Lowrance HDS Gen3 Polaris Manuel utilisateur
ENGLISH
HDS Gen3 Polaris
Installation manual
polaris.com
by Lowrance
| 1
Preface
Governing Language: This statement, any instruction manuals,
user guides and other information relating to the product
(Documentation) may be translated to, or has been translated
from, another language (Translation). In the event of any
conict between any Translation of the Documentation, the
English language version of the Documentation will be the
ocial version of the Documentation. This manual represents
the product as at the time of printing. Navico Holding AS and
its subsidiaries, branches and aliates reserve the right to make
changes to specications without notice.
Copyright
Copyright © 2014 Navico Holding AS.
Warranty
The warranty card is supplied as a separate document.
In case of any queries, refer to the brand web site of your
display or system:
www.polaris.com
Compliance Statements
HDS Gen3 Polaris:
• complies with CE under R&TTE directive 1999/5/
EC
• complies with the requirements of level 2 devices
of the Radio-communications (Electromagnetic
Compatibility) standard 2008
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
The relevant Declaration of Conformity is available on the
following website, under the model documentation section:
www.polaris.com
2 |
Industry Canada
IC RSS-GEN, Sec 7.1.3 Warning Statement- (Required for license-
exempt devices)
This device complies with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur
de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Warning
The user is cautioned that any changes or modications not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent
from that of the receiver
• Consult the dealer or an experienced technician for help
| 3
About this manual
This manual is a reference guide for installing the HDS Gen3
Polaris displays.
Important text that requires special attention from the reader is
emphasized as follows:
¼Note: Used to draw the reader’s attention to a comment or
some important information.
!
Warning: Used when it is necessary to warn personnel
that they should proceed carefully to prevent risk of injury
and/or damage to equipment/personnel.
Trademarks
• Polaris® is a registered trademark of Polaris Industries, Inc.
• NMEA 2000® is a registered trademark of the National Marine
Electronics Association
• SiriusXM® is a registered trademark of Sirius XM Radio Inc.
4 |
Contents
6 HDS Gen3 Polaris overview
7 Front - controls
8 Rear - connectors
9 MicroSD card slot
10 Check the contents
11 Display Installation
11 Mounting location
11 Bracket mounting
13 Wiring
13 Guidelines
14 Power connection
17 NMEA 0183 device connection
18 Video In
19 Software setup
19 First time startup
19 Time and Date
20 Source selection
21 Device list
22 Diagnostics
23 Damping
24 Ethernet setup
26 Wi setup
30 Video In conguration
30 Software updates and data backup
33 Dimensional drawing
33 HDS-7 Gen3 Polaris
34 Accessories
34 NMEA 2000
34 Display accessories
34 Other accessories
| 5
35 Supported data
35 NMEA 2000 compliant PGN List
40 NMEA 0183 supported sentences
41 Specications
6 | HDS Gen3 Polaris overview | HDS Gen3 Polaris Installation Manual
HDS Gen3 Polaris overview
The ability to network over NMEA 2000 and Ethernet allows access
to data as well as control of numerous optional devices that can
provide audio entertainment and weather.
All displays are charting ready, with built-in high speed GPS receiver
(10Hz) and support for Polaris embedded Topo base map or Polaris
Regional HD mapping card.
The displays may be mounted to the vehicle with the appropriate
optional Polaris vehicle dash mounting kit.
The displays are intended for 12 V DC operation, though will accept
the moderate uctuations commonly seen in DC systems.
1
| 7
HDS Gen3 Polaris overview | HDS Gen3 Polaris Installation Manual
Front - controls
1
2
3
4
56
7 8
9 10
11
1 Multi-touch touchscreen
2 Pages
3 Cursor (8-way)
4 Zoom out / Zoom in (combined press = MOB)
5 Exit (X)
6 Enter
7 Menu (short press = menu, long press = hide menu bar,
double press = Settings menu)
8 Active panel
9 New waypoint (long press = nd dialogue)
10Power key (short press = system controls, long press =
power o)
11 Card reader door
8 | HDS Gen3 Polaris overview | HDS Gen3 Polaris Installation Manual
Rear - connectors
2 1 4 5 3
1 NMEA 2000 - data input / output
2 ETHERNET - high bandwidth data (Optional connection for
SiriusXM weather)
3 POWER - 12 V input & NMEA 0183. Optional video-in via
adaptor
4 SONAR - CHIRP and Broadband Sonar (Feature disabled by
default)
5 STRUCTURE - StructureScan HD sonar (Feature disabled by
default)
