Logitech TYPE-S Manuel utilisateur
TYPE-S
Thin and light protective keyboard case
For Samsung GALAXY Tab S 10.5
Setup Guide
2
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Contents
English 3
www.logitech.com/support/type-s
3 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Know your product
12
11
8
7
9
10
1
2
5
3
6
4
1. Tablet holder
2. Protective case
3. Hook
4. Magnet
5. Function keys
6. Keyboard
7. Bluetooth/battery status light
8. Bluetooth connect button
9. On/o switch
10. Micro-USB charging port
11. Micro-USB charging cable
12. Product documentation
12
620-00xxxx.001
PDF
www.logitech.com/support/type-s
3
®
TYPE - S
Thin and light protective keyboard case
For Samsung GALAXY Tab S 10.5
4
4 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Setting up the keyboard case
Getting started
1. Open the keyboard case and push
your Samsung GALAXY Tab S 10.5
into the tablet holder:
2. Push your Samsung GALAXY Tab S 10.5
down into the hook:
3. Move the keyboard case into the typing
position by lifting the back of the
protective case and sliding the hook
forwards until it aligns with the magnet:
5 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Connecting your keyboard and tablet
The keyboard case links to your tablet
via a Bluetooth connection. The first time
you use the keyboard case, you must pair
the keyboard with your tablet.
®
®
TYPE - S
1. Turn on the keyboard:
The status light blinks blue (fast blink)
to indicate that the keyboard is
discoverable, ready for pairing with
your tablet. The first time you turn on
the keyboard it remains discoverable
for 15 minutes.
If the status light turns red,
charge the battery. For more information,
see “Charging the keyboard battery.”
2. Make sure your tablet’s Bluetooth
feature is on.
From a Home screen, touch Apps
Settings Network connections
section, and turn on the Bluetooth switch.
3. Pair the keyboard case with your tablet.
(i) In your tablet’s Bluetooth settings
page, select “TYPE-S” in the list of
Available devices.
(ii) When prompted, enter the PIN
displayed using the case keyboard.
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.
6 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Connecting to another tablet
1. Make sure the keyboard is turned on.
2. Make sure your tablet’s Bluetooth
feature is on.
From a Home screen, touch Apps
Settings Network connections
section, and turn on the Bluetooth switch.
3. Press the Bluetooth Connect button:
®
The status light blinks blue (fast blink)
to indicate that the keyboard is
discoverable, ready for pairing with
your tablet. The keyboard is discoverable
for 3 minutes.
4. Pair the keyboard case with your tablet.
(i) In your tablet’s Bluetooth settings
page, select “TYPE-S” in the list of
Available devices.
(ii) When prompted, enter the PIN
displayed using the case keyboard.
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.
7 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Using the keyboard case
Two viewing positions
The keyboard case provides two viewing
positions—one for typing and another
for browsing.
To type:
1. Move the tablet holder into the typing
position, aligning it with the built-in
magnet to secure it:
2. Turn on the keyboard:
If the status light turns red,
charge the battery. For more information,
see “Charging the keyboard battery.”
If you don’t use the keyboard for a while in
the typing position, it enters sleep mode
automatically. Pressing any key wakes it.
To browse, place the tablet holder in the
browsing position:
You can switch o the keyboard if you want
to conserve battery power.
Typing position
Browsing position
8 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Status light indicators
Bluetooth and battery status light
Light Description
Blinking green The battery is charging.
Green The battery is charged (more than 10%).
Red Battery power is low (less than 10%). Recharge the battery.
Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.
Slow: The keyboard is trying to reconnect to your Samsung
GALAXY Tab S 10.5.
Solid blue Bluetooth pairing or reconnection is successful.
9 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Function keys
FN + Back: Esc
FN + 1: Lock screen
Lock or unlock the tablet screen
FN + 2: Web browser
FN + 3: Mail
31
FN + 4: Calendar
FN + 5: Music
FN + 6: Previous track
FN + 7: Play/Pause
FN + 8: Next track
FN + 9: Mute
FN + 0: Volume down
FN + -: Volume up
FN + =: Print Screen
FN + Backspace: Forward delete
FN + Tab: Show all apps
FN + Caps Lock:
Quick panel/Notifications
FN + X: Cut
FN + C: Copy
FN + V: Paste
FN + Left cursor: Home
FN + Right cursor: End
FN + Up cursor: Page Up
FN + Down cursor: Page Down
FN + Search: Voice search
Use your voice to send messages,
make calls, and more
FN + Right Alt: Android™ menu
FN + Android home: Switch
applications
FN + spacebar: Switch language
Note:
• To select a function key, press and hold the FN key, and then press the key indicated above.
10 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Charging the keyboard battery
If the status light is red the keyboard case
battery needs to be charged.
1. Plug one end of the micro-USB cable
into the charging port, and the other end
into a USB port on your computer.
The status light blinks green as
the battery charges.
2. Charge the battery until the status light
turns solid green.
Battery information
• A fully charged battery provides about
three months of use when the keyboard
is used about two hours a day.
• Charge the battery if the status light
turns red briefly after the keyboard turns
on.
• When not in use, turn o the keyboard
to conserve battery power.
• The keyboard enters sleep mode
automatically if not used for a while
in the typing position. Press any key
to wake it.
USB
