Look Solutions Tiny F07 Manuel utilisateur

Operating manual

aLook Solutions product

TINY F07

Set of Equipment supplied

–1Tiny F07

–1Powercord with push-pull plugs

–1control panel with cable

–1rechargeable battery-pack 11.1V

–1charger

–1fluid tank (50 milliliters) with quick connector and air valve

–1bottle of fluid (250 milliliter)

When the order includes a radio remote, the following items are supplied

additionally:

–1receiver with stereo jack

–1radio remote

–1manual „Radio remote control“

Please check whether all ordered products are supplied.

Contents

1. Procedure of the Tiny-Fogger 4

2. Safety Instructions 5

3. Descriptions of the parts 6

4. Fluid 8

4.1 General

5. Operating the Tiny F07 8

5.1 Selecting the Location 8

5.2 Mounting the Tiny F07 8

5.3 Starting-up the Tiny F07 9

5.4 Programming of a fixed fogging time 9

5.4.1 Programming the fogging time 9

5.4.2 Delete a fixed fogging time 10

5.5 Status Display of the battery 10

5.6 Wiring of connectors 10

6. The rechargeable Battery 11

6.1 General 11

6.2 Capacity and life time 11

6.3 Operating and Storing 11

6.4 Charging the battery-pack 11

6.5 Fuse 12

6.6 Safety Instructions 12

6.7 Technical Data 12

7. The Charger 13

7.1 General 13

7.2 Operating the Charger 13

7.3 General Notes 13

7.4 Technical Data 13

8. Service and Maintenance 14

8.1 Changing the Vaporizer 14

8.1.1 Removal of the Vaporizer 14

8.1.2 Installation of the Vaporizer 14

8.1.3 Calibrating the Vaporizer 15

8.2 The machine does not work perfectly 16

8.2.1 Status and error display 16

8.2.2 The new vaporizer cannot be calibrated 17

8.3 Care and Maintenance 17

9. Technical Data 18

10. Warranty Conditions 19

1. Procedure of the Tiny F07

The Tiny F07 is a battery-operated, microprocessor-controlled mini fog generator.

It is based (as most fog generators) on the vaporizer principle, i.e. a glycol fluid is

evaporated and condenses into fog when leaving the fog nozzle. However, the

Tiny F07 only heats when fog is actually produced.

Due to the Sleep-mode the Tiny F07 uses only 15 mA in idle status and conse-

quently it may remain connected to the the battery for several hours with no

discharging to speak of. Therefore the standby time is approx. 250 hours with a

fully charged battery.

When emitting fog a strong current of 5 to 6 A runs with peak levels of 12 to 13

The following sequence produces fog:

a) Warming up (1 second, without pumping fluid).

b) The pump runs

c) Post-run mode (15 seconds to vaporize the fluid remaining in the vaporizer).

In the post-run mode the fogging process can be started via the start button in

the lid or via the start button on the cable remote or radio remote.

2. Safety instructions

A fog machine is not a toy!

•Very hot steam escapes from the nozzle. Danger of getting burnt.

•Occasionally very hot droplets of fluid may escape when in operation.

Thus never aim at persons directly and keep a minimum distance of 3 m to the

nozzle.

•Never touch the nozzle when in operation. Danger of getting burnt.

•The location for the machine must be non-flammable, non-combustible and

not sensitive to heat. It has to be twice as big as the machine.

•Keep a minimum distance of 60 cm to all flammable, combustible objects and

objects sensitive to heat.

•Glycol is alcohol and burns with a slightly bluish, almost invisible flame. Never

point the fog at strong sources of ignition like fire or pyrotechnic effects.

•Never open the machine and leave the machine unattended when connected

to a power supply.

• The visibility has to be more than 2 m in rooms where people walk around.

•Only use the supplied TINY-FLUID. Different types of fluid do not generate the

fog you require and destroy your fog generator.

•Do not swallow the fog fluid. Keep it away from children. In case of eye contact,

rinse with a lot of water. Consult a doctor should you have accidentally

swallowed some fluid.

•Spilled fluid or splashed fluid droplets can cause slip hazard. Mop up the fluid

and dispose of it according to regulations. TINY-FLUID is completely water-

soluble and biodegradable.

•Fog may activate smoke detectors.

Artificially-made fog can be produced in many different ways. The method

used here to produce fog, with a device which works according to the vaporizer

principle, is the most harmless one.

No case has so far been reported in which a sound human being has been

harmed because of using our device to produce artificial fog. However, this can

only be guaranteed if the professional fog generators are used accordingly, i.e.

at the correct vaporization temperatures as well as with the correctly mixed fog

fluid.

We, however, recommend: People with health problems or problems of the

respiratory tract or with an inclination for allergies should avoid any contact

with artificially-made fog.

3. Description of the parts

· Start button

· Sockets for control panel

and radio remote

1: · Air slots

2: · Fog nozzle

3: · Screws to unscrew the

stainless steel hood

4: · Start button

5: · Yellow LED

3. Description of the parts

·Socket for

connecting

the battery

cable

· Connecting pins for

vaporizer

7: · Vaporizer

8: · Fluid tube

9: · Tubing spout

·Connector for

fluid tube

6: · Screws for connecting the vaporizer to

the connecting pins

10:

·Socket for connecting

the cable of the control

panel or the receiver of

the radio remote

5.1 Selecting the Location

The location for the Tiny F07 must

•be dry

•guarantee sufficient air supply

•have sufficient distance (at least 60 cm) from inflammable materials

•have very little vibration

•have an ambient operating temperature between 5°C and 45°C

•have a relative air humidity of less than 80%.

5.2 Mounting the Tiny F07

If the Tiny F07 is to be built in props or similar, make sure that a fog-free air

supply is guaranteed. Too high a fog concentration can condense inside the

machine and can result in damages caused by moisture.

When installing the Tiny F07 make sure that

•no fog is passed back into the fog generator,

•no condensed fluid runs into the apparatus,

•the air vents [1] are not covered or concealed,

• no objects jut out into the fog nozzle [2]. This may destroy the vaporizer.

5. Operating the Tiny F07

4. Fluid

The Tiny F07 is built to be used with original Look TINY-FLUID. Use of other

liquids will clog the vaporizer and void the warranty.

Please do not use Tiny-fluid if it looks blue or green. This can clog the vaporizer!

Note: If the Tiny F07 will not be in use for a long period, please empty the fluid

tank and pour the fluid back into the original fluid bottle despatched with the

unit.

4.1 General

5. Operating the Tiny F07

5.3 Starting up

a) Pour the TINY-FLUID into the fluid bottle and firmly lock the bottle. Plug the

connecting spout of the fluid tubing into the quick connector of the fluid

bottle (audible click).

Check the cleanness of the connecting spout, so that no dirt (fluff etc.) can be

sucked in by the pump. Even the smallest impurity immediately leads to clog-

ging of the machine.

b) Connect the machine and the battery-pack to the delivered cable, using the

right sockets.

c) Press the start button in the lid of the machine [4]. After approx. 1 second the

unit generates fog according to the fogging time preset by the factory.

If you would like to control the machine via the cable remote or radio remote,

connect the delivered cable for the remote or the receiver of the radio remote

to the machine. You can start the fogging process by pressing the start button

at the cable remote or radio remote.

Caution: Do not put anything into the fog nozzle. This may destroy the vaporizer

and it then has to be changed (see point 8.1)

Sleep-mode: After approx. 1 minute the Tiny F07 automatically switch to the

Sleep-mode. The yellow LED [5] does not light anymore. The machine can be

activated at any time by pressing the start button at the lid, the cable remote

or the radio remote.

5.4 Programming a fixed fogging time

For some applications it will be useful to program in a fixed fog amount, which

can be easily reproduced later.

The shortest fog time is pre-programmed. If a new fog time is programmed,

the pre-programmed fog time will be deleted.

a) Connect the battery-pack and the cable remote to the machine.

b) Press and hold the start button in the machines lid [4]. If the requested fog-

ging time is reached, press the start button at the cable remote shortly to

confirm the fogging period. Now the fogging time is saved and the start button

in the machines lid [4] can be released.

5.4.1 Programming the fogging time

5.6 Wiring of Connectors

Mini-Stereo jack plug:

Sleeve = Ground, Ring = switch on/off, Tip = 12 V DC (+) output

The microprocessor save the fogging time and this programmed fogging time

now can be recalled by pressing the start button on the cable remote or at the

transmitter of the radio remote (option) shortly as long as no new fogging period

has been programmed in.

The programmed fogging time cannot be recalled by pressing the start button

in the machines lid [4]. If the start button in the lid is pressed, the Tiny F07 will

produce fog as long as the button is hold down, no matter whether a fogging

time has been programmed in.

5. Operating the Tiny F07

The programmed fogging time can be deleted in two ways:

1) Press the start button in the machines lid [4] shortly and press the start button

on the cable remote for confirmation. The programmed fogging time is now

deleted.

2) Disconnect the machine from the battery-pack, press and hold the start button

on the cable remote and connect the machine to the battery-pack. The

programmed fogging time is now deleted.

The Tiny F07 now produces fog as long as the start button in the machines lid

[4], on the cable remote or at the transmitter of the radio remote will be pressed

and hold.

5.4.2 Delete a programmed fogging time

5.5 Battery Status Display

The yellow LED [5] at the Tiny F07 indicates (among other things (see point

8.2)) how strong/efficient the battery still is and/or when it must be recharged.

1) LED flashes slowly:

Battery capacity of 15% – 100%, the battery is fully operational

2) LED flashes fast:

Battery capacity below 15% – the battery should be changed and/or charged.

3) LED lights up permanently:

the battery is flat

Table des matières

Autres manuels Look Solutions Machine à brouillard

Look Solutions

Look Solutions Viper 2.6 Manuel utilisateur

Look Solutions

Look Solutions Cryo-Fog Manuel utilisateur

Look Solutions

Look Solutions UNIQUE 2 Manuel utilisateur

Look Solutions

Look Solutions Viper NT Manuel utilisateur

Look Solutions

Look Solutions Power-Tiny Manuel utilisateur

Look Solutions

Look Solutions Viper NT Manuel utilisateur

Look Solutions

Look Solutions Unique 2.1 Manuel utilisateur

Look Solutions

Look Solutions Tiny CX Manuel utilisateur

Look Solutions

Look Solutions Cobra 3.1 Manuel utilisateur

Look Solutions

Look Solutions Tiny FX Manuel utilisateur

Look Solutions

Look Solutions Cryo-Fog Manuel utilisateur

Look Solutions

Look Solutions Orka deLuxe Manuel utilisateur

Look Solutions

Look Solutions TINY S Manuel utilisateur

Look Solutions

Look Solutions Unique 2.1 Manuel utilisateur

Manuels Machine à brouillard populaires d'autres marques

Antari

Antari ICE Manuel utilisateur

Boost

Boost BOOST-FOG400LED-BK Manuel utilisateur

Home Accents Holiday

Home Accents Holiday FM1000-ASH Manuel utilisateur

EuroLite

EuroLite ZEITGEIST FOG-1200 Manuel utilisateur

Dyna-Fog

Dyna-Fog CYCLONE ULTRA 2734 Manuel utilisateur

PROEL

PROEL DRAGO HEAVY PLFD150HY Manuel utilisateur

Sparklyn

Sparklyn Y846 Manuel utilisateur

Magicfx

Magicfx CO2 Gun Manuel utilisateur

Ibiza

Ibiza LSM500LAS Manuel utilisateur

Antari

Antari M-5 Manuel utilisateur

Venue Lighting Effects

Venue Lighting Effects ULTRA MINI-FOGGER Manuel utilisateur

High End

High End F-100 Manuel utilisateur

Chauvet

Chauvet ARENA 2100 FLEX Manuel utilisateur

Antari

Antari X FAZER Manuel utilisateur

Beamz

Beamz F1600 Manuel utilisateur

Sagitter

Sagitter SG ARS900C Manuel utilisateur

KISANKRAFT

KISANKRAFT KK-STF-480 Manuel utilisateur

Orion

Orion OT-U250PP Mode d’emploi
