LORD F5 Manuel utilisateur
User manual
Návod kobsluze
Návod na obsluhu
Freezer
Mraznička
Mraznička
F5
User manual............................................................................... page 3
Návod k obsluze ..................................................................... strana 23
Návod na obsluhu................................................................... strana 43
Safety information
3
In the interest of your safety and to ensure the correct use, before installing and first
using the appliance, read this user manual carefully, including its hints and warnings.
To avoid unnecessary mistakes and accidents, it is important to ensure that all people
using the appliance are thoroughly familiar with its operation and safety features. Save
these instructions and make sure that they remain with the appliance if it is moved or
sold, so that everyone using it through its life will be properly informed on appliance
use and safety.
For the safety of life and property keep the precautions of these user‘s instructions as
the manufacturer is not responsible for damages caused by omission.
Children and vulnerable people safety
yThis appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given super vision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
yChildren aged from 3 to 8 years are allowed to load and unload this appliance.
yChildren should be supervised to ensure that they do not play with the appliance.
yCleaning and user maintenance shall not be made by children unless they are aged
from 8 years and above and supervised.
yKeep all packaging well away from children. There is risk of suffocation.
yIf you are discarding the appliance pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the door to
prevent playing children to suffer electric shock or to close themselves into it.
ylf this appliance featuring magnetic door seals is to replace an older appliance
having a spring lock (latch) on the door or lid, be sure to make that spring lack
unusable before you discard the old appliance. This will prevent it from becoming a
death trap for a child.
General safety
WARNING! Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
WARNING! Do not use other electrical appliances (such as ice cream makers)
inside of refrigerating appliances, unless they are approved for this purpose by the
manufacture.
WARNING! Do not touch the light bulb if it has been on for a long period of
time because it could be very hot.1)
1) If there is a light in the compartment.
Safety information
Safety information
4
WARNING! When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING! Do not locate multiple portable socket-outlets or portable power
suppliers at the rear of the appliance.
yDo not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.
yThe refrigerant isobutane (R-600a) is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of environmental compatibility, which is
nevertheless flammable.
yDuring transportation and installation of the appliance, be certain that none of the
components of the refrigerant circuit become damaged.
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the appliance is situated
yIt is dangerous to alter the specifications or modify this product in any way. Any
damage to the cord may cause a short circuit, fire and/or electric shock.
yThis appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
WARNING! Any electrical components (plug, power cord, compressor and
etc.) must be replaced by a certified service agent or qualified service personnel.
WARNING! The light bulb supplied with this appliance is a„special use lamp
bulb“ usable only with the appliance supplied. This„special use lamp“ is not usable
for domestic lighting.1)
yPower cord must not be lengthened.
yMake sure that the power plug is not squashed or damaged by the back of the
appliance. A squashed or damaged power plug may overheat and cause a fire.
yMake sure that you can come to the mains plug of the appliance.
yDo not pull the mains cable.
yIf the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
yYou must not operate the appliance without the lamp.
yThis appliance is heavy. Care should be taken when moving it.
yDo not remove nor touch items from the freezer compartment if you hands are
damp/wet, as this could cause skin abrasions or frost/freezer burns.
yAvoid prolonged exposure of the appliance to direct sunlight.
1) If there is a light in the compartment.
Safety information
5
Daily use
yDo not put hot on the plastic parts in the appliance.
yDo not place food products directly against the rear wall.
yFrozen food must not be re-frozen once it has been thawed out.1)
yStore pre-packed frozen food in accordance with the frozen food manufactu re·s
instructions.1)
yAppliance’s manufactures storage recommendations should be strictly adhered to.
Refer to relevant instructions.
yDo not place carbonated of fizzy drinks in the freezer compartment as it creates
pressure on the container, which may cause it to explode, resulting in damage to
the appliance.1)
yIce lollies can cause frost burns if consumed straight from the appliance.1)
yTo avoid contamination of food, please respect the following instructions.
yOpening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
yClean regularly surfaces that can come in contact with food and accessible drainage
systems.
yClean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
yStore raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
yTwo-star frozen-food compartments (if they are presented in the appliance) are
suitable for storing pre-frozen food, storing or making ice-cream and making ice
cubes.
yOne-, two- and three -star compartments (if they are presented in the appliance) are
not suitable for the freezing of fresh food.
yIf the appliance is left empty for long periods, switch off, defrost, clean, dry and
leave the door open to prevent mount developing within the appliance.
Care and cleaning
yBefore maintenance, switch off the appliance and disconnect the mains plug from
the mains socket.
yDo not clean the appliance with metal objects.
yDo not use sharp objects to remove frost from the appliance. Use a plastic scraper.1)
yRegularly examine the drain in the refrigerator for defrosted water. If necessary,
clean the drain. If the drain is blocked, water will collect in te bottom of the
appliance. 2)
1) If there is a freezer compartment.
2) lf there is fresh-food storage compartment.
Safety information
6
Installation
IMPORTANT! For electrical connection carefully follow the instructions given in
specific paragraphs.
yUnpack the appliance and check if there are damages on it. Do not connect the
appliance if it is damaged. Report possible damages immediately to the place you
bought it. In that case retain packing.
yIt is advisable to wait at least four hours before connecting the appliance to allow
the oil to flow back in the compressor.
yAdequate air circulation should be around the appliance, lacking this leads to
overheating. To achieve sufficient ventilation follow the instructions relevant to
installation.
yWherever possible the spacers of the product should be against a wall to avoid
touching or catching warm parts (compressor, con-denser) to prevent possible burn.
yThe appliance must not be located close to radiators or cookers.
yMake sure that the mains plug is accessible after the installation of the appliance.
Service
yAny electrical work required to do the servicing of the appliance should be carried
out by a qualified electrician or competent person.
yThis product must be serviced by an authorized Service Center, and only genuine
spare parts must be used.
Energy saving
yDon‘t put hot food in the appliance;
yDon‘t pack food close together as this prevents air circulating;
yMake sure food don‘t touch the back of the compartment(s);
yIf electricity goes off, don‘t open the door(s);
yDon‘t open the door(s) frequently;
yDon‘t keep the door(s) open for too long time;
yDon‘t set the thermostat on exceeding cold temperatures;
yAll accessories, such as drawers, shelves balconies, should be kept there for lower
energy consumption.
Environment Protection
This appliance does not contain gasses which could damage the ozone layer,
in either its refrigerant circuit or insulation materials. The appliance shall not be
discarded together with the urban refuse and rubbish. The insulation foam contains
flammable gases: the appliance shall be disposed according to the appliance
regulations to obtain from your local authorities. Avoid damaging the cooling unit,
especially the heat exchanger. The materials used on this appliance marked by the
symbol are recyclable.
Safety information
7
The symbol on the product or on its packaging ,U indicates that this
product may not be treated as household waste. Instead it should be
taken to the appropriate collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling
of this product. For more detailed information about recycling of this product, please
coctact your local council, your household waste disposal service or the shop where
you putchased the product.
Packaging materials
The materials with the symbol are recyclable.
Dispose the packaging in a suitable collection containers to recycle it.
Disposal of the appliance
1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.)
WARNING! During using, service and disposal the appliance, please
pay attention to symbol similar as left side, which is located on rear of
appliance (rear panel or compressor) and with yellow or orange color.
It’s risk of fire warning symbol. There are flammable materials in
refrigerant pipes and compressor.
Please be far away fire source during using, service and disposal.
Overview
8
Electronic control plate
Freezer
Drawers
Leveling Feet
Note: Above picture in for reference only, the actual number of dravers will different from dlfferent rnodels.
Overview
Reverse Door
9
1. Remove the 2 covers.
2. Remove the 2 screws, then remove
the upper hinge that holds the door
in place. Lift the door and place it on
a padded surface to prevent it from
scratching.
3. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side. Unscrew
Note: Above pictures are for reference only.
Reverse Door
Overview
10
4. Unscrew and remove the bottom
hinge pin, tum the bracket over and
replace it.
Unscrew
Screw
5. Refit the bracket fitting the bottom
hinge pin. Replace both adjustable
feet. Screw
6. Detach the Fridge and the Freezer
door gaskets and then attach them
after rotating.
Note: Above pictures are for reference only.
