Ltech T4 LED RGBW Manuel utilisateur

T4 RGBW ControllerLED

2 in 1Sync/Zone

DIY Sync/Zone

Scene 3×

Touch

2.4GHz

Charging

RGBW

8 Zones

Scene-mode

RGBW

LED RGBW Controller

T4 is the 2.4GHz RF wireless sync/zone RGBW controller which adopts

4 global initiate technology. It has powerful function that general RF

remote control can’t realize, especially in wireless connection between

receivers to realize sync dynamic change effect. It is very convenient

in installation for users.

— 1 —

T4-CV T4-CC

1. Product Size:

LED RGBW Controller

Remote Remote Holder

Receiver

170mm

55mm

145mm

22mm

27mm

60mm

86mm

65mm

175mm

44mm

30mm

— 2 —

Charging Voltage:

Working Current:

Working Frequency:

RF Remote Distance:

Remote Option:

Battery Capacity:

Package Size:

Weight (G.W.):

5Vdc(Built-in lithium battery)

<30mA

2.4GHz

30m

Sync/Zone/Programming Control

1000mAh

L168×W96×H34(mm)

210g

T4 Remote

2. Technical Specs:

T4-CV Receiver

Input Voltage:

Current Load:

Output Power:

Working Temp.:

Package Size:

Weight (G.W.):

Wireless Signal:

3. Notice for the Remote Charging:

C. No memory effect in the lithium battery of remote. Follow the standard charging procedure even for the first 3 times, no need over charge.

B. The blue indicator light flickers while charging, and turns green means the charging is completed. The remote can be chargeable even at off

state, which the indicator light is dark.

A. When charging, please connect USB cable to the mobile charger or computer.

D. Red indicator light flickers meaning low battery and need to be charged. Charging in low battery will affect the life of battery.

E. the remote should be full charged and stored at a ventilated and dry place when long time no use, and please full recharge every 3 months.

Max 100W/240W/480W(5V/12V/24V)

T4-CC Receiver

5～24Vdc

5A×4CH Max 20A

-30℃～55℃

L178×W48×H33(mm)

150g

2.4GHz

Input Voltage:

Output Voltage:

Current Load:

Output Power:

Wireless Signal:

Working Temp.:

Package Size:

Weight (G.W.):

12～48Vdc

3～46Vdc

CC 350/700/1050mA×4CH

1.05W～48.3W×4CH

-30℃～55℃

L178×W48×H33(mm)

165g

Max 193.2W

2.4GHz

LED RGBW Controller

LED CONTROLLER

T4-CC

RUN

LED CONTROLLER

T4-CV

OUT PUT

R G B W V+

5. Receiver Components Description:

ID Learning Button

Running Light

Power Input Socket

Current Selection Switch

5~24Vdc

12~48Vdc

LED Lamp Connected Socket

4. The Learning ID Method:

Learning ID:

Cancelling ID:

1. Turn on the receiver and remote.

Press “ID learning button” on the receiver more than 8 seconds, the buzzer beep twice, delete all the learned remote.

2. Short press "ID learning button" on the receiver, the running light keeps on, then long press “1-8" zone-selection keys on the remote, the

running light returns to flash (the buzzer long beep, the green light flashes 3 times), activated.

Sync Control: 1 remote to unlimited receivers. Zone Control: 1 remote to Max 8 receivers ( 1 receiver per zone ).

— 3 —

(Method of operation see below form)

LED RGBW Controller

6. Remote Instructions:

ress the key and simultaneously more than 2S. P

Built-in two control programs, it is convenient for user’s different habits and place, free switching the two programs.

Sync Control

Highlights

Mode Keys : Switch black/red/green/blue/yellow/purple/cyan/white/RGB/RBGYPCW.

Open the Buzzer: Long press . Close the Buzzer: Long press .

Unmanned operation more than 1 minute on the remote, the remote will off automatically to realize zero loss, extending

operation life. Press “ON/OFF” to restart the remote.

Power Saving:

— 4 —

Control Unlimited Receivers

Synchronously.

Programmable Function.

8 Save Keys.

ress the key and simultaneously more than 2S.P

Zone Control

Highlights

Zone Control Arbitrarily or

Sync Control.

Programmable Function.

LED RGBW Controller

PWPW

A. Sync Program:

USB Charge Port

Touch Color Circle

Speed

Brightness

On/Off

Scene-save

Keys

Programming Key

White light Key

Mode

Switch Key for

Changing Modes

Sync Status

Indicator Light

The Usage of The Programming “P” :

(Jumping/Smooth )/Strobe

(Press to turn on/off the white LEDs.

Long press to adjust white LEDs)

Red

Green Blue

Blue

Yellow Cyan White Black

BlackBlackBlackBlackBlackBlack

Purple

Example 1:

Example 2:

R G B Y P C W

R B

Red

Green

Blue

Black

Example 3:

Example 4:

R BK G BK B

R G B

BK R BK G BK B

Note: Select black color with keys .

3) Short press the key to exit color selection.

5) Long press any key from “1-8" to save the edited scene.

4) Press to switch the selected colors’ Jumping, smooth and strobe

(brightness/speed adjustment).

— 5 —

7 Colors’ Jumping/Smooth/Strobe

2 Colors’ Jumping/Smooth/Strobe

5 Colors’ Jumping/Smooth/Strobe

3 Colors’ Fade out and Fade in

6 Colors’ Jumping/Strobe

enter the programming mode.

Long press the key in 2 seconds, the buzzer long beep, means

2) Color selection: Short press a key from “1-8" in order, then press

“MODE” key or “touch color circle” to select the color. (color will be

saved in this key automatically, max 8 colors)

LED RGBW Controller

B. Zone Program:

Zone-selection Keys

Zone ON/OFF Keys

Select single zone:

Press single key from “1-8".

USB Charge Port

Touch Color Circle

Speed

Brightness

On/Off

Programming Key

White light Key

Mode Keys

Switch Key for

Changing Modes

Sync Status

Indicator Light

(Jumping/Smooth )/Strobe

(Press to turn on/off the white LEDs.

Long press to adjust white LEDs)

— 6 —

Select multiple zones:

Open/Close the zone:

Press multiple keys from

“1-8" continuously.

Short press to open the zone,

Long press to close the zone. 5) OK, completed scene editing, press to play the scene.

The Usage of The Programming “P” :

enter the programming mode.

Long press the key in 2 seconds, the buzzer long beep, means

Red

Green Blue

Blue

Yellow Cyan White Black

BlackBlackBlackBlackBlackBlack

Purple

Example 1:

Example 2:

R G B Y P C W

R B

Red

Green

Blue

Black

Example 3:

Example 4:

R BK G BK B

R G B

BK R BK G BK B

Note: Select black color with keys .

3) Short press the key to exit color selection.

4) Press to switch the selected colors’ Jumping, smooth and strobe

(brightness/speed adjustment).

2) Color selection: Short press a key from “1-8" in order, then press

“MODE” key or “touch color circle” to select the color. (color will be

saved in this key automatically, max 8 colors)

7 Colors’ Jumping/Smooth/Strobe

2 Colors’ Jumping/Smooth/Strobe

5 Colors’ Jumping/Smooth/Strobe

3 Colors’ Fade out and Fade in

6 Colors’ Jumping/Strobe

LED RGBW Controller

Red

Black

Green

Blue

Yellow

Purple

Cyan

White

Red, Green, Blue

Red, Green, Blue, Yellow,

Purple, Cyan, White

Static Red

Static Green

Static Blue

Static Yellow

Static Purple

Static Cyan

Static White

RGB Jumping

7 Colors Jumping

Red fade out and fade in

Green fade out and fade in

Blue fade out and fade in

Yellow fade out and fade in

Purple fade out and fade in

Cyan fade out and fade in

White fade out and fade in

RGB color smooth

Full-color smooth

Red strobe

Green strobe

Blue strobe

Yellow strobe

Purple strobe

Cyan strobe

White strobe

RGB strobe

7 colors strobe

Press button to switch the 3 types

No.

Color

Press Button

to Switch color Strobe

Jumping Smooth

7. Tables of Changing Mode:

— 7 —

LED RGBW Controller

8. Wiring Diagram:

5-24Vdc 5-24Vdc 5-24Vdc

RGBW Strip

— 8 —

12-48Vdc 12-48Vdc 12-48Vdc

……

LED

Panel Light

LED

Panel Light

Round LED

Panel Light

LED RGBW Controller

RUN

LED CONTROLLER

T4-CV

OUTPUT

R G B W V+

RUN

LED CONTROLLER

T4-CV

OUTPUT

R G B W V+

RUN

LED CONTROLLER

T4-CV

OUTPUT

R G B W V+

LED CONTROLLER

T4-CC

RUN

LED CONTROLLER

T4-CC

RUN

LED CONTROLLER

T4-CC

RUN

350mA

700mA

1050mA

9. Other Special Functions:

Turn on the remote, long press the “on/off” key for 5 seconds until the red light flashes 3 times, and then the green light flashes, the

numbers of the green flash will be the frequency point of the remote. you can only edit the frequency point after 3 seconds.

In frequency changing state,

A. Reset Function:

B. Check and Edit the Frequency Point on the Remote:

Long press the 2 keys simultaneously, release after 3 seconds, the remote will auto off, undo for more than 1 minute, means

reset completed. and then could restart the remote.

Feature: Reset function is available when remote operates abnormally.

Operation:

b. Multiple remotes sync-control becomes available when they use the same frequency point.

Revising the frequency point to eliminate the external disturbance. 12 revisable frequency points for user.

Attn: After reset or revised the frequency points in the remote, receivers only can be used after relearn the ID.

Feature:

Check the Frequency Point on the Remote:

Edit the Frequency Point on the Remote:

Method 2: Long press “on/off” key over 5 seconds, the green light flashes, the flash times plus 1 means the frequency point accumulate 1.

In short, long press the “on/off” key over 5 seconds each time, the frequency point will accumulate 1, which will again become value 1

when added to 12, and that cycle repeats.

Method 1: Short press any key from “1-8”, the frequency point will be “1-8” correspondingly, the green light will flash in the same numbers. Then

press any key or touch the color circle to exit the frequency edit state.

— 9 —
