Logitech QuickCam Sphere AF Manuel utilisateur
Logitech®
QuickCam®Sphere AF
User’s Guide
2QuickCam®Sphere AF
Contents
English..................................................................... 3
Deutsch ................................................................... 12
Français ................................................................... 21
Italiano....................................................................30
Español....................................................................39
Português .................................................................48
Nederlands................................................................ 57
Svenska....................................................................66
Dansk..................................................................... 75
Norsk .....................................................................84
Suomi..................................................................... 93
Ελληνικά ..................................................................102
По-русски .................................................................111
Magyar120
Česká verze 129
Po polsku 138
3QuickCam®Sphere AF
1 Camera Features English
Thank you for purchasing your new Logitech®QuickCam®Sphere AF with Carl Zeiss optics
and autofocus. This guide will help you install and get the best performance from your webcam.
Camera
Activity light
Microphone
Carl Zeiss
optics with
autofocus
9’’ (22.9cm) eye-level stand
USB cable
4QuickCam®Sphere AF
Camera bottom Stand top
Base top Stand bottom
Line up connectors
Line up connectors
Incorrect
Correct: Hold base
and stand to move camera.
2 Using the camera stand
Remove the camera from the base.
Connect the stand to the base. Carefully use the alignment features to connect the stand easily
to the base.
Connect the camera to the stand. Carefully line up the connectors on the stand with the connectors
on the camera.
Do not carry the camera by the stand. The base could detach from the stand, and the base
could get damaged if it were to hit the floor. Move the unit by holding on to the base and stand at
the same time.
1.
2.
3.
4.
5QuickCam®Sphere AF
3Install the Software First
Insert the installation CD into your
CD-ROM/DVD-ROM drive. Your CD
should start automatically. If it does not,
follow the steps below:
Double-click the My computer icon.
Alternatively, click Start My computer.
Right-click the CD-ROM/DVD-ROM
drive icon, and then click Autoplay.
•
•
Install the software
before
plugging in the camera. Many of your camera’s extended features,
including autofocus, will not operate properly without the complete software installation.
4Connect Your Camera to Your Computer
Wait until you are prompted by the software before
connecting your camera to an available USB port on
your computer.
6QuickCam®Sphere AF
5Position Your Camera, Microphone,
and Speakers
Your camera comes with Logitech®RightSound™Technology.
RightSound™Technology cancels echo and significantly reduces
background noise. The following steps will ensure the best
possible audio performance:
Tabletop Placement. The camera can be placed on
a tabletop next to your computer monitor. Use the camera
on its base, or use the stand to raise the camera to your eye
level.
Monitor Placement. If there is a flat, stable surface on top
of your monitor, place the camera on the base in the middle
of your monitor for optimal eye contact. You don’t need
to use the stand on your monitor.
Camera Rotation. Do not manually rotate the camera on
the base or on the stand. You could damage the camera.
Use your mouse or keyboard to pan and tilt the camera.
Or activate face-tracking for automatic camera movements.
Position your camera’s microphone no more than 3 feet
(1 m) away from you and point it toward you.
Position your speakers (if used) at least 12 inches (30 cm)
away from your microphone to reduce feedback,
and then angle your speakers away from your microphone.
•
•
•
•
•
Tip Do not place objects
between you and
the microphone.
7QuickCam®Sphere AF
6The Audio Tuning Wizard
The first time that you start QuickCam, you are guided
through the Microphone/Speaker Setup Utility and Audio
Tuning Wizard that lets you do the following:
Select the audio input device (microphone)
and audio output device (speakers).
Enable Acoustic Echo Cancellation (AEC)—
recommended.
Enable background suppression—recommended.
Specify microphone input volume and speaker
output volume.
Test audio settings.
In situations with loud and irregular background noise,
your voice can become distorted when using noise
suppression. If this occurs, disable noise suppression in
the QuickCam®software.
Tip To change your audio settings in the QuickCam®
software, click the Settings button,
and then click the Audio tab.
•
•
•
•
•
8QuickCam®Sphere AF
Your camera is now set up and ready to go!
There are many ways to enjoy using your new webcam, including
Making free video calls to friends and family. (Installation and use of an instant messaging application
is required. Click in the QuickCam®software to learn more.)
Taking still photos or recording videos to share or e-mail.
Adding videos to your E-bay auctions (see www.logitech.com/videosnap).
•
•
•
7Congratulations
To start the Logitech®QuickCam®software, do either of the following:
On your desktop, double-click the QuickCam®icon.
- or-
In the lower-right corner of your desktop in the taskbar, click the QuickCam®icon.
•
•
8Using the QuickCam®Software
9QuickCam®Sphere AF
Tip To personalize your video calls with customized Avatar images, Face Accessories, or Fun Filters,
click the Video Effects button.
Record videos or capture images.
Enable Logitech Video Effects.
Enable Audio & Video Mute (when on a video call).
Specify camera settings.
Install and use video programs and services.
9 QuickCam®Software Features
The autofocus system will ensure that images as close as 10 cm to the camera will be put in focus,
automatically. If you wish to control the lens focus manually, switch to manual mode in ‘‘autofocus’’ controls on
the Settings tab of the QuickCam®software.
10 Using Autofocus
10 QuickCam®Sphere AF
Logitech®RightLight™2 ensures that you automatically get the best image quality in harsh, dim, or back lit
conditions that usually cast a shadow on your face. When your camera determines that you are experiencing
these situations, a dialog box appears asking if you want to turn on Logitech®RightLight™2. Click Yes to let
your camera automatically adjust frame rates, color, and exposure to produce the best image quality.
To manually adjust these settings, click the Settings button.
11 Ensure Quality Images
Audio Information. Go to http://www.logitech.com/rightsound.
Software Updates. Go to http://www.logitech.com/support.
Additional Help. Launch the software and click the Help button.
To learn more about Logitech®products, go to http://www.logitech.com.
UL Testing. Your product is UL tested and should only be used with other UL listed devices.
Compliance. For compliance information, go to http://www.logitech.com/compliance.
12 For More Information
