Linksys EG1032 Instructions d'utilisation d'origine

Model No.

Quick Installation

A Division of Cisco Systems, Inc.

Model No.

WIRED

Before installing the Adapter’s Driv-

ers, you must physically install the

Adapter.

APower off your PC and any

peripheral equipment

attached to it. Unplug your

PC’s power cord.

BOpen your PC’s case, and

locate an available PCI slot on

the motherboard. Check with

your computer manufacturer if

you need instructions.

CRemove the metal PCI slot

cover on the back of the PC.

DInsert the Adapter into the PCI

slot. Make sure that all the pins

are touching the slot’s con-

tacts. You may have to apply a

bit of pressure to slide the

Adapter all the way in.

EAfter the Adapter is set firmly in

place, secure its fastening tab

to your PC’s chassis with a

mounting screw. Then, close

your PC’s case.

FConnect one end of the Ether-

net network cable to the RJ-45

port of the Adapter. (Category

5e or better Ethernet network

cabling is required for Gigabit

transmission speeds.)

Installing the Adapter

GConnect the other end of the

Ethernet network cable to your

network’s Gigabit switch port.

Reconnect your PC’s power cord,

and then power on your computer.

Package Contents

• 10/100/1000 Gigabit Network

Adapter

•UserGuideCD-ROM

•QuickInstallation

• Registration Card

EG1032

Network Adapter

10/100/1000 Gigabit

EA screen may appear informing

you that the software has not

passed Windows Logo testing.

The software does work with

Windows XP. Click the Continue

Anyway button.

FWhen Windows XP has finished

installing the driver, the Com-

pleting the Found New Hard-

ware Wizard screen will

appear. Click the Finish button.

Driver installation is complete. If

you want to configure the

Adapter, refer to the chapter in

the User Guide for configura-

tion under Windows XP.

After physically installing the Adapter

in your computer, follow these

instructions to install the driver

required for Windows XP.

APower on your computer. Make

sure you have administrative

rights on your computer; other-

wise you cannot install the

driver.

BWindows XP will automatically

detect the presence of the

Adapter in your computer.

Insert the Driver CD into your

computer’s CD-ROM drive.

COn the Welcome screen of the

Found New Hardware Wizard,

select Install from a list or spe-

cific location (Advanced), and

click the Next button.

DAfter selecting Search for the

best driver in these locations

on the screen that appears,

choose Include this location in

the search:, and enter

D:\driver\WinXP in the field pro-

vided (if “D” is the letter of your

CD-Rom drive). Then, click the

Next button.

For additional information or troubleshooting

help, refer to the User Guide on the Setup CD-

ROM. You can also call or email for further

support.

24-hour Technical Support

800-326-7114

(toll-free from US or Canada)

E-mail Support

[email protected]

Website

http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization)

http://www.linksys.com/support

FTP Site

ftp://ftp.linksys.com

Sales Information

800-546-5797 (800-LINKSYS)

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

Model No.

EG1032_v3-QI-50406 KL

2Installing the Windows XP Driver
