FEATURES

www.lorextechnology.com

CVC6941

SECURITY CAMERA

VIEW YOUR WORLD -

WITH CLARITY.

TRUE COLOR IMAGE

DAY AND NIGHT

FLEXIBLE INSTALLATION

Connects to a TV, DVR or Security Monitor

WATCH DAY OR NIGHT

Automatic Infrared light filter for accurate color reproduction in all lighting conditions

VERSATILE INSTALLATION

Install indoors or outdoors, on walls or ceilings

SEE IT ALL

•18 IR LEDs provide night vision range up to 60ft (18m)1

•True day/night operation using built-in IR filter changeable mechanism to

•achieve accurate color representation in varying lighting conditions

•Advanced day/night mode: picture automatically switches to B&W delivering better clarity in low light conditions

•Weatherproof design: ideal for outdoor and indoor applications (IP66)2

•Easy connect to any DVR, observation system, TV or VCR

•Ceiling or wall mountable

FEATURES

60ft NIGHT VISION

INDOOR/OUTDOOR

420 TVL

SIMPLE INSTALLATION

HOME BUSINESS

Standard Accurate Colors with Exclusive

Infrared Filter Technology

Standard With Anti-glare

Technology

ANTI-GLARE

COLOR REPRODUCTION

SPECIFICATIONS

PRODUCT INFORMATION

1 IR illumination range of 60ft (18m) under ideal conditions. Objects at or beyond this range

may be partially

or completely obscured, depending on the camera application.

2 Not recommended for submersion in water. Installation in a sheltered location recommended.

www.lorextechnology.com

CVC6941

As our product is subject to continuous improvement, Lorex Technology & subsidiaries

reserve the right to modify product design, specifications & prices without notice and

without incurring any obligation. E&OE.

3700 Koppers Street

Baltimore, Maryland 21227,

USA.

Lorex Technology Inc.

250 Royal Crest Court, Markham,

Ontario L3R 3S1

Canada.

1-26-052011

INSTALLATION DIAGRAM

SECURITY CAMERA

DISCLAIMERS

CVC6941: 7-78597-69410-9

Package Weight: 1.14kg / 2.5lbs

Package Dimensions:

(W x D x H)

299mm/11.8” (w) x 83mm/3.3”

(d) x 197mm/7.8 (h)

Package Cube: 0.17 Cbf / 0.005 Cbm

Contents: 1 x Camera with stand,

1 x BNC Female/RCA Male Adapter, 1

x 60ft BNC/Power Extension Cable, 1 x

12V DC Power Adapter

Image Sensor: 1/4” Color Image Sensor

Video Format: NTSC

Effective Pixels: H: 640, V: 480

Resolution: 420 TV Lines

Scan System: 2:1 Interlace

Sync System: Internal

S/N Ratio: More than 40dB

Iris: AES

AES Shutter Speed: 1/30~1/62,500 Sec

Mini Illumination: 0.6 Lux without IR LED, 0 Lux with IR LED

Video Output: Composite 1.0Vpp @ 75 ohm

Lens/ Lens Mount: 3.6m F2.0/Board Type

FOV (Diagonal): 64°

Termination: BNC Type

IR LED/ Night Vision Range: 18 pieces / 850 nm / 60ft

Power Requirement: 12V DC

Power Consumption: 170 mA or 2W max

Operating Temp Range: -10° ~ 50° C (14°F ~ 122°F)

Environmental Rating: IP 66

DIMENSIONS

4.2” /

107mm

5.2” /

132mm

2.6” /

66mm

BNC Extension cable

(included )

Terminatio n

BNC

Included

BNC/RCA Adapter

TV/

Monitor

DVR Power Power

Included

Power Adapter

Terminatio n

BNC

Camera
