Linksys SPA-941 Manuel utilisateur

IMPORTANT NOTICE CONCERNING EMERGENCY 911 SERVICES

Your service provider, not the manufacturer of the equipment,

is responsible for the provision of phone services through this

equipment. Any services provided through this equipment are

not intended to replace or be a substitute for primary line voice

services or Plain Old Telephone Service (“POTS”) and are not

meant to provide Automatic Number Identification or Automatic

Location Information capabilities associated with emergency

911 or E911 services. Check with your service provider to

determine whether emergency 911 or E911 services are offered

as part of your plan. Even where emergency 911 services are

offered as part of your plan, the service will not work properly if

you move the equipment to a different location from your

registered location. You should also be aware that phone

services (including 911) will not work in the event of either a

failure of your internet service or in the event of a power

outage. You must inform any other persons who may use this

equipment of the limitations of 911 and E911 emergency

services. It is strongly recommended that you always maintain

an alternate means of reaching a 911 operator in case of an

emergency. The manufacturer, distributor and service provider

shall not be liable for, and expressly disclaim, any direct or

indirect damages, claims, losses, expenses, liabilities, actions,

risks, or harms arising out of or related to the services provided

through this equipment, including without limitation,

emergency 911 or E911 services.

The use, disclosure, modification, transfer, or transmittal of this work for

any purpose, in any form, or by any means, without the written permission

of the copyright holder, is strictly forbidden.

Disclaimer

The content of this manual is subject to change without notice and should

not be construed as a commitment by the manufacturer, distributor, or

service provider. This manual is furnished for informational use only and

the manufacturer, distributor, or service provider assumes no

responsibility for any errors or inaccuracies that may appear herein.

My VoiceLine Account Information

Fill in the form(s) below to keep a record of your VoiceLine account

information.

VoiceLine Line 1 Information

VoiceLine Phone Number:

Account Number:

PIN:

VoiceMail Access Number:

Table of Contents

Introduction............................................................................................. 1

Package Contents .................................................................................. 1

Becoming Familiar with the Linksys SPA941 Connections............... 2

Linksys SPA941 Front Panel Features and Buttons........................................3

Linksys SPA941 LED Status Indicators...........................................................4

Installing the SPA941............................................................................. 4

Placing Calls ........................................................................................... 5

Understanding Local Dial Plans.......................................................................5

Making Calls....................................................................................................5

CALLING WITHIN YOUR AREA CODE (USING A U.S. DIAL PLAN).......................... 5

CALLING WITHIN NORTH AMERICA (USING A U.S. DIAL PLAN)............................. 5

CALLING INTERNATIONAL DESTINATIONS (USING A U.S. DIAL PLAN)................... 5

Using VoiceMail...................................................................................... 7

Recording a Personal Greeting .......................................................................7

Listening to VoiceMail Messages.....................................................................7

FROM YOUR VOICELINE-CONNECTED TELEPHONE ............................................ 7

FROM THE WEB ............................................................................................. 7

REMOTELY FROM ANY TOUCH-TONE PHONE .................................................... 8

Managing Your Account at the VoiceLine Account Center ............... 9

Customer Support.................................................................................. 9

Troubleshooting ................................................................................... 10

FAQs...................................................................................................... 11

VoiceLine Calling Features.................................................................. 13

Introduction

VoiceLine allows you to use your existing phone and broadband Internet

connection to receive calls and make local, long distance, and international calls

– all at incredibly low rates.

Instead of relying on the traditional telephone network, VoiceLine securely

transmits phone calls over the Internet, at rates much lower than traditional

phone companies can offer.

Just follow the simple installation instructions, and when you pick up the phone a

few minutes later, you will hear a dial tone! No need to dial an access number or

an account number.

This guide will walk you through the set-up process and explain everything you

need to know to begin using the VoiceLine service.

Package Contents

►1 Linksys SPA941 IP Phone

►1 Phone base station

►1 Phone hand set

►1 Hand set cable

►1 Desk stand

►1 5-Volt D/C power adapter

►1 Ethernet network cable (RJ-45)

Becoming Familiar with the Linksys SPA941

Connections

The underside of the phone contains the input/output ports. Use this diagram

as a reference when setting up your phone.

5V DC

WAN

Handset

Figure 1: Linksys SPA941 Connections

►5V DC (Power) – connects to a wall outlet with the supplied 5-Volt D/C

power adapter.

►WAN – connects to your broadband router with an Ethernet network cable

(RJ-45).

►Handset – connects the handset to the telephone’s base (RJ-7).

Linksys SPA941 Front Panel Features and Buttons

The following illustration and table describe the various features of the SPA941’s

front panel and LCD display.

Linksys SPA941 Front Panel Features

Navigation

Button Allows you to navigate through the features displayed on the

LCD screen

LCD Screen The phone’s display screen – It shows the date, time, phone

number, call duration, caller ID, line/call status, extension

numbers, and softkeys

Line LEDs Show phone number/extension and status

Softkey buttons Buttons that correspond to features displayed on the LCD

display

Softkey features Functions displayed on the LCD, which correspond to one of

the softkey buttons

Linksys SPA941 LED Status Indicators

Linksys SPA941 Statuses

Green Line is ready to be used.

Red Line is seized (in use).

Orange The phone has not successfully downloaded configuration

information or registered with the call servers.

If the phone’s LCD display indicates that there is a problem, please refer to

Troubleshooting in this guide.

Installing the SPA941

The following instructions will allow you to connect the Linksys SPA941 directly

to your broadband router. Refer to Figure 2 below for a diagram of this

configuration.

1. Using the standard Ethernet network cable (RJ-45) included with the

phone, connect the WAN port on the back of the phone to your router.

2. Using the standard telephone wire (RJ-11) included with the phone,

connect the handset to the telephone base.

3. Connect the D/C power adapter (included with the device) to the 5V DC

port on the back of the SPA941, and then plug in the power cord.

There will be a short wait for the device to initialize.

4. The SPA941 will obtain an IP address from the broadband router. The

phone display may read “Upgrading Firmware” as it downloads and

installs a firmware update. Do not reboot the device while this is

occurring. Once the device is ready for calls the display will show your

VoiceLine phone number and the Line LEDs will be green

5. Once the four line LEDs are green and the display shows your

VoiceLine phone number, lift the handset to ensure that you hear a dial

tone.

Figure 2: Linksys SPA941 Configuration
