Ltech LT-995 Manuel utilisateur

www.ltech-led.com

Short circuit / Over current / Overheat protection

8 bit / 16 bit

3 kinds of DMX interfaces

CHANNELS

LT-995

Photoelectric

isolation

006

Short circuit

protection

Overheat

protection

Over current

protection

4. With RDM remote management protocol, the operations can be completed

via the RDM master console, such as parameters browsing & settings, DMX

address settings, equipment recognition, etc.

2. Easy operation with digital display and the touch buttons.

1. Designed with 5 channels output, and Max. 6A current per channel, up to

720W output power.

6. With short circuit / overheat / over current protection, as well as warning

function when a fault occurs.

9. 16bit (65536 levels) / 8bit (256 levels) grey level available.

3. 3-pin XLR, RJ45 DMX and green terminal interface with photoelectric

isolation, improve signal transmission efficiency and anti-interference

ability, the green terminal also has signal amplifier function.

Product Introduction

www.ltech-led.com

3-pin XLR RJ45 RDM

7. With fast self-testing function.

5. With firmware upgrade function.

8. High/low PWM frequency available.

Photoelectric

isolation

TechnicalSpecs

www.ltech-led.com

LT-995

DMX512/RDM

12~24Vdc

6A × 5CH Max. 30A

(0~72W...144W) × 5CH Max. 720W

3-pin XLR, RJ45, green terminal

8bit (256 levels) / 16bit (65536 levels)

Yes

Short circuit / Overheat / Over current

protection, recover automatically.

-30°C~65°C

169×80×39mm(L×W×H)

182×91×41mm(L×W×H)

550g

Model:

Input Signal:

Input Voltage:

: Current Load

Output Power:

DMX Interfaces:

Grey Level:

Photoelectric Isolation:

Protection:

Working Temperature:

Dimensions:

Package Size:

Weight (G.W.):

5-Year

Warranty

E500585

0 0 6

169

157

www.ltech-led.com

Product Size

Main Component Descripition:

Unit: mm

RJ45

3-pin XLR

Green terminal

DMX/RDM

input & output

Digital

display

Dip

switch

Green terminal

LED lamp connection

12-24Vdc

Power input

Digital display Dip switch

High Smooth

Low Std

PWM Hz DIM

Bit

Digital display will enter the locked

mode without operating after 15S.

Long press “M” key to unlock.

Short press “M” key to switch numbers.

Press “ ””v” key to adjust value.

006

Screen

30S off

Enable

PUSH

GND

DATA+

DATA-

12-24Vdc 12-24Vdc 12-24Vdc

LT-995 LT-995 LT-995

www.ltech-led.com

Wiring Diagram

LT-995 is equipped with 3 kinds of DMX terminals for

users’ selection. The following diagram takes 3-pin

XLR as an example, same connecting method for the

rest two: RJ45 & green terminal (with amplifier

function).

1. DMX console onnectionc :

DMX

console

DMX signal

DMX signal DMX signal

Resistor

terminal

If the recoil effect occurs because of longer signal line or bad line quality,

please try to connect 0.25W 90-120Ω terminal resistor at the end of each line.

LT-995

RGBWY LEDs

2 Connecting LED lights:

DMX/RDM Signal DMX/RDM Signal

12-24Vdc

LED driver

V+

www.ltech-led.com

LT-995 LT-995 LT-995

LT-995

LT-995 LT-995

LT-995 LT-995 LT-995

These 3 terminals can be connected in a mixed way.

Resistor

terminal

Resistor

terminal

Resistor

terminal

Terminal

Resistor

4. The connection diagram of AMP signal amplifier terminal:

3. The connection diagram of 3 kindsofDMX/RDM terminals:

Connecting with green terminal or an extra amplifier will be needed when more than 32

decoders are connected or use overlong signal wire (as shown below).

Signal amplifier should not be more than 5 times continuously.

AMP

LT-995

www.ltech-led.com

3-pin XLR

connected

in parallel

RJ45

connected

in parallel

Green terminal

connected

in parallel

www.ltech-led.com

LT-995

LT-995 LT-995

Work with RDM Editor

LT-995 can work with LTECH RDM editor (Model: WiFi-RDM01) to realize changing

the parameters by long-range setting, wiring diagram as below:

5-24Vdc

Power

input

WiFi-RDM01

www.ltech-led.com

RDM Editor App Interface Instructions

Download the App, setting LT-995 parameters (dimming range, brightness, boot

fade time etc.) after well connecting the RDM editor, more details, please check

the manual of WiFi-RDM01.

Well installation of products first, then working with WiFi -RDM01 to realize setting

parameters and firmware upgrade by App.

a: Click”Add”, edit the address in corresponding box.

b: Click”ID”, get more product details.

c: Click” ”, enter edited interface.

d: Click”No.”, issue the recognizing command.

WiFi-RDM01

upgrade

DMX device

upgrade

Supporting WiFi-RDM01

upgrade and DMX driver

upgrade.

Update Time: 06/01/2021_A2

Attentions

Warranty agreement

Warranty exclusions below:

No any contract signed by LTECH.

Warranty labels and barcodes have been damaged.

Damage caused by natural disasters and force majeure.

Products with severe physical damage.

Beyond warranty periods.

Warranty periods from the date of delivery : 5 years.

Free repair or replacement services for quality problems are provided within warranty periods.

Any artificial damage caused by high voltage, overload, or improper operations.

1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for

any incidental or consequential damage unless it is within the law.

2. LTECH has the right to amend or adjust the terms of this warranty, and release in written

form shall prevail.

This manual is subject to changes without further notice. Product functions depend on the goods.

Please feel free to contact our official distributors if you have any question.

Products shall be installed by qualified professionals.

LTECH products are non-waterproof (special models excepted). Please avoid the sun and

rain. When installed outdoors, please ensure it is mounted in a water proof enclosure.

Good heat dissipation will extend the working life of products. Please ensure good ventilation.

Please check if the working voltage used complies with the parameter requirements of products.

The diameter of wire used must be able to load the light fixtures you connect and ensure the

firm wiring.

Before you power on products, please make sure all the wiring is correct in case of incorrect

connection that causes damage to light fixtures.

If a fault occurs, please do not attempt to fix products by yourself. If you have any question,

please contact your suppliers.
