CAUTION & SAFETY

READ THE ENTIRE MANUAL BEFORE OPERATING THE FAN.Ensurethatallsafetypracticesandinstructionsarefollowedduring

theinstallation,operationandservicingofthefan.Failuretoapplythesesafetypracticescouldresultindeathorseriousinjury.Ifyoudo

notunderstandtheinstructionspleasecallourTechnicaldepartmentforguidance.

Thefaninstallationshouldfollowtherecommendationsoutlinedinthismanual.MacroAirisnotresponsibleforanyinjuryordamageto

peopleorpropertyasaresultofnotcomplyingwiththerecommendationsoutlinedinthismanual.

HAZARDOFELECTRICSHOCK,

EXPLOSION,ORARCFLASH

Readandunderstandthismanualbefore

installingoroperatingafanunit.Installation,

adjustment,repair,maintenancemustbe

performedbyqualiedpersonnel.

Theuserisresponsibleforcompliancewith

allinternationalandnationalelectricalcode

requirementswithrespecttogroundingofall

equipment.

Manyofthepartsofthisunitoperateatline

voltage.DONOTTOUCH.

Installallcoversbeforeapplyingpoweror

startingandstoppingtheunit.

DAMAGEDEQUIPMENT

Donotoperateorinstallanyfansorfanaccessoriesthatappeartobedamaged.

Failuretofollowthisinstructioncanresultindeath,seriousinjury,orequipment

damage.

MAINTENANCEANDSERVICE:

Ifthefandoesnotoperateproperlyusingtheproceduresinthismanual,BECERTAIN

TOREMOVEALLPOWERTOTHEUNITandcontactourtechnicaldepartmentfor

futherassistance.

Keepallbodypartsclearofmovingpartatalltimes.

Allelectricaltroubleshootingandrepairmustbedonebyaqualiedtechnicianand

meetallapplicablecodes.

5 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

FAN CLEARANCE & PLACEMENT

Slope (in) 2/12 4/12 6/12 8/12 10/12

Roof Angle 9.5o18.4o26.6o33.7o39.8o

Diameter Recommended Extension Length Clearance

Radius

8feet N/A N/A 1 1 2 15’’

10feet N/A 1 1 2 3 18’’

12feet N/A 1 2 3 4 22’’

14feet 1 2 3 4 5 26’’

16feet 1 3 4 5 7 29’’

18feet 2 3 5 6 8 33’’

20feet 2 4 5 7 9 36’’

Thegoalofthisdiagramistodeterminetheproperextensionlengthtomaintainaminimumbladeclearanceof15%ofthefan’s

diameter.Theextensionlengthsaboveareminimumrecommendationsonly,basedsolelyonroofpitchandfandiameter.Otherfactors

mustbeevaluatedwhendeterminingextensionrequirements.Inaddition,OSHArequirementsstatethatthefanbladesmustbea

minimumof10feet(3.05meters)abovetheoor.Contactourtechnicaldepartmentforassistancewithfanplacementandextension

selection(technicalsupportcontactinformationcanbefoundonpage39).

6 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

FAN COMPONENTS

Blade

SafetyRetainerLink

FanUnit

BladeEndCap

BladeStrut

7 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

RigidMount

OptionalRigid

MountExtension,

1FT-2FT

RIGID MOUNT & COMPONENTS

Therigidmountisusedwhenextensions2feetorshorterarerequiredorwhen

noextensionisrequiredforanapplication.Noguywiresarerequiredforuse

witharigidmount.

8 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

UniversalMount

UniversalMount

Extension,

3FT-10FT

GuyWireKit

UNIVERSAL MOUNT & COMPONENTS

TheUniversalMountisusedwhenextensionslongerthan2feetare

requiredinanapplication.Thismountutilizesfour(4)guywirecables

withturnbucklestolevelandstabilizethefan.

GuyWireAttachment

Points

9 CopyrightMacroAir2013  macroairfans.com  AirEliteInstallationManual  

FAN LEVELING FOR RIGID MOUNT

Rotatemountasillustrateduntilfanunitislevel.Oncethefanunitislevel,torqueallboltsto70Ft-Lbs.
