CEILING FAN MANUAL

INSTALLATION

OPERATION

MAINTENANCE

WARRANTY INFORMATION

LUCCI

BREEZER SERIES

CEILING FANS

CAUTION

READ INSTRUCTIONS CAREFULLY FOR SAFE

INSTALLATION AND FAN OPERATION.

Installation Instruction Manual .......................................................................................... 3

Installationsanleitung ........................................................................................................13

Guide d’installation............................................................................................................23

Manual de instrucciones de instalación.............................................................................33

Manuale delle istruzioni di installazione............................................................................43

Installatiehandleiding.........................................................................................................53

CONTENTS

Congratulations on purchasing this quality Lucci product. To ensure correct function and safety,

please read and save all instructions carefully before using the product.

The information contained in the following pages has been prepared to ensure you of trouble-

free operation of your ceiling fan .

1. This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning the use of the appliance in a safe way and understand

the hazards involved. Cleaning and maintenance shall not be undertaken by children without

supervision.

2. Children should be supervised to ensure that they do not play with the appliance.

3. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local

wiring rules.

4. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection

facilities. Contact your local government for information regarding the collection systems available.

If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into

the ground water and get into the food chain, damaging your health and well-being.

5. The structure to which the fan is to be mounted must be capable of supporting a weight of 30kg.

6. The fan should be mounted so that the blades are at least 2.3 m above the floor in Europe or 2.1

m above the floor in Australia.

7. The fan is designed for indoor use only. Mounting the fan in a situation where it is subject to water

or moisture is dangerous.

8. Only an authorized electrician should execute the installation.

CONGRATULATIONS ON YOUR PURCHASE

SAFETY PRECAUTIONS

Unpack the fan and carefully identify the parts. Please refer to Fig 1.

1. Hanger bracket (1) x 1

10. Pendant for light (10) x 1

2. Down rod with ball joint (2) x 1

11. Balance kit (11)x 1 set

3. Canopy (3) x 1

12. Wooden screws (12) x 2

4. Fan motor assembly (4) x 1

13. Flat washers (13) x 2

5. Blade holders (5) x 4

14. Spring washers (14) x 2

6. Blades (6) x 4

15. Blade mounting screw nuts (15) x 13

7. Glass (7) x 1

16. Blade mounting screws (16) x 13

8. Wall plugs for screws (8) x 2

17. Motor screws (17)x 9

9. Pendant for fan (9) x 1

BEFORE INSTALLATION

Fig. 1

The ceiling fan must be installed in a location so that the blades are at least 300mm, from the tip

of the blade, to the nearest objects or walls.

Secure the hanging bracket to A ceiling joist or structure, that is capable of carrying a load of at

least 30KG, with the two long screws provided. Ensure at least 30mm of the screw is threaded into

the support.

NOTE: The bracket screws provided are for use with wooden structures only. For structures

other than wood, the appropriate screw type MUST be used.

ANGLED CEILING INSTALLATION

This fan hanging system supports a maximum 25

degree angled ceiling installation.

INSTALLING THE MOUNTING BRACKET

Fig. 2

Fig. 3

INSTALL THE DOWN ROD

1. Loosen and remove the ball joint (1) and pins from down rod (2).

2. Feed the motor wires (4) through the down rod (2) and attach the down rod (2) to the hanger (5)

with the bolt (6) and pin (7).

3. Adjust the rocking screws (8) to ensure down rod (2) is centrally located in the hanger (5).

4. Install canopy (3) over the downrod (2).

5. Refit the ball joint (1) onto the downrod (2). Ensure all pins and screws are secure.

BLADE ATTACHMENT

1. Assemble the blades & holders using the screw set (2 and 3). (Fig. 5)

2. Secure the blade holder on the motor by using two motor screws (5) with washers to tighten it

ensuring they are tightened simultaneously. (Fig.6). Once completed, repeat the process on

remaining blades.

BLADE INSTALLATION

Fig. 4

Fig. 6

Fig. 5

1. Lift the fan assembly onto mounting bracket.

Fig.7

2. Ensure the notch of the ball joint is positioned

on the stopper of mounting bracket to prevent

fan from rotating when in operation.

LIGHT KIT Installation

1. Insert and secure the light bulbs into

the E27 sockets.

(Bulb not included)

2. Carefully place the glass shade

cover over the lamp and secure it by

the three spring clips.

WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY

A LICENSED ELECTRICIAN.

NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE

FIXED WIRING.

HANGING THE FAN

INSTALLING THE FAN

ELECTRICAL WIRING DIAGRAM

INSTALLING THE FAN

Fig. 7

Fig. 9

Fig. 8

After completing the electrical connection at the

mounting bracket terminal block, connect the ceiling fan

wiring via the quick connector plug.

Cover the mounting bracket with the canopy. Ensure all

electrical wiring is tucked inside the canopy and that

they are not damaged during this step. Secure the

canopy to the hanger bracket using the screws provided.

Fig 10.

Using the pull chain connectors (3),

connect the Fan pendant (1) to the fan

speed switch (as shown in Fig 11) and the

light pendant (2) to the light switch.

FAN SPEED CONTROL

Your ceiling fan is controlled via the fan speed

pull chain switch.

To change speeds, pull the fan speed switch 4

times, and the fan will start running at:

High speed --- Medium speed ---- Low speed-

-- Off

LIGHT ON/OFF CONTROL

Your ceiling fan is controlled via the light pull

chain switch.

To turn on/off the light, pull the light switch.

FINISHING THE INSTALLATION

USING YOUR CEILING FAN

Fig. 10

Fig. 11

Fig. 12

USING YOUR FAN WITH REMOTE

IMPORTANT NOTE: The pull chain light switch must be set to the 'on' position and the pull chain fan

switch must be set on high speed when you are using your ceiling fan with a remote.

REVERSING SWITCH

Your ceiling Fan can operate either summer or winter mode.

SUMMER Mode: The reverse switch shall be in the “down” (SUMMER) position to make the fan rotate

in an anticlockwise direction. The airflow will be directed downwards, for cooling in summer.

WINTER Mode: The reverse switch shall be in the “up” (WINTER) position to make the fan rotate in a

clockwise direction. The airflow will be directed upwards assisting in the circulation of warm air, for

energy conservation in winter.

Reverse Switch

WOBBLE:

NOTE: CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY

ARE MOUNTED ON A RUBBER GROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE

CEILING IT WOULD CAUSE EXCESSIVE VIBRATION. MOVEMENT OF A FEW CENTIMETRES IS

QUITE ACCEPTABLE AND DOES NOT SUGGEST ANY PROBLEM.

TO REDUCE THE FAN WOBBLE: PLEASE CHECK THAT ALL SCREWS WHICH FIX THE

MOUNTING BRACKET AND DOWN ROD ARE SECURE.

BALANCING KIT: A balancing kit is provided to balance the ceiling fan on initial installation. Please

refer to the instruction on how to use the balancing kit. The balancing kit can be used to assist re-

Fig. 13

AFTER INSTALLATION

balancing should the ceiling fan become un-balanced again. Store your balancing kit away after

installation for future use if required.

NOISE:

When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations

and frequency signals superimposed in the electricity for off-peak hot water control, may cause a

change in fan motor noise. This is normal. Please allow a 24-hour “breaking -in” period, most noises

associated with a new fan disappear during the time. The manufacturer’s warranty covers actual faults

that may develop and NOT minor complaints such as hearing the motor run –All electric motors are

audible to some extent.

CARE AND CLEANING

Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free

cloth to avoid scratching the paint finish. Please turn off electricity power when you do so.

Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and

create the possibility of an electrical shock.

The motor has a permanently lubricated ball bearing. There is no need to oil

NOTE: Always turn off the power at the mains switch before attempting to clean your fan.

Ceiling Fan model

Rated Voltage

Rated Power

(motor)

Rated Power

(lamp)

BREEZER

230VAC

60W

Max. 1 x 42W E27 halogen globe or

Max. 1x 15W E27 CFL spiral

IN AUSTRALIA / NEW ZEALAND – Please refer to the separated WARRANTY STATEMENT.

IN EUROPE – If you are a European Customer Please contact the retail outlet where the fan was

purchase for warranty service.

TECHNICAL INFORMATION

WARRANTY INFORMATION
