KNIGHT®FLOOR STANDING AND WALL MOUNT HEATING BOILERS

KNIGHT

HEATING BOILER

Submittal Sheet

KBN-Sub-09

JOB NAME ______________________________________________________________________

LOCATION ______________________________________________________________________

ARCH./ENGR.____________________________________________________________________

WHOLESALER __________________________________________________________________

MECH. CONTRACTOR ___________________________________________________________

MODEL NO. _____________________________________________________________________

TYPE GAS ______________________________________________________________________

Btu/hr INPUT_____________________________________________________________________

Btu/hr OUTPUT___________________________________________________________________

NOTES

Standard Features

>Energy Star®Qualified

> Up to 96% DOE AFUE Efficiency

> Modulating Burner with 5:1 Turndown

> Direct-Spark Ignition

> Low NOx Operation

> Field Convertible from Natural to LP Gas

> Vertical & Horizontal Direct-Vent

> PVC, CPVC or SS Venting up to 100 Feet

> Factory Supplied Sidewall Vent Termination

> ASME Stainless Steel Heat Exchanger

> Automatic Reset High Limit

> Inlet & Outlet Temperature Sensors

> Boiler Circulating Pump

> 30 psi ASME Relief Valve

> Adjustable Leveling Legs (KB Models only)

> Wall Mount Bracket (WB Models only)

> Zero Clearances to Combustible Material

> 12 Year Limited Warranty (See Warranty for Details)

SMART SYSTEMTM Features

> SMART SYSTEM Digital Operating Control

> 2 line, 16 Character Display

> Dual Level Password Security

> Domestic Hot Water Prioritization

> Built in Cascading Sequencer for up to 8 Boilers

> 0-10 VDC Input Control

> Outdoor Reset Control with Outdoor Air Sensor

> Low Water Flow Safety Control & Indication

> Alarm on Any Failure Contacts

> Service Reminder

> Freeze Protection

> Night Setback

> Time Clock

> Three Pump Control (System, Boiler & DHWP)

> Data Logging

> Examples: Hours Running, Space Heating

> Programmable System Efficiency Optimizers

> Examples: Anti-cycling, Ramp Delay

Optional Equipment

Place an X in the box by all options that apply

Adjustable High Limit w/ Manual Reset

Flow Switch

Low Water Cutoff w/Manual Reset & Test

Alarm Bell

Concentric Vent Kit

Condensate Neutralization Kit

SMART SYSTEM PC Software

Multi-Stack Frame

Firing Codes

M9 Standard Construction

M7 California Code

Lochinvar Corporation • 300 Maddox Simpson Pkwy • Lebanon, TN 37090 • 615-889-8900 / Fax: 615-547-1000

www.Lochinvar.com

5/09—Printed in U.S.A.

KNIGHT Heating Boiler and Wall Mount Dimensions & Specifications

KNIGHT Heating Boiler Dimensions & Specifications

Models:

KBN80-210

Models:

WBN50-210

Models:

KBN285

Input Heating NET

Model Min Max AFUE Capacity I=B=R Gas Water Air Vent Shipping

Number MBH MBH % MBH MBH A C D E F G H I J K M Conn. Conn. Inlet Size Weight

WBN050 10 50 95.3 45 39 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 2" 6-3/4" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 130

WBN080 16 80 95.3 72 63 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 2" 6-3/4" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 130

WBN105 21 105 95.4 94 82 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 3-1/2" 5-1/2" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 134

WBN150 30 150 95.5 135 119 29-1/4" 20-3/4" NA 15-3/4" 8-1/2" 3-1/2" 5-1/2" NA 8-3/4" 9-3/4" 1-1/2" 1/2" 1" 3" 3" 162

WBN210 42 210 95.7 190 165 29-1/4" 25" NA 20" 12" 3-1/2" 5-1/2" NA 13" 14" 1-1/2" 1/2" 1" 3" 3" 177

KBN080 16 80 95.3 72 63 33-1/4" 14" 7" 5-3/4" 5" 3" 20-1/2" 22" 1-3/4" 6-1/2" NA 1/2" 1" 3" 3" 125

KBN105 21 105 95.4 94 82 33-1/4" 14" 6-1/2" 5-3/4" 4-1/2" 1-1/2" 20-1/2" 22" 1-3/4" 6-1/2" NA 1/2" 1" 3" 3" 129

KBN150 30 150 95.5 135 119 33-1/4" 18" 12-1/4" 11-1/2" 10" 1-1/2" 21-1/4" 23" 1-3/4" 12" NA 1/2" 1" 3" 3" 157

KBN210 42 210 95.7 190 165 33-1/4" 22-1/4" 16-1/2" 15-3/4" 14-1/4" 5-1/4" 21-1/4" 23" 1-3/4" 16-1/4" NA 1/2" 1" 3" 3" 172

KBN285 57 285 96.0 260 226 42-1/2" 19-3/4" 12-3/4" 13-1/2" 6" 2" 34" 31" 11-3/4" 4-1/4" NA 3/4" 1-1/4" 4" 4" 224

Notes: Performance data based on manufacturer’s test results. Indoor installation only. All information subject to change. Change “N” to “L” for LP gas models.
