LINDY Art. Nr. 70578

English Manual

Low Profile PCI Card 2S 16C650 1P EPP/ECP

Description

The 70578 32Bit PCI bus Plug & Play 2S/1P I/O card is equipped with two High-Speed RS-232.V24 Standard

Serial Interfaces and one ECP/EPP/SPP/BPP IEEE 1284 Centronics Parallel Interface. The serial ports include 32

Byte FIFO with a speed up to 921Kb/Sec. 70578 has two 9 pin male connectors for attaching peripherals´ units with

Serial RS-232 Standard Interface and one 25 pin female connector for peripherals' units with IEEE 1284 Centronics

Parallel Interface.

Hardware Specification

Serial Port:

UART Chipset: SUN1889, Hardware FIFO: 32Byte FIFO

Compatible chips: with 16C650, 16C550 and 16C450.

IEEE standard: RS-232 Interface

Driver Chipset: TI-75232, speed up to 100Kb/Sec, length 300-500m

Max. Speed: up to 921Kb/Sec (HYPER Terminal program)

Parallel Port:

Parallel Chipset: SUN1689, Hardware FIFO: 32Byte FIFO

Compatible chips: with ACC3203, ST-78C36 and HT6535.

IEEE standard: ECP/EPP/SPP/BPP (PS-II) Interface

Max. Speed: up to 2.7MB/Sec

Hardware Installation

Turn off the power of your computer

Plug the 70578 Serial Adapter to the PCI bus of your computer

Connect the peripheral (Printer, Modem, Scanner… etc. to this adapter

Turn on the power of your computer

PCI device listing display (for example…)

Bus No Device No Func. No Vendor ID Device ID Device Class IRQ

0 7 1 8086 7010 IDE Controller 14

0 13 0 1409 7168

Simple COMM.

Controller 10

LINDY Art. Nr. 70578

English Manual

When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error occurs, please change the PCI slot.

After correct hardware installation you can start installing the software from the driver CD.

Pin Assignments

Parallel 25Pin female connector pin assignments:

Parallel 25 Pin female connector:

Pin Signal Pin Signal Pin Signal

1 STROBE 10 ACKNOWLEDGE 19 GROUND

2 DATA 0 11 BUSY 20 GROUND

3 DATA 1 12 PAPER EMPTY 21 GROUND

4 DATA 2 13 SELECT 22 GROUND

5 DATA 3 14 AUTO FEED 23 GROUND

6 DATA 4 15 ERROR 24 GROUND

7 DATA 5 16 INIT 25 GROUND

8 DATA 6 17 SELECT INPUT 26 GROUND

9 DATA 7 18 GROUND

Serial 9 Pin male connector pin assignments:

Serial 9 Pin male connector (S1 and S2):

Pin Signal Pin Signal Pin Signal Pin Signal

1 CD 4 DTR 6 DSR 8 CTS

2 RD 5 GROUND 7 RTS 9 RI

3 TD

Technical Specification

Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/III/C5/K6

Operating system: WIN 9.x/ME/NT/2000, LINUX, DOS

Chips: 1 x SUN1889, 1 x SUN1689

Connections: 2 x DB 9 m connector serial, 1 x DB 25 f connector parallel

PCB: 2 Layer / 120 x 64 mm
