Lochinvar POWER-FIN PB/PF 1501 Guide d'application

Replacement Parts List

Power-Fin®

Heating Boilers &

Hot Water Supply Boilers

PB/PF 1501, 1701, 2001

PBX-PFX-RP-06

PARTS & SERVICE DEPARTMENT

Nashville, Tennessee

615-889-8900 • Fax: 615-547-1000

www.Lochinvar.com

41 38

HEAT EXCHANGER ASSEMBLY

2 of 4

PBX-PFX-RP-06

GAS TRAIN ASSEMBLY

CONTROL PANEL

ITEM NO. PART NO. DESCRIPTION MODEL NO.

CONTROLS

1 FAN3719 FAN REPLACEMENT ASSEMBLY PB/PF1501-2001

2 PRS30002 SWITCH, PRESSURE BEFORE D08 PB/PF1501-2001-M9

2 PRS20008 SWITCH, PRESSURE AFTER D08 PB/PF1501-2001-M9

2 PRS30003 SWITCH, PRESSURE BEFORE D08 PB/PF1501/2001-B9

2 PRS20009 SWITCH, PRESSURE AFTER D08 PB/PF1501/2001-B9

2 PRS30004 SWITCH, PRESSURE BEFORE D08 PB/PF1701-B9

2 PRS20012 SWITCH, PRESSURE AFTER D08 PB/PF1701-B9

3 RLY2114 CONNECTION BOARD ALL

PLEASE HAVE MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.

3 of 4

PBX-PFX-RP-06

ITEM NO. PART NO. DESCRIPTION MODEL NO.

CONTROLS CONTINUED

4 RLY2210 BOARD, CONTROL, USER INTERFACE ALL

5 RLY2100 BOARD, CONTROL, MAIN ALL

6 RLY2706 RELAY, PUMP ALL

7 RLY2105 RELAY, 24VAC COIL ALL

8 SWT2006 SWITCH, ON,OFF ALL

9 HLC2702 HIGH LIMIT MANUAL RESET ALL PB

9 HLC2701 HIGH LIMITAUTO RESET ALL PB

10 GTP2900 GAUGE, TEMPERATURE AND PRESSURE ALL PB

11 RLV2003 VALVE, PRESSURE RELIEF, 1", 50# PB1501/1701

11 RLV2001 VALVE, PRESSURE RELIEF, 3/4", 50# PB2001

11 RLV2016 VALVE, T & P RELIEF, 1", 150# All PF

12 WTR2040 SWITCH, FLOW ALL

GAS TRAIN ASSEMBLIES

13 BNR3717 MAIN BURNER ASSEMBLY PF/PB1501

13 BNR3718 MAIN BURNER ASSEMBLY PF/PB1701

13 BNR3719 MAIN BURNER ASSEMBLY PF/PB2001

14 MSC2731 SIGHT GLASS, 1/2" ALL

15 PLT3400 IGNITOR, HOT SURFACE KIT ALL

16 GKT2012 GASKET, IGNITER ALL

17 GKT2058 GASKET, BURNER,FAN ALL

37 GKT2056 GASKET, BURNER ALL

18 VAL3414 GAS VALVE ASSEMBLY, NAT PF/PB 1501

18 VAL3415 GAS VALVE ASSEMBLY, NAT PF/PB 1701

18 VAL3416 GAS VALVE ASSEMBLY, NAT PF/PB 2001

18 VAL30022 GAS VALVE ASSEMBLY, LP PF/PB 1501

18 VAL30023 GAS VALVE ASSEMBLY, LP PF/PB 1701

18 VAL30024 GAS VALVE ASSEMBLY, LP PF/PB 2001

19 VAL2160 VALVE, VENTURI PF/PB1501-1701

19 VAL2127 VALVE, VENTURI PF/PB2001

20 GKT2057 GASKET FAN, VENTURI ALL

21 GKT2050 GASKET, GAS TRAIN ALL

22 VAL2951 VALVE, BALL, 1.5" ALL

23 TFL2088 FLANGE, GAS 1 1/4" NPT ALL

HEAT EXCHANGERS

24 WTR4708 FLANGE ALL

25 GKT2006 GASKET, TOP HEADER FLANGE 1/4" ALL

25 GKT2019 GASKET, TOP HEADER FLANGE 1/8" ALL

26 HEX3060 HEAT EXCHANGER (HLW) PF1501

26 HEX3061 HEAT EXCHANGER (HLW) PF1701

26 HEX3062 HEAT EXCHANGER (HLW) PF2001

26 HEX3068 HEAT EXCHANGER (H) PB1501

26 HEX3069 HEAT EXCHANGER (H) PB1701

26 HEX3070 HEAT EXCHANGER (H) PB2001

27 DRV3801 DRAIN VALVE KIT ALL

PLEASE HAVE MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.

02/11 - Printed in U.S.A.

4 of 4PBX-PFX-RP-06

ITEM NO. PART NO. DESCRIPTION MODEL NO.

MISCELLANEOUS

28 TST2300 BULBWELL, EMMEN CONTROL ALL

29 TST2306 BULBWELL, HIGH LIMIT ALL

30 JKH2012 V-BAFFLE, HEAT EXCHANGER (24) PF/PB1501

30 JKH2013 V-BAFFLE, HEAT EXCHANGER (24) PF/PB1701

30 JKH2014 V-BAFFLE, HEAT EXCHANGER (24) PF/PB2001

31 JKH6431 RETAINER, V-BAFFLE ALL

32 FIL2000 FILTER,AIR, HEAVY DUTY ALL

33 FAN2027 FAN,VENTILATION ALL

34 MSC2975 CONDENSATE TRAP ALL

35 TST2032 THERMISTOR SENSOR ALL

36 BRS2404 3/4 X 3/8 BRASS BUSHING ALL

- KIT3115 OUTDOOR AIR SENSOR ALL

- TST3012 FLUE SENSOR ALL

- MSC2933 ALUMINUM TUBING (Order by the foot) ALL

- TUB8000 TUBING, EPDM 3/8" (Order by the foot) ALL

PUMPS

- ARM3077PAB PUMPASSEMBLY PF

JACKET/DOOR ASSEMBLIES

37 JKH40015 JACKET TOP, WITHOUT VENTILATION FAN ALL

38 JKH6914 JACKET, OUTER FRONT UPPER LEFT ALL

39 JKH6936 JACKET, OUTER FRONT LOWER PF/PB1501

39 JKH6937 JACKET, OUTER FRONT LOWER PF/PB1701

39 JKH6938 JACKET, OUTER FRONT LOWER PF/PB2001

40 JKH5073 JACKET, OUTER RIGHT PF/PB1501

40 JKH5074 JACKET, OUTER RIGHT PF/PB1701

40 JKH5075 JACKET, OUTER RIGHT PF/PB2001

41 JKH6939 JACKET, OUTER LEFT PF/PB1501

41 JKH6940 JACKET, OUTER LEFT PF/PB1701

41 JKH6941 JACKET, OUTER LEFT PF/PB2001

INSULATION

- FIB2119 INSULATION, SIDES PF/PB1501

- FIB2120 INSULATION, SIDES PF/PB1701

- FIB2121 INSULATION, SIDES PF/PB2001

- FIB2269 INSULATION, BACK PF/PB1501

- FIB2270 INSULATION, BACK PF/PB1701

- FIB2271 INSULATION, BACK PF/PB2001

- FIB2106 INSULATION, FRONT PF/PB1501

- FIB2107 INSULATION, FRONT PF/PB1701

- FIB2108 INSULATION, FRONT PF/PB2001

- FIB2109 INSULATION, FRONT DOOR PF/PB1501

- FIB2110 INSULATION, FRONT DOOR PF/PB1701

- FIB2111 INSULATION, FRONT DOOR PF/PB2001

PLEASE HAVE MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
