LUCCI FUTURA ECO Instructions d'installation et d'utilisation

FUTURA ECO LED – V2.0 –MUTIL-2014-05-6

LUCCI

FUTURA ECO DIMMABLE LED

CEILING FAN

INSTALLATION

OPERATION

MAINTENANCE

WARRANTY INFORMATION

CAUTION

READ INSTRUCTIONS CAREFULLY FOR SAFE

INSTALLATION AND FAN OPERATION.

Futura Eco Installation Instructions

1 | Page

CONTENTS

Installation Instruction Manual .......................................................................................... 3

Installationsanleitung ........................................................................................................11

Guide d’installation............................................................................................................18

Manual de instrucciones de instalación.............................................................................26

Manuale delle istruzioni di installazione............................................................................34

Installatiehandleiding.........................................................................................................42

Futura Eco Installation Instructions

2 | Page

CONGRATULATIONS ON YOUR PURCHASE

Congratulations on purchasing this quality Lucci product. To ensure correct function and safety, please read and save all

instructions before using the product.

SAFETY PRECAUTIONS

The information contained in the following pages has been prepared to ensure you of trouble-free operation of your

ceiling fan.

1. This appliance is NOT intended for use by persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

2. An all-pole disconnection switch must be incorporated in the fixed wiring in accordance with local wiring rules.

3. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact

your local government for information regarding the collection systems available. If electrical appliances are

disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain,

damaging your health and well-being.

4. The structure to which the fan is to be mounted must be capable of supporting a weight of 40kg.

5. The fan should be mounted so that the blades are at least 2.3 metres above the floor in Europe

6. The fan should be mounted so that the blades are at least 2.1 metres above the floor in Australia

7. The fan is suitable for indoor use only.

8. Only an authorized electrician should execute the installation.

Futura Eco Installation Instructions

3 | Page

BEFORE INSTALLATION

Unpack the fan carefully and identify the parts. Please refer to Fig. 1.

1 Hanger bracket x 1

2 Remote receiver x 1

3 LED driver x 1

4 Pre-assembled fan motor, down rod and canopy cover x 1

5 LED light kit x 1

6 Blades x 4

7 Screw for hanger bracket x 2

8 Flat washer x 2

9 Spring washer x 2

10 Balancing kits x 1 set

11 Wall plugs for screw x 2

12 Motor screws for blades x 13

13 Remote hand set x 1 set

Fig. 1

Futura Eco Installation Instructions

4 | Page

INSTALLING THE MOUNTING BRACKET

•The ceiling fan must be installed in a location so that the blades are spaced 300mm from the tip of the blade to the

nearest objects or walls.

•Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 40kg, with

two long screws provided. Ensure at least 30mm of the screw is threaded into the support.

NOTE: The bracket screws provided are for use with wooden structures only. For structures other than wood,

the appropriate screw type MUST be used.

Angled ceiling Installation

This fan hanging system supports a maximum 20 degree angled

ceiling installation.

Fig. 2

Fig. 3

Futura Eco Installation Instructions

5 | Page

INSTALLING THE FAN

1. Carefully lift the fan and place the down rod ball assembly into the spacing allocated in the mounting bracket and

lock the ball into place. Insert the LED driver into the lower layer of the mounting bracket and then insert the remote

receiver into the top layer of the mounting bracket. Fig. 4

2. Refer to the wiring diagram provided for Electrical Connection/installation. Fig. 5

WARNING: To prevent electrical shock or risk of fire, do not attempt to perform the electrical connection wiring

yourself. All electrical connections must be carried out by a licensed electrician.

NOTE:An additional all pole disconnection switch must be included in the fixed wiring.

3. After completing the electrical wiring at the mounting bracket terminal and connecting the remote receiver power

input wires and fixed wiring via the 4-ports quick connectors (1); connect the LED driver power input wires and

remote receiver power output wires via the 2-ports quick connectors (2); connect the LED driver PWM signal input

wires and remote receiver PWM signal output wires via the 2-ports quick connectors (3); connect the remote

receiver fan output and motor input wires via the 4-ports quick connectors (4); also connect the LED driver output

wires and LED light wires via the 2-ports quick connectors (5). Fig. 5

4. Cover the mounting bracket with the canopy cover. Ensure all electrical wirings is tucked inside the canopy and that

it is not damaged during this step, and secure with screws. Fig. 6

Fig. 4

Fig. 5

Futura Eco Installation Instructions

6 | Page

Finally attach the canopy cover to the canopy screws by turning it clockwise. Fig. 6

5. Insert the blades through the side slot of the motor and align with the 3 holes. If the holes do not align, the blade is

upside down. The blade should fit securely and the screws should slot into the blade screw holes.

Insert the screw driver with screw through the key hole of the lamp bracket. Secure the blades with 3 blade screws.

Ensure all screws are tightened evenly to reduce the chance of warping or unbalancing. Repeat this process for all

blades. Fig. 7

6. Attach the LED light kit to the lamp base and connect wires to the LED light kit via the quick connectors. Insert the

housing assembly screws into the larger ends of key hole slots and turn the LED light kit body clockwise until the

housing assembly screws are firmly situated in the narrow ends of the keyhole slots. Fig. 8

Fig. 6

Fig. 7

Fig. 8

Futura Eco Installation Instructions

7 | Page

USING YOUR CEILING FAN

REMOTE CONTROL

Your ceiling fan is controlled via the remote control. There are 4 buttons (HI, MED, LOW, OFF) to control the fan speed

and one button to control light on/off and dimming function. Fig. 11

Before operating the remote, the following must be considered.

-2 x AAA 1.5V (size) batteries are required to operate the remote control. Remove the battery cover from the

back of the remote and insert 2 x AAA batteries. Ensure the polarities are correct as shown in the battery

compartment. (Batteries not included.)

-The remote (transmitter) and receiver must be configured so that communication between each other is paired

up. This is achieved by setting the DIP switch on the receiver and remote on the same setting.

Note: The DIP switch assembly has 4 switches which can be setup to 16 different transmitting code

combinations. This is practical when there is more than 1 remote/receiver pair operating locally or in the same

room.

Note: To access the receiver DIP switches, remove the DIP switch cover.

Fig. 9 Remote battery compartment Fig. 10 Receiver DIP switch

OPERATING THE REMOTE:

Before you start using the remote, take the time to read through this section and get familiar with the buttons and

function of each button.

LED Indicator

The red LED indicator on the top of the transmitter will flash when the

buttons are active.

BUTTONS ON THE REMOTE

HI: Press the button to set fan running at High speed.

MED: Press the button to set fan running at Medium speed.

LOW: Press the button to set fan running at Low speed.

OFF: Press the button to turn OFF the fan.

: Press the button to turn ON/ OFF the light and press and hold the

button to access the light dimming function. Fig. 11

Futura Eco Installation Instructions

8 | Page

The remote has memory function. If the fan or light is turned off by the isolating switch, it will memorise and recover the

last status when turned on next.

REVERSING SWITCH

Your ceiling fan can operate in either summer or winter mode.

SUMMER Mode: The reverse switch shall be in the “down” (SUMMER) position to make the fan rotate in an

anticlockwise direction. The airflow will be directed downwards, for cooling in summer.

WINTER Mode: The reverse switch shall be in the “up” (WINTER) position to make the fan rotate in a clockwise

direction. The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in winter.

Reverse Switch

AFTER INSTALLATION

WOBBLE:

NOTE: CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON

A RUBBER GROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING IT WOULD CAUSE EXCESSIVE

VIBRATION. MOVEMENT OF A FEW CENTIMETRES IS QUITE ACCEPTABLE AND DOES NOT SUGGEST ANY

PROBLEM.

TO REDUCE THE FAN WOBBLE: PLEASE CHECK THAT ALL SCREWS WHICH FIX THE MOUNTING BRACKET

AND DOWN ROD ARE SECURE.

BALANCING KIT: A balancing kit is provided to balance the ceiling fan on initial installation. Please refer to the

instruction on how to use the balancing kit. The balancing kit can be used to assist re-balancing should the ceiling fan

become un-balanced again. Store your balancing kit away after installation for future use if required.

NOISE:

When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations and frequency

signals superimposed in the electricity for off-peak hot water control, may cause a change in fan motor noise. This is

normal. Please allow a 24-hour “settling -in” period, most noises associated with a new fan disappear during this time.

Fig. 12

Futura Eco Installation Instructions

9 | Page

The manufacturer’s warranty covers actual faults that may develop and NOT minor complaints such as hearing the

motor run – All electric motors are audible to some extent.

CARE & CLEANING

Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to avoid

scratching the paint finish. Please turn off electricity power when you do so.

Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the possibility

of an electrical shock.

The motor has a permanently lubricated ball bearing. There is no need to oil.

NOTE: Always turn off the power at the mains switch before attempting to clean your fan.

TECHNICAL INFORMATION

Futura ECO LED

SERIES models Rated

Voltage

Rated

power

(motor)

Rated power lamp Lamp type

48 inch blade fan only 220-240 VAC 60W

18W,LED Life time:

30,000H

LED Driver Model No.:

KLC-016-031A1

52 inch blade fan only 220-240 VAC 70W 18W, LED Life time:

30,000H

LED Driver Model No.:

KLC-016-031A1

WARRANTY INFORMATION

IN AUSTRALIA / NEW ZEALAND – Please refer to the separated WARRANTY STATEMENT.

IN EUROPE – If you are a European Customer Please contact the retail outlet where the fan was purchase

for warranty service.
