Instruction manual
Model no.: P96
~ II ~
Table of contents
1Brief introduction..............................................................1
1.1 Product features................................................1
1.2 Safety cautions..................................................2
1.3 What’s in the box?.............................................2
1.4 Product appearance..........................................3
1.5 Buttons and connectors.....................................3
2Quick experience.............................................................5
2.1 Basic operation:.................................................5
2.2 Main interface....................................................7
2.4 Connecting Wi-Fi...............................................9
3Product operation ..........................................................11
3.1 Online Video....................................................11
3.2 Multimedia.......................................................11
3.3 File Manager....................................................11
3.4 HDMI/MHL IN..................................................14
3.7 Other app...................................................................15
3.9 Browser......................................................................17
3.12 Battery...................................................................23
~ III ~
3.13 Connecting to computer........................................24
3.14 System recovery....................................................25
4Appendix A: Product Specification.................................26
5Appendix B: Trouble shooting........................................28
~ 1~
1Brief introduction
Thanks for buying this pico projector. It is an integrated platform with
portable office, web browsing, audio and video playback, games and
entertainment. You can use it for business presentation, training, home and
outdoor entertainment.
Before using this product，please kindly read this instruction manual carefully,
and keep in mind the safety cautions, operations, and product specifications,
this will help you to use the product quicker and more conveniently.
1.1 Product features
The product gets the following features：
Slim and cute, delicate and portable
Mini projector, clear projection with high brightness
Video play, full HD video decoding
Wi-Fi net-surfing, mobile office
Play store, mass APP download
High-capacity Li-battery
~ 2~
1.2 Safety cautions
Do not put the working projector towards any person’s or pet’s eyes.
Do not expose the projector to direct sunlight, rain or any moisture.
Do not pack or store the product in a warm environment, such as an electric
blanket etc.
Do not put the product to on uneven surface or near any heat source such as a
furnace, heating machine.
Wipe the product with dry cloth.
Do not use this product when driving or riding.
Use the corresponding accessories provided by manufacturer.
If the product is dropped or is broken in shells, please turn off the power and
contact the authorized dealer or the service center.
1.3 What’s in the box?
Please kindly check if you have got all the accessories listed below in the
package. If you get anything missing, please contact the dealer.
Product ...................................................................................... ×1
Adapter ...................................................................................... ×1
Remote control------------------------------------------------------- ×1
Quick set-up guide .................................................................... ×1
Warranty card............................................................................ ×1
~ 3~
1.4 Product appearance
Remark: The buttons on the top panel is touch key, and the light will be off
within around 7 seconds. A 2nd touch will reactivate the buttons.
1.5 Buttons and connectors
1.5.1 Buttons
As shown on page 3, you can find the product image. Button names, functions
and operation methods are listed below:
Button name function operation
POWER ON/FF Power on/OFF, SLEEP press
HOME Enter into main interface. press
RETURN（BACK）Return back to previous step. press
~ 4~
Direction buttons
（Up/Down/Left/Right）
Switch among each interface. press
OK
Confirm the operation.(Enter, open or
other functions nominated by the SW.
press
FOCUS Adjust the projection lens. stir
MENU Display the menu of the APP. press
RECOVERY This is used for system recovery. poke
1.5.2 Connectors
As shown on page 3, you can find all the connectors. Connector names and
functions are listed below:
Connector function
USB
Universal serial bus interface
It is used to connect U disk, keyboard, mouse, etc…
DC-IN
5V DC power input jack.
Connect power adapter to get power supply or charge.
Audio jack This can be used to connect the earphone and speakers.
USB OTG
Connect computer to transmit data.
Connect OTG converter to connect U disk, keyboard, mouse etc
HDMI/MHL
-IN
High definition multimedia interface. This can be used to connect
with HD signal output devices, such as computer, game machine,
high-definition camera etc...
~ 5~
2Quick experience
After having a basic understanding on the product, you can start to use it.
2.1 Basic operation:
For first using the production, please charge the battery in time (Refer to Page
27 for battery charging details.).
2.1.1 Power on/OFF/SLEEP
1) In shutdown mode, press the power button and hold for 3 seconds, the
indicator will become green, then the product enters into starting mode,
and the system will get started.
2) When the product is powered on, press the power button and hold for 3
seconds, a menu will pop up with three options: POWER
OFF/SLEEP/CANCEL.
3) Wake up: When the production is in SLEEP mode, press the POWER
button, the product will resume the working status before its sleep.
Remark:
1). If the product gets system crash or halts, press the POWER button and
hold for 6 seconds, the product will be powered off mandatorily.
~ 6~
2). Sleep: This means the product is in standby model, and projection is closed. The
power consumption is quite low. Push the “ON/OFF” key, the product will resume the
working status before its sleep immediately.
After entering the main interface of the product, you can also click the POWER icon on
the bottom of the screen to power off the product.
2.1.2 Focus adjustment
Enfilade the product toward a flat and clear projection place (for example:
projection cloth, white walls, or any white surface). Press the POWER button
to power on the product. Adjust the focus slowly to get a clearest projection.
Remark: In consideration of the design specification and user experience, and getting a
clear projection, the minimum distance between the lens and projection plane is 0.5m.
2.1.3 Mouse operation
When you use the mouse which is compatible with this product as interactive
device, you can use mouse to operate the product.
Mouse key functions are listed as below (basing on operations via right hand):
Left key: Its function is the same as the ENTER button.（Refer to for
details）.You can do click, double click, and long-time press.
Right key: Its function is the same as the RETURN button (Refer to 1.5.1 for
details). You can do click.
~ 7~
2.2 Main interface
Power on the product and adjust the focus if needed. After the system is
started, you will see the main menu as listed below:
The bottom region of the interface is the system status bar. It shows the
function buttons, icons and notice. The main interface includes: Online video,
Multimedia, File manager, HDMI/MHL IN, Pico Setting, Tools, Other App,
Browser, App Store and Settings.
You can use direction keys (UP/DOWN/LEFT/RIGHT) or mouse to operate:
①Online video: Click and you will see the online video APP interface.
②Multimedia: Click and you will see the multimedia playing tools.
③File manager: Click and you can see the files in the local(projector
storage) and USB.
④HDMI/MHL IN: Click and project the contents from HDMI/MHL
output devices.
⑤Pico Setting: Click and you can set the projector’s brightness, ect..
⑥Tools: Click and you the tools, such as:WPS
