Lindy 42449 Manuel utilisateur
1
Q
uick Installation Guide
1Before You Begin…
System Requirement:
●10 Base-T Ethernet or 100 Base-TX Fast Ethernet
●CD-ROM drive
●CPU: Intel Pentium II 266MHz or above
●Memory: 32MB (64MB recommended)
●VGA resolution: 800x600 or above
Package Contents:
●One SOHO Wireless Internet Camera
●This
Quick Installation Guide
●One External Antenna
●One Installation CD-ROM
●One Camera Stand
●One DC Power Adapter
●One RJ-45 Ethernet Cable
Note: If any item contained is damaged or missing, please contact
your local dealer immediately.
2
Q
uick Installation Guide
2Hardware Installation
Attaching the Camera Stand
The Wireless Internet Camera comes with
a camera stand, which has a swivel ball
screw head that can be attached to the
camera’s screw hole on the top/bottom
panel. Attach the camera stand to the
camera and station it for your application.
Connecting the Power Supply
Connect the external power supply to the
DC power input connector located on the
camera’s rear panel, and then connect it
to your wall outlet. (
Tip: You can confirm
the power source is supplied from the
Power LED on the camera.
)
Installing the Antenna
Connect an Ethernet cable to the network
cable connector located on the camera’s
rear panel, and then connect it to the
network.
Connecting the Ethernet Cable
Connect an Ethernet cable to the network
cable connector located on the camera’s
rear panel, and then connect it to the
network.
3
Q
uick Installation Guide
3Running the Setup Wizard
The Setup Wizard is a convenient tool that will guide you through the
installation of your camera easily and quickly. After connecting the
camera to your computer, you can install the Setup Wizard and
complete the configuration now.
1. Insert the Installation
CD-ROM into your CD-ROM
drive.
Click Install Wizard.
2. Click Next.
3. Click Yes.
4
Q
uick Installation Guide
4. Click Next.
5. Click Finish.
To run the Setup Wizard,
click Start -> Programs
-> Setup Wizard.
5
Q
uick Installation Guide
4Using the Setup Wizard
When you launch the Setup Wizard, the main window will appear as
shown, and the connected camera will be displayed in the list.
The components on the Setup Wizard:
Click Wizard to begin configuring the selected
camera.
Click Search allows you to search the connected
camera again.
Click Link to launch the web browser and view the
images.
Click About to show the general information of the
selected camera.
Click Exit to close the Setup Wizard.
Control buttons
The connected camera list
6
Q
uick Installation Guide
Changing the Admin ID and Password
By default settings, the Admin ID and Password are blank. For
security purpose, you are recommended to change the Admin ID and
Password immediately.
Click Wizard. The dialog box as
shown appears, asking you to enter
the Admin ID and Password. Both
fields are “blank”.
Click
If required, select the Change
options and enter the new Admin ID
and Password.
Click
The settings of IP Address, Subnet
Mask and Default Gateway must
correspond with your camera and
networking settings. Please check
with your network administrator for
correct settings.
Click
The Connection Mode depends on
how your camera is connected to
your network. Click Infrastructure
for use with a router or Adhoc for
peer-to- peer. The Network
Name, Wireless Channel, and
Encryption Key MUST correspond
with your wireless network settings.
7
Q
uick Installation Guide
This window displays the settings you
set up. For any change, click to
modify your settings. Otherwise,
click to save and apply the
settings.
The configuration is completed, and
you will return to the main window.
Click Link to launch the web browser
and view the images.
8
Q
uick Installation Guide
5Tips
Software Information
Click About to show the
general information of the
selected camera.
Click V to return to the
main window.
Technical Support
For more information, please refer to the User’s Guide located on the
CD-ROM.
9
Q
uick Installation Guide
1Avant de Commencer…
Système Requis:
●10 Base-T Ethernet ou 100 Base-TX Fast Ethernet
●Lecteur CD-ROM
●CPU: Intel Pentium II 266MHz ou supérieur
●Mémoire: 32MB (64MB recommandé)
●Résolution VGA: 800x600 ou supérieur
Contenu de l'Emballage:
●Une Caméra Internet Sans Fil SOHO
●Ce
Guide Rapide d'Installation
●Une Antenne Externe
●Une Installation CD-ROM
●Un Support de Caméra
●Un Adaptateur d'Alimentation DC
●Un Câble Ethernet RJ-45
Note: Au cas où l'un des éléments précités serait manquant ou
endommagé, veuillez contacter votre revendeur immédiatement.
10
Q
uick Installation Guide
2Installation du Matériel
Fixer la Caméra au Support
La Caméra Internet MPEG-4 est fournie
avec un support, possédant une tête de
vis à bille orientable pouvant s'attacher au
trou prévu sur le haut/bas de la caméra.
Attacher le support à la caméra et
orienter selon votre utilisation.
Connecter l'Adaptateur
d'Alimentation
Connecter l'adaptateur d'alimentation
externe au connecteur d'alimentation DC
situé sur la face arrière de la caméra et
puis le connecter à la prise murale.
(
confirmer la bonne alimentation grâce au
voyant LED allumé sur la caméra.
)
Installer l'Antenne
Connecter une Antenne au connecteur
d'Antenne situé sur la face arrière de la
caméra et ensuite la connecter au réseau.
Connecter le câble Ethernet
Connecter un câble Ethernet au
connecteur de câble réseau situé sur la
face arrière de la caméra et puis la
connecter au réseau.
