Lindy CPU Switch Lite Manuel utilisateur



/,1'<

&386ZLWFK/,7(

(QJOLVK0DQXDO

The preferred solution to control multiple PCs

from one console.

Exclusively for PS/2 1:2 Version, Art.No. 32822

1:4 Version, Art.No. 32823

English Manual



Short Manual

•Switch off everything.

•Connect the CPU Switch LITE to the

computers, keyboard, monitor and

mouse using the appropriate cables.

•Switch on the monitor followed by the

computers.

•Additional information can be found in

the manual under the Installation and

Operation Sections of this manual.

English Manual



Overview

The LINDY CPU Switch LITE allows control of up to 4 PCs from one

keyboard, monitor and mouse. The keyboard and mouse connectors

on the PC both have to be PS/2 style. With this unit you can save the

cost of additional keyboards, monitors and mice. At the same time you

will save space and you will eliminate the problems of using the wrong

keyboard or mouse and all the trouble connected with this.

This unit is a pure hardware solution and therefore it is not dependant

on the operating system. This unit requires no software installation.

You only have to connect the cables and switch on the devices.

The CPU Switch LITE supports two ways of switching between the

connected computers: via keyboard hotkeys and by pressing the

switch on this device.

The CPU Switch LITE emulates the keyboard, monitor and mouse

connections for all connected PCs permanently. This prevents error

messages when switching between connected PCs.

FEATURES

•Supports monitor resolution up to 1600 x 1200

•Permanent Keyboard, Monitor and Mouse emulation

•Supports PCs with PS/2 type connectors

•Serial Mice and connectors are NOT supported

•Runs with all known operating systems

•Connection with standard LINDY cables for SVGA and PS/2

•No power supply required

English Manual



INSTALLATION

Before you start please switch off all devices to be attached.

Apart from the PCs to be connected you only need one keyboard,

monitor and PS/2 mouse and the standard connection cables (male to

male) to connect the keyboard, monitor and mouse ports of your PCs

to the LINDY CPU Switch LITE. If some cables are not long enough we

recommend that the complete cable is replaced with a longer length

rather than using extension cables. Extension cables introduce

additional plug to socket connections, which always lowers the signal

quality. When using high resolution or long distances this should be

noted.

Connect the keyboard, monitor and mouse directly to sockets of the

LINDY CPU Switch LITE named CONSOLE. If your keyboard has a 5

pin DIN connector you can use a PS/2 adaptor (LINDY Art.No. 70129).

Serial Mice with 9 Way D connectors are not supported and cannot be

used, even with an adapter.

Connect the PCs keyboard, monitor and mouse ports directly to the

appropriate sockets on the LINDY CPU Switch LITE named CPU A, B,

C or D. The mouse port on your PC has to be PS/2 type (6 pin Mini

DIN socket).

When you have made all connections switch on the monitor first and

then the PCs.

English Manual



OPERATION

Your monitor will only display one PC signal at any one time. All

keyboard and mouse commands are sent to this PC.

After initial power up, port A is active by default. When a PC is

connected to this port and it is not switched on or is in sleep mode, the

monitor will not show any signal. Please note that this is not the sign of

a faulty CPU Switch!

Operation via hotkey varies for the 2- and 4-port version.

Version 1:4 (Art. No. 32823):

To switch between the connected computers either press the

appropriate switch on the CPU Switch LITE or use a hotkey from your

keyboard. The following hotkeys are available: (Note: ALT + CTRL +

SHIFT keys have to be pressed simultaneously, then released before

the additional keys are pressed one after the other.)

Direct port selection: ALT + CTRL + SHIFT followed by 1or 2(or 3

or 4for the 1:4 version) and ENTER. The LINDY CPU Switch LITE will

then switch to the selected port.

Auto-Scan Mode: ALT + CTRL + SHIFT followed by 0and ENTER.

The LINDY CPU Switch LITE switches into the scan mode and scans

through each CPU signal in sequence. Pressing the SPACE will

terminate this mode. All other keyboard and mouse inputs will be

ignored.

Last/Next mode: ALT + CTRL + SHIFT followed by 9and ENTER.

The LINDY CPU Switch LITE switches into the Last/Next mode. By

pressing the left SHIFT key, the LINDY CPU Switch LITE switches to

the previous port. Pressing right SHIFT key switches to the next port.

Pressing the SPACE will terminate this mode. All other keyboard and

mouse inputs will be ignored.

Version 1:2 (Art. No. 32822):

Direct port selection: Instead of ALT + CTRL + SHIFT press CTRL

twice. This allows the switch to alternate the active channel.

English Manual



Auto-Scan-Mode: You may select this mode by pressing and

releasing in succession the LEFT SHIFT and RIGHT SHIFT key.When

in Auto-Scan-Mode, press LEFT SHIFT for PC 1 and RIGHT SHIFT for

PC 2. To exit from the Auto-Scan-Mode press the SPACEBAR .

LED DISPLAY MEANING

LED Status Meaning

ON This port is selected

OFF This port is not selected

Flashing equally Scan mode is active and this port is now

displayed

Flashing: ON long, OFF shortLast/Next mode is active and this port is

now displayed

TECHNICAL DATA

Power Consumption 5V DV, 20 mA max. via PS/2 connectors of the

attached computers

Operating Temperature around 5°C ... 40°C

Weight approximately 200g

TROUBLESHOOTING

If you are experiencing problems, first ensure that all cables are

properly connected.

After initial power up port A is active by default. When the PC is

connected to this port and it is not switched on or is in sleep mode the

monitor will not show any signal. Please note that this is not a sign of a

faulty CPU Switch!

Please also note that the LINDY CPU Switch LITE will not respond to

keyboard and mouse commands in Auto-Scan or Last/Next mode.

Pressing the spacebar can only terminate this mode. All other

keyboard and mouse inputs will be ignored.

If this does not solve your problems please follow the steps on the

following two pages.

English Manual



TROUBLESHOOTING

Symptom

No reaction

after pressing a

hotkey

command

Low quality

video image

Probable reason

The LINDY CPU Switch

LITE may be in Auto-

Scan or Last/Next mode.

The computer connected

to the selected port is

switched off or in sleep

mode

The hotkey entered was

wrong

Please check the proper

connection of the SVGA

cables.

Action to take

Press the SPACE and

quit this mode

Check the computer and

switch on or wake up

Please note: ALT +

CTRL + SHIFT keys

have to be pressed

simultaneously, then

released before

additional keys are

pressed one after the

other

Please note especially at

higher resolutions or

longer cable lengths you

have to use high quality

SVGA cables instead of

standard VGA cables.

SVGA cables can easily

be identified by the

larger diameter of the

cable. Please also avoid

using extension cables

and use long connection

cables. Every

English Manual



plug/socket

connection lowers the signal quality.

Symptom

The mouse is

not recognised

by Windows or

does not work

Probable reason

You can ONLY use a

mouse with a PS/2

connector and ONLY

PS/2 style mouse ports

on the computer are

supported. Serial to

PS/2 mouse adaptors

are NOT supported.

Incorrect installation of

cables

Incorrect or missing

mouse drivers

Action to take

You have to use a PS/2

style mouse and a PS/2

mouse port on your

computer.

Please check if all

cables are properly

connected.

When using a PS/2

mouse or pointing device

you must ensure that the

proper device driver has

been loaded into your

operating system.

Please check your

computer and make sure

that the driver is installed

correctly.

Note: the LINDY CPU Switch LITE supports many special pointing

devices such as wheel mice etc. These devices usually use their own

specific drivers individual bus protocols. For this reason it cannot be

guaranteed that any of these non standard protocols are supported.

Deutsche Anleitung



/,1'<

&386ZLWFK/,7(

'HXWVFKH$QOHLWXQJ

Die günstigste Lösung, um mehrere PCs

von einem Arbeitsplatz zu bedienen.

Ausschließlich PS/2 Version 1:2, Art. Nr. 32822 und

Deutsche Anleitung



Version 1:4, Art. Nr. 32823

KURZANLEITUNG

•Alle Geräte ausschalten.

•CPU-Switch LITE, Rechner, Monitor,

Maus und Tastatur mit geeigneten

Kabeln anschließen.

•Monitor und Rechner einschalten.

•Bedienung/Umschalten siehe unten.

•Weitere hilfreiche Informationen

entnehmen Sie bitte den einzelnen

Kapiteln.
