esigned for small-to-medium business (SMB)

and home networking, these EtherFast 10/100

Network in a Box kits each contains all you

need to build a 10/100 network, with the best value for

your networking dollar. Ideal for sharing high-speed

cable or DSL Internet access, these starter kits come

with two 10/100 auto-sensing PCI LAN Cards and a 5-

Port 10/100 auto-sensing Switch or Hub that delivers up

to a blazing 200Mbps data transfer.

Plus, your EtherFast 10/100 PCI Cards support Wake-

on-LAN management and full duplex transfer mode,

while your 10/100 hub or switch expands your network

easily with its built-in uplink port. These kits work with

virtually all network operating systems, including Linux

and Windows NT, so you don’t have to worry about

compatibility issues. If you're looking for top perform-

ance, your EtherFast 10/100 auto-sensing network will

seamlessly integrate with 10 and 100Mbps hardware, so

you can enjoy the speed and power of networking for

years to come.

•Connects Up to 5 Computers Together at

10Mbps, 20Mbps, 100Mbps, or 200Mbps Speed

•Each 10/100 Port Automatically Adjusts to

10BaseT or 100BaseTX Speeds in both Half or

Full Duplex Transfer Mode

•Perfect for Sharing a Cable Modem, DSL, or

Any Other Internet Access With all Your PCs

•5-Port 10/100 Switch Delivers Full-Duplex

200Mbps Dedicated Bandwidth to Each Port

•Wake-On-LAN Compatible PCI LAN Cards

•LAN Cards are Fully Backwards Compatible

with Non-Wake-On-LAN Motherboards

•Windows 95 and 98 Plug-and-Play Compatible

•Works with All Major Networking Operating

Systems, including Windows NT 4.0 and Linux

•Easily Expandable --Connect to More Hubs,

Switches and PCs with the Built-in Uplink Port

•Lifetime Warranty on LAN Cards and Cables

•5-Year Limited Warranty on Switches and Hubs

•Optimal Value for Versatile 10/100

Auto-Sensing Networking at Blazing Speeds

• Perfect for Sharing High-Speed Cable or DSL

Internet Access Among AllYour PCs

•10/100 Auto-Sensing Hub or Switch

Seamlessly Integrates 10 and 100Mbps

Hardware

•Two 10/100 PCI LAN Cards Feature a 10/100

RJ-45 Port and Wake-On-LAN Support

•Kit Contains AllYou Need to Build a

10/100 Auto-Sensing Network

•Works with Virtually All Operating Systems,

Including Linux and Windows NT 4.0

•Free 24/7 Technical Support

EEtthheerrFFaassttSSwwiittcchheedd1100//110000NNeettwwoorrkkiinnaaBBooxx

((FFEESSWWSSKK55))

EEtthheerrFFaasstt1100//110000NNeettwwoorrkkiinnAABBooxx

((FFEENNSSKK0055))

EverythingYou Need to Get the Highest in 10/100

Network Performance for the Best Value

Features

Benefits

HotPerformance!

BestValue!

EtherFast®10/100

Network in a Box

Two10/100FastEthernetKitstoChooseFrom!

Specifications

Standards IEEE 802.3, IEEE 802.3u,

PCI 2.1, 2.2, PC 99

Protocol CSMA/CD

Ports Cards: 1 10/100 RJ-45 Port

Switch: 5 10/100 RJ-45 Ports,

1 Uplink Port (Shared)

Hub: 5 10/100 RJ-45 Ports,

1 Uplink Port (Shared, *extends 100

meters when all ports run 100Mbps)

WOL Support Cards: Remote Wake-Up

Power Management Event (PME)

Speed Per Port 10Mbps or 20Mbps (Half Duplex Hub)

100Mbps or 200Mbps (Full Duplex Switch)

LEDs Cards: Link/Activity, 100Mbps, Full Duplex

Switch: Power, Link/Activity, 100Mbps,

Full Duplex/Collision, Uplink

Hub: Power, 10/100 Collision, Uplink,

Link/Activity, 100 Mbps, SW

Environmental

Card Dimensions 5” x 2.3” x .75”

Card Weight 2.5 oz.

Switch Dimensions 7.5” x 5.4” x 2.0”

Switch Weight 1.3 lbs.

Hub Dimensions 7.5” x 5.4” x 1.4”

Hub Weight 0.9 lbs.

Power 3.3V, 3.0 A

Certifications FCC Class B, CE Mark Commercial,

UL and CSA Listed

Operating Temp. 32ºF to 122ºF (0ºC to 49ºC) for both kits

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC) for both kits

Operating Humidity 10% to 85% Non-Condensing for both kits

Storage Humidity 5% to 90% Non-Condensing for both kits

Package Contents

EtherFast Switched 10/100

Network in a Box

• Two EtherFast 10/100 PCI LAN

Cards (Wake-On-LAN Compatible)

• Two Wake-On-LAN jumper wires

• One 5-Port 10/100 Auto-Sensing Switch

• One AC Power Adapter (for Switch)

• Two 15-Foot Category 5 UTP Cables

• Two Driver Disks

• Internet Sharing Software

• One User Guide and Registration Card

(Model No.: FESWSK5)

Sales (800) 546-5797

Support (800) 326-7114

Fax (949) 261-8868

Email [email protected]

Web www.linksys.com

The EtherFast 10/100 LAN Card’s

Wake-on-Lan feature is optional. To

use the feature, the card must be

properly connected to a PCI moth-

erboard that supports WOL event

management. If your motherboard

does not support Wake-on-Lan, the

card will operate as a normal 10/100

LAN Card.

WOL

Wake-On-LAN Compatible

EtherFast 10/100

Network in a Box

• Two EtherFast 10/100 PCI LAN

Cards (Wake-On-LAN Compatible)

• Two Wake-On-LAN jumper wires

• One 5-Port 10/100 Auto-Sensing Hub

• One AC Power Adapter (for Hub)

• Two 15-Foot Category 5 UTP Cables

• Two Driver Disks

• Internet Sharing Software

• One User Guide and Registration Card

(Model No.: FENSK05)
