Lotus ILMVX3T Manuel utilisateur

MULTIFUNCTION

ILMVX3T

INSTRUCTION MANUAL

ILMVX3T

MULTIFUNCTION

DISPLAYS AND BUTTONS

SETTING THE TIME AND DAY

SETTING THE DATE

ILMVX3T ILMVX3T

English

DISPLAYS AND BUTTONS

ENGLISH

DISPLAYS AND BUTTONS

[Features]

1. Hour, Minute and Second Hands.

2. 3:00H: 31 day calendar display.

3. 6:00H: 24 hour display

4. Retrograde Day Indicator

After the day hand reaches the last day of

the week, the hand will jump to the first day

of the week.

ILMVX3T

10:30H: Retrograde day

Date hand

Minute hand

Day hand

Retrograde

day indicator

Second hand

Hour hand

24 - hour hand

N. Normal.

1. First click position.

2. Second click position.

Crown

ILMVX3T ILMVX3T

English

DISPLAYS AND BUTTONS

Movement size 10 1/2”

Outside Diameter 24.00 mm: 21.50 mm (12H-6H) X 21.50 mm (3H - 9H)

Casing Diameter 23.30 mm: 21.30 mm (12H-6H) X 21.50 mm (3H - 9H)

Height 3.86 mm (Include battery)

Battery SR920SW

Battery Life Approx. 3 years

5. Timming of day changes.

• Thedatehandmovestothenextbetween11:00p.m.and12:00p.m.

• Thedayhandmovestothenextbetween2:00a.m.and4:00a.m.

SETTING THE TIME AND DAY

[How to Set Time and Day of the Week]

Pull crown out to the 2nd click position

when the second hand is at the 12

o’clock position.

1 2

Turnthecrownclockwisetoadvancethe

hour and minute hands until Day hand is

set to the desired day of the week.

Note: The day hand will not back by

turning the crown counterclockwise.

Pull out

2nd. position

ILMVX3T ILMVX3T

English

SETTING THE TIME AND DAY

Turn to set the time. Push crown back to normal position.

3 4

Push back

Normal position

1. Toadvancethedayhandquickly, turn back the hour and the minute hands 4 to 5

hours beyond the point of the day changes (between 11:00 p.m. and 4:00 a.m.), and

thenadvancethemagainuntilthedayhandissettothenext.

Note:Thedayhandwillnotmovebackbyturningthecrowncounterclockwise.

2. After the day hand reaches the last day of the week, turn the crown clockwise and the

hand will return to the first day of the week (retrograde day indicator).

3. The24-hourhandmovescorrespondinglywiththehourhand.

4. When setting the hour hand, check that the 24-hour hand is correctly set.

5. Whensettingtheminutehand,advanceit4to5minutesaheadofthedesiredtime

andthenturnitbacktotheexacttime.

[Advance Setting Technique]

SETTING THE TIME AND DAY

10 11

ILMVX3T ILMVX3T

English

SETTING THE DATE SETTING THE DATE

(How to Set Date]

Pull crown out to the 1st click position.

1 2 3

Push crown back to normal position.

Push back

Normal position

Turn the crown counterclockwise to set

Date hand.

Note: The date hand will not back by turning

the crown clockwise.

1. Do not set the date hand

between 9:00 p.m. and 1:00

a.m. Otherwise, it may not turn

properly.

2. While setting the date hand,

checkthatitmovesproperlyin

one-day increments.

3. It is necessary to adjust the date

on the first day after a 30-day

month and February.

[Advance Setting Technique]

ILMVX3T

Byvirtue of theregulationspursuant to the handlingof waste products derivingfrom

electronic and electrical equipment, end of lifecycle watch making products must be

selectively collected for processing. You may therefore dispose of your quartz watch

makingproductsatanyofourretailoutletsoranyotherauthorizedcollectionpoint.Theselective

collection, processing, rating and recycling of these products helps contribute to safeguarding the

environmentandprotectingourhealth.
