Linksys WAP2000 Manuel d'utilisation
BUSINESS SERIES
PRODUCT DATA
Model: WAP2000
Wireless-G Access Point
with Power over Ethernet
RangeBooster Wireless Access Point
Solution
The WAP2000 is a Wireless Access Point ideal for small businesses that want to
expand their existing wired networks or create new wireless networks for the
workforce or guests. It features RangeBooster technology that is compatible to
standard 802.11g but with a range up to two times farther and throughput by up to
35% faster. Unlike ordinary wireless technologies that are hampered by wireless signals
that reflect off walls, ceilings, and other objects, RangeBooster uses these multiple
signals with two smart receivers at each end (router or access point and client adapter)
to boost range and throughput speeds. As a result, a RangeBooster solution reduces or
eliminates wireless signal deadspots in offices and other buildings so users can connect
to the network in more areas. The WAP2000 comes with 3 dBi antennas for increased
power, also helping to extend the range of the Access Point.
Advanced security features like Wi-Fi Protected Access™ (WPA2 Enterprise), make this
solution ideal for your business. Integrated Quality of Service (QoS) features provide
consistent voice and video quality on both the wired and wireless networks, enabling your
workforce to communicate or view video content without disruptions and delay.
The WAP2000 can be powered from its included AC adapter or from a Power over Ethernet
(PoE) Switch via Ethernet cabling enabling mounting in ceilings or high on walls where
power outlets may not be available.
Additional features like Multiple BSSIDs, Wireless Roaming, Auto-Channel Selection, and Load
Balancing give your business added flexibility to keep employees and guests connected. The
WAP2000 also features dual firmware images so it remains functional if a firmware upgrade
process is disrupted.
Linksys Business Series WAP2000 Access Point is Linksys One Ready. That means it includes the
necessary firmware to be seamlessly integrated into a Linksys One data or data/voice network.
Once connected, a Linksys One Service Router will discover the WAP2000 device, automatically
configure it and make it available to other users on the network. Linksys One technology is
automatic and self-configuring.
Standards-based PoE (IEEE
802.3af) or External DC
power
RangeBooster technology
for up to twice the range,
reduced dead spots,
and up to 35% more
throughput than standard
802.11g.
Advanced wireless security
using Wi-Fi Protected
Access™ (WPA2) with up
to 256-bit encryption
and Support for WMM
provides improved QoS
over wireless connections
for better video and voice
performance.
Linksys One Ready for
instant integration into a
Linksys One network.
WAP2000
PRODUCT DATA
BUSINESS SERIES
Features
10BASE-T/100 BASE-TX
Ethernet Port, Autosensing
half/full duplex & MDI/MDI-X
Full backwards compatibility
with 802.11b
Easy installation and
configuration Web Interface
Dual images for resilient
firmware upgrades
Supports WEP,WPA-PSK,
WPA2-PSK,WPA-ENT, WPA2-
ENT authentication (802.11i
ready)
SMA detachable Dipole
antennae with 1x2 MIMO to
increase coverage
Supports Power over
Ethernet (PoE) or external
DC power
Supports 4 BSSID and
802.1Q VLAN to SSID
mapping
Supports SNMP and
intuitive Web-based
interface
WMM wireless QoS support
- upgradeable to 802.11e
Supports wireless roaming
based on 802.11F (IAPP)
Supports AP, Bridge Mode
and Repeater mode
Supports wireless client
isolation
Metal casing
3 year limited warranty
Linksys One Ready - Simple,
one-step automated
installation and initial
configuration
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Wireless-G Access Point with Power over Ethernet
Specifications
Model WAP2000
Standards IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u,
IEEE802.3af (Power over Ethernet), 802.1p (QoS priority), 802.1Q (VLAN),
802.1X (Security Authentication), 802.11i - Ready (Security WPA2),
802.11e - Ready (Wireless QoS), 802.11F (Wireless Roaming)
Ports 10BASE-T/100BASE-TX Ethernet, 12VDC Power
Buttons Reset
Cabling Type UTP CAT 5
LEDs Power, PoE, Wireless, Ethernet
Operating System Linux
Setup/Config
WebUI Built-In Web UI for Easy Browser-Based Configuration (HTTP/HTTPS)
Management
SNMP Version SNMP Version 1, 2c, 3
Event Logging E-Mail Notification
Remote Syslog
Web F/W upgrade Firmware Upgradeable Through Web-Browser
Diags: Flash, etc. Diags: Flash, RAM, LAN, WLAN
DHCP DHCP Client
Operating Modes
Access Point Access Point Mode, Point-to-Point Bridge Mode,
Point-to-Multipoint Bridge Mode, Repeater Mode
Wireless
Spec/Modulation Radio and Modulation Type: 802.11b/DSSS, 11g/OFDM
Channels Operating Channels: 11 North America, 13 Most of Europe
(ETSI and Japan)
# of Internal Ant. None
# of External Ant. 2 (Omnidirectional) 3dBi SMA Detachable
Transmit Power Transmit Power (Adjustable) @ Normal Temp Range:
11b - 18 dBm; 11g - 16 dBm
Antenna Gain in dBi 3
Receiver Sensitivity 11.g: 54Mbps@ -72dBm, 11.b: 11Mbps@ -85dBM
Security
WEP/WPA/WPA2 WEP 64bit/128bit, WPA-PSK, WPA2-PSK, WPA-ENT, WPA2-ENT
Access Control Wireless Connection Control: MAC-Based
SSID Broadcast SSID Broadcast Enable/Disable
802.1X IEEE 802.1X Support
Wireless Client Isolation Wireless Client Devices can be Isolated from Each Other Either Within an
SSID or Between Two SSIDs
Quality of Service
QoS 4 Queues
WMM Wireless Priority
General
Wireless Roaming based on IAPP
Load Balancing
Auto-Channel Selection
PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
Web: www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world. For a complete list of local
Linksys Sales and Technical Support
contacts, visit our worldwide website
at www.linksys.com
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc. All rights reserved. Other brands
and product names are trademarks or registered trademarks of their respective holders.
7081610NC-RR Model: WAP2000
Environmental
Dimensions 8.66" x 6.69" x 1.50" (220 x 170 x 38 mm)
Weight 1.69 lb (0.765 kg)
Power 12V 1A DC input, and IEEE802.3af Compliant PoE
Max Power Draw: 3.48W
Certification FCC, ICES-003, CE
Operating Temp. 14 to 131ºF (-10 to 55ºC)
Storage Temp. -22 to 158ºF (-30 to 70ºC)
Operating Humidity 10 to 90%, Noncondensing
Storage Humidity 5 to 95%, Noncondensing
Package Contents
Wireless-G Access Point with Power over Ethernet
2 x SMA Detachable Dipole Antenna (3 dBi)
User Guide on CD-ROM
Quick Installation Guide
Ethernet Network Cable
Power Adapter
Registration Card
Minimum Requirements
802.11b, 802.11g Wireless Adapter with TCP/IP Protocol Installed Per PC
Switch/Router with Power over Ethernet (PoE) Support Or PoE Injector when used with PoE
Web-Based Configuration: Java-Enabled Web Browser
•
•
•
•
•
•
•
•
•
•
