Operator’s Manual

FineLine 300HD Plasma System

www.lincolnelectric.com/register

Authorized Service and Distributor Locator:

www.lincolnelectric.com/locator

Save for future reference

Date Purchased:

Code: (ex: 10859)

Serial: (ex: U1060512345)

THE LINCOLN ELECTRIC COMPANY

BK8053-000107 Rev D | Issue Date: 11/2022 22801 St. Clair Avenue Cleveland, OH 44117-1199 U.S.A.

FineLine 300HD Plasma System BK8053-000107 Rev D

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 2 of 132

Revision History

Rev

Date

Description of Change

D 11/2022

Section 5.3 retract within 15mS. Section 4.4.5 TTS 9.5s. Added Section 6.5.1.

Section 2.1 updated pierce capacity to 2 in. (50mm). Added Section 4.2.4. Section

4.4 updated Settings screens. Section 7.2.2 added event codes. Section 3.5

remove inrush current.Added CutLinc trademark. Updated for CE code break

G9717-3/13525.

Trademark Notice

FineLine, CutLinc, Magnum, Burny, Inova, and the Lincoln Electric logo are registered trademarks

of Lincoln Global, Inc. All other trademarks are property of their respective owners.

THANK YOU FOR SELECTING

QUALITY EQUIPMENT BY

LINCOLN ELECTRIC.

Please examine carton and equipment for damage immediately

When this equipment is shipped, title passes to the purchaser upon receipt by the carrier.

Consequently, claims for material damaged in shipment must be made by the purchaser against

the transportation company at the time the shipment is received.

Customer Assistance Policy

The business of The Lincoln Electric Company is manufacturing and selling high quality welding

equipment, consumables, and cutting equipment. Our challenge is to meet the needs of our

customers and to exceed their expectations. On occasion, purchasers may ask Lincoln Electric for

advice or information about their use of our products. We respond to our customers based on the

best information in our possession at that time. Lincoln Electric is not in a position to warrant or

guarantee such advice, and assumes no liability, with respect to such information or advice. We

expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s

particular purpose, with respect to such information or advice. As a matter of practical

consideration, we also cannot assume any responsibility for updating or correcting any such

information or advice once it has been given, nor does the provision of information or advice

create, expand or alter any warranty with respect to the sale of our products.

Lincoln Electric is a responsive manufacturer, but the selection and use of specific products sold by

Lincoln Electric is solely within the control of, and remains the sole responsibility of the customer.

Many variables beyond the control of Lincoln Electric affect the results obtained in applying these

types of fabrication methods and service requirements.

Subject to Change – This information is accurate to the best of our knowledge at the time of

printing. Please refer to www.lincolnelectric.com for any updated information.

BK8053-000107 Rev D FineLine 300HD Plasma System

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 3 of 132

Table of Contents

1.0 Safety Warnings ......................................................................................5

1.1 General Precautions ............................................................................5

1.2 California Proposition 65 ......................................................................5

1.3 Ultraviolet Radiation Protection ............................................................5

1.4 Fire Prevention.....................................................................................5

1.5 Noise Protection...................................................................................6

1.6 Toxic Fume Prevention ........................................................................6

1.7 Health Support Equipment ...................................................................6

1.8 Electric Shock Prevention ....................................................................7

1.9 Explosion Prevention............................................................................8

1.10 Safety Standards Booklet Index .........................................................9

2.0 Specifications ........................................................................................11

2.1 System Description ............................................................................11

2.2 System Components ..........................................................................11

2.3 Compliance ........................................................................................ 13

2.4 FineLine 300HD Power Supply ..........................................................14

2.5 Cooling System and Torch Coolant....................................................15

2.6 Gas Supply.........................................................................................16

2.7 FineLine Gas Controller (GC)............................................................. 17

2.8 FineLine Arc Start Console (ASC)......................................................18

2.9 Magnum PRO LC300M Plasma Torch & Accessories ....................... 19

2.10 FineLine User Interface & CutLinc Server........................................20

2.11 Ethernet Router/Switch ....................................................................20

2.12 Airborne Noise Emissions ................................................................21

2.13 Electromagnetic Compatibility (EMC)...............................................21

2.14 ECO Design Information .................................................................. 22

3.0 Installation..............................................................................................25

3.1 Component Placement.......................................................................25

3.2 Bend Radius for Cables, Hoses and Torch Leads .............................30

3.3 Connection Diagram...........................................................................31

3.4 Radio Frequency (RF) and Electromagnetic Interference (EMI) ........33

3.5 Power Supply Input Connections - Primary Power.............................35

3.6 Power Supply Input Connections - Gas Supply..................................38

3.7 Power Supply Output Connections ....................................................39

3.8 Arc Start Console Output Connections...............................................42

3.9 Gas Controller Input Connections ......................................................44

3.10 Gas Controller Output Connections .................................................46

3.11 Torch Connections ...........................................................................47

3.12 Mount the Torch ...............................................................................48

3.13 Install Consumables......................................................................... 49

3.14 Ethernet Connections....................................................................... 50

3.15 Emergency Stop (EStop) Circuit ......................................................51

3.16 CNC Interface ..................................................................................52

3.17 Software Installation ......................................................................... 54

3.18 Commission the System................................................................... 56

FineLine 300HD Plasma System BK8053-000107 Rev D

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 4 of 132

3.19 Fill the Cooling System.....................................................................58

3.20 Installation Checklist......................................................................... 59

4.0 Operation................................................................................................61

4.1 Status Lights and Buttons ..................................................................61

4.2 Operational Sequence........................................................................63

4.3 FineLine User Interface – Operation .................................................. 67

4.4 FineLine User Interface – Settings & Diagnostics ..............................76

5.0 LC300M Plasma Torch & Consumables ..............................................81

5.1 Installing / Removing the Quick-Disconnect Torch Head ...................81

5.2 Replacing Consumables ....................................................................83

5.3 Maximizing Consumable Life .............................................................85

5.4 Cut Quality .........................................................................................86

5.5 Piercing Thick Materials .....................................................................87

5.6 Edge Starts ........................................................................................87

5.7 Cut Charts ..........................................................................................87

6.0 Maintenance...........................................................................................89

6.1 Routine Maintenance .........................................................................90

6.2 Coolant Filter Replacement (without Coolant Flush) ..........................92

6.3 Coolant Flush and Filter Replacement ............................................... 93

6.4 Consumable Inspection...................................................................... 95

6.5 Software/Firmware Updates............................................................... 96

7.0 Troubleshooting .................................................................................... 99

7.1 Error Identification ..............................................................................99

7.2 Error Codes and Event Log..............................................................101

7.3 Replacing System Components .......................................................109

8.0 Parts List ..............................................................................................111

8.1 Torch and Related Parts ..................................................................111

8.2 Hoses, Leads, and Cables ...............................................................112

8.3 Supply Gas Hose Fittings Kit, BK300421 (Optional) ........................ 114

9.0 Wiring & Flow Diagrams .....................................................................115

9.1 Power Supply K4900-1 Wiring Diagram (click to open PDF)............115

9.2 Power Supply K4900-2 Wiring Diagram (click to open PDF)............116

9.3 Cooling System (Inside Power Supply) Flow Diagram ..................... 118

9.4 Gas Controller (GC) Wiring Diagram................................................ 119

9.5 Gas Controller (GC) Flow Diagram ..................................................120

9.6 Arc Start Console (ASC) Wiring Diagram.........................................121

Appendix A Electromagnetic Compatibility (EMC) ................................. 123

Appendix B Inova System Integration .....................................................127

Appendix C PS Interconnect Cable Extender .........................................131

BK8053-000107 Rev D FineLine 300HD Plasma System

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 5 of 132

1.0 Safety Warnings

WARNING

1.1 General Precautions

Whereas plasma cutting has been used

safely for years, it does require certain

precautions to ensure the safety of the

operator and other people around the

equipment. The following safety information

must be provided to each person who will

operate, observe, perform maintenance, or

work in close proximity to this piece of

equipment. Always wear appropriate

personal protective equipment (PPE).

Installation, operation, and repairs made to

this System should only be performed by

qualified personnel. The System makes use

of both A.C. and D.C. circuitry for operation.

Fatal shock hazard does exist. Exercise

extreme caution while working on the

System.

1.2 California Proposition 65

This product, when used for welding or

cutting, produces fumes or gases which

contain chemicals known to the State of

California to cause birth defects and, in

some cases, cancer. (California Health &

Safety Code § 25249.5 et seq.)

WARNING: Cancer and Reproductive Harm

www.p65warnings.ca.gov

1.3 Ultraviolet Radiation

Protection

Plasma cutting produces

ultraviolet radiation similar to

a welding arc. This ultraviolet

radiation can cause skin and

eye burns. For this reason, it

is essential that proper protection be worn.

The eyes are best protected by using safety

glasses or a welding helmet with an AWS

No. 12 shade or ISO 4850 No. 13 shade,

which provides protection up to 400

amperes. All exposed skin areas should be

covered with flame-retardant clothing. The

cutting area should also be prepared in

such a way that ultraviolet light does not

reflect. Walls and other surfaces should be

painted with dark colors to reduce reflected

light. Protective screens or curtains should

be installed to protect additional workers in

the area from ultraviolet radiation.

1.4 Fire Prevention

When using this System, it is

necessary to exercise good

judgment. While cutting, the

arc produces sparks that

could cause a fire if they fall

on flammable materials. Make sure that all

flammable materials are a suitable distance

away from the cutting area. All flammable

liquids should be at least 40 feet away from

the cutting area, preferably stored in a

metal cabinet. Plasma cutting should never

be attempted on containers that contain

flammable materials. Make sure that fire

extinguishers are readily accessible in the

cutting area.

Make sure that the cutting area is properly

ventilated when using oxygen as a cutting

gas.

FineLine 300HD Plasma System BK8053-000107 Rev D

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 6 of 132

WARNING

1.5 Noise Protection

The System generates high

noise levels while cutting.

Depending on the size of the

cutting area, distance from the

cutting torch, and arc current

cutting level, acceptable noise levels may

be exceeded. Proper ear protection should

be used as defined by local or national

codes. Refer to Section 2.12 for noise

emission levels.

1.6 Toxic Fume Prevention

Care should be taken to

ensure adequate ventilation

in the cutting area. Some

materials give off toxic

fumes that can be harmful

or fatal to people in the vicinity of the cutting

area. Also, some solvents decompose and

form harmful gases when exposed to

ultraviolet radiation. These solvents should

be removed from the area prior to cutting.

Galvanized metal can produce harmful

gases during the cutting process. Ensure

proper ventilation and use breathing

equipment when cutting these materials.

Certain metals coated with or containing

lead, cadmium, zinc, beryllium, and

mercury produce harmful toxins. Do not cut

these metals unless all people subjected to

the fumes wear proper air breathing

equipment.

1.7 Health Support Equipment

The System creates electric

and magnetic fields that

may interfere with certain

types of health support

equipment, such as

pacemakers. Any person

who uses a pacemaker or similar item

should consult a doctor before operating,

observing, maintaining, or servicing the

System. Observe the following guidelines to

minimize exposure to these electric and

magnetic fields:

•Stay as far away from the Power Supply,

torch, torch leads, and arc start console

as possible.

•Route the torch leads as close as possible

to the work ground cable.

•Never place your body between the torch

leads and work ground cable. Keep the

work ground cable and the torch leads on

the same side of your body.

•Never stand in the center of a coiled up

set of torch leads or work ground cable.

BK8053-000107 Rev D FineLine 300HD Plasma System

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 7 of 132

WARNING

1.8 Electric Shock Prevention

The System uses high open

circuit voltages that can be

fatal. Extreme care should be

used when operating or

performing maintenance on the

System. Only qualified personnel should

service the System. Observe the following

guidelines to protect against electric shock:

•A wall-mounted disconnect switch should

be installed and fused according to local

and national electrical codes. The

disconnect switch should be located as

close as possible to the Power Supply so

it can be turned off in case of an

emergency.

•The primary power cord should have a

600 volt minimum rating in order to protect

the operator. In addition, it should be

sized according to local and national

electrical codes. Inspect the primary

power cord frequently. Never operate the

System if the power cord is damaged in

any way.

•Make sure the primary power ground wire

is connected to the input power ground

stud on the Power Supply. Make sure the

connection is securely tightened.

•Make sure the positive output (work

ground) of the Power Supply is connected

to a bare metal area on the cutting table.

A driven ground rod should be placed no

further than five feet from this connection.

Make sure this ground point on the cutting

table is used as the star ground point for

all other ground connections.

•Inspect the torch leads frequently. Never

use the System if the leads are damaged

in any way.

•Do not stand in wet, damp areas when

operating or performing maintenance on

the System.

•Wear insulated gloves and shoes while

operating or performing maintenance on

the System.

•Make sure the System is switched off at

the wall disconnect before servicing the

Power Supply or torch.

•Never change torch consumable parts

unless the System is switched off at the

wall disconnect.

•Do not attempt to remove any parts from

beneath the torch when cutting.

Remember that the workpiece forms the

current path back to the Power Supply.

•Never bypass the safety interlock devices.

•Before removing any of the covers, switch

the System off at the wall disconnect.

Wait at least five (5) minutes before

removing any cover. This will give the

capacitors inside the unit time to

discharge.

•Never operate the System without all of

the covers in place.

•Preventive maintenance should be

performed daily to avoid possible safety

hazards.

FineLine 300HD Plasma System BK8053-000107 Rev D

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 8 of 132

WARNING

1.9 Explosion Prevention

The System uses compressed

gases. Use proper techniques

when handling compressed

gas cylinders and other

compressed gas equipment. Observe the

following guidelines to protect against

explosion:

•Never operate the System in the presence

of explosive gases or other explosive

materials.

•Never cut pressurized cylinders or any

closed container.

•When using a water table and cutting

aluminum under water or with water

touching the underside of the aluminum

plate, hydrogen gas is produced. This

hydrogen gas may collect under the plate

and explode during the cutting process.

Make sure the water table is properly

aerated to help prevent the accumulation

of hydrogen gas.

•Handle all gas cylinders in accordance

with safety standards published by the

U.S. Compressed Gas Association

(CGA), American Welding Society (AWS),

Canadian Standards Association (CSA),

or other local or national codes.

•Compressed gas cylinders should be

maintained properly. Never attempt to use

a cylinder that is leaking, cracked, or has

other signs of physical damage.

•All gas cylinders should be secured to a

wall or rack to prevent accidental knock

over.

•If a compressed gas cylinder is not being

used, replace the protective valve cover.

•Never attempt to repair compressed gas

cylinders.

•Keep compressed gas cylinders away

from intense heat, sparks, or flames.

•Clear the compressed gas cylinder

connection point by opening the valve

momentarily prior to installing a regulator.

•Never lubricate compressed gas cylinder

valves or pressure regulators with any

type of oil or grease.

•Never use a compressed gas cylinder or

pressure regulator for any purpose other

than which it is intended.

•Never use a pressure regulator for any

gas other than which it is intended.

•Never use a pressure regulator that is

leaking or has other signs of physical

damage.

•Never use oxygen hoses and pressure

regulators for any gas other than oxygen.

•Never use any gas hose that is leaking or

has other signs of physical damage.

Refer to

www.lincolnelectric.com/safety

for additional safety information.

BK8053-000107 Rev D FineLine 300HD Plasma System

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 9 of 132

1.10 Safety Standards Booklet Index

For further information concerning safety practices to be exercised with plasma arc

cutting equipment, please refer to the following publications:

•AWS Standard AWN, Arc Welding and Cutting Noise, obtainable from the

American Welding Society, 550 NW LeJeune Road, Miami, FL 33126.

•AWS Standard C5.2, Recommended Practices for Plasma Arc Cutting, obtainable

from the American Welding Society, 550 NW LeJeune Road, Miami, FL 33126.

•AWS Standard FSW, Fire Safety in Welding and Cutting, obtainable from the

American Welding Society, 550 NW LeJeune Road, Miami, FL 33126.

•AWS Standard F4.1, Recommended Safe Practices for Preparation for Welding

and Cutting of Containers and Piping, obtainable from the American Welding

Society, 550 NW LeJeune Road, Miami, FL 33126.

•AWS Standard ULR, Ultraviolet Reflectance of Paint, obtainable from the

American Welding Society, 550 NW LeJeune Road, Miami, FL 33126.

•AWS / ANSI Standard Z49.1, Safety in Welding, Cutting, and Allied Processes,

obtainable from the American Welding Society, 550 NW LeJeune Road, Miami, FL

33126.

•ANSI Standard Z41.1, Standard For Men’s Safety-Toe Footwear, obtainable from

the American National Standards Institute, 11 West 42nd Street, New York, NY

10036.

•ANSI Standard Z49.2, Fire Prevention in the Use of Cutting and Welding

Processes, obtainable from the American National Standards Institute, 11 West

42nd Street, New York, NY 10036.

•ANSI Standard Z87.1, Safe Practices For Occupation and Educational Eye and

Face Protection, obtainable from the American National Standards Institute, 11

West 42nd Street, New York, NY 10036.

•ANSI Standard Z88.2, Respiratory Protection, obtainable from the American

National Standards Institute, 11 West 42nd Street, New York, NY 10036.

•OSHA Standard 29CFR 1910.252, Safety and Health Standards, obtainable from

the U.S. Government Printing Office, Washington, D.C. 20402.

•NFPA Standard 51, Oxygen - Fuel Gas Systems for Welding, Cutting, and Allied

Processes, obtainable from the National Fire Protection Association, 1

Batterymarch Park, Quincy, MA 02269.

•NFPA Standard 51B, Cutting and Welding Processes, obtainable from the National

Fire Protection Association, 1 Batterymarch Park, Quincy, MA 02269.

•NFPA Standard 70, National Electrical Code, obtainable from the National Fire

Protection Association, 1 Batterymarch Park, Quincy, MA 02269.

•CGA booklet P-1, Safe Handling of Compressed Gases in Containers, obtainable

from the Compressed Gas Association, 1725 Jefferson Davis Highway, Suite

1004, Arlington, VA 22202.

FineLine 300HD Plasma System BK8053-000107 Rev D

This information is subject to the controls of the Export Administration Regulations [EAR]. This information shall not be provided to

non-U.S. persons or transferred by any means to any location outside the United States contrary to the requirements of the EAR.

Page 10 of 132

•CGA booklet P-14, Accident Prevention in Oxygen-Rich and Oxygen-Deficient

Atmospheres, obtainable from the Compressed Gas Association, 1725 Jefferson

Davis Highway, Suite 1004, Arlington, VA 22202.

•CGA booklet TB-3, Hose Line Flashback Arrestors, obtainable from the

Compressed Gas Association, 1725 Jefferson Davis Highway, Suite 1004,

Arlington, VA 22202.

•CSA Standard W117.2, Safety in Welding, Cutting, and Allied Processes,

obtainable from Canadian Standards Association, 178 Rexdale Boulevard,

Toronto, Ontario M9W lR3, Canada.

•Canadian Electrical Code Part 1, Safety Standard for Electrical Installations,

obtainable from the Canadian Standards Association, 178 Rexdale Boulevard,

Toronto, Ontario M9W 1R3, Canada.

Table des matières

Autres manuels Lincoln Electric Système de soudage

Lincoln Electric

Lincoln Electric PRO 100 Manuel utilisateur

Lincoln Electric

Lincoln Electric Power MIG 350MP Manuel utilisateur

Lincoln Electric

Lincoln Electric 2100 Manuel utilisateur

Lincoln Electric

Lincoln Electric 11457 Manuel utilisateur

Lincoln Electric

Lincoln Electric SF7000 Manuel utilisateur

Lincoln Electric

Lincoln Electric IDEALARC SVM136-A Manuel utilisateur

Lincoln Electric

Lincoln Electric SQUARE WAVE IM467-B Manuel utilisateur

Lincoln Electric

Lincoln Electric IDEALARC CV-300 Manuel utilisateur

Lincoln Electric

Lincoln Electric RANGER 305D IM730 Manuel utilisateur

Lincoln Electric

Lincoln Electric PF26 Manuel utilisateur

Lincoln Electric

Lincoln Electric VANTAGE 520 SD Manuel utilisateur

Lincoln Electric

Lincoln Electric POWER WAVE 455 Manuel utilisateur

Lincoln Electric

Lincoln Electric Stick Electrode Welding C2.410 Manuel utilisateur

Lincoln Electric

Lincoln Electric Flextec 350XP Manuel utilisateur

Lincoln Electric

Lincoln Electric Vantage 549 Manuel utilisateur

Lincoln Electric

Lincoln Electric IDEALARC CV-250 Manuel utilisateur

Lincoln Electric

Lincoln Electric Pro-MIG 140 Manuel utilisateur

Lincoln Electric

Lincoln Electric IM-99-A Manuel utilisateur

Lincoln Electric

Lincoln Electric 180i MP Manuel utilisateur

Lincoln Electric

Lincoln Electric POWER MIG 216 Manuel utilisateur

Lincoln Electric

Lincoln Electric MARQUETTE AutoPro 155S Manuel utilisateur

Lincoln Electric

Lincoln Electric PLASMA 20 Manuel utilisateur

Lincoln Electric

Lincoln Electric AUTODRIVE 4R220 Manuel utilisateur

Lincoln Electric

Lincoln Electric MAGNUM PRO 350 Manuel utilisateur

Manuels Système de soudage populaires d'autres marques

Berner

Berner PLASMACUT 54 Manuel utilisateur

Pro Spot

Pro Spot PR-155 Manuel utilisateur

Forney

Forney 210 Manuel utilisateur

Thermal Arc

Thermal Arc 400S Manuel utilisateur

GYS

GYS PROTIG 201 AC/DC Manuel utilisateur

TAFA

TAFA 30*8B35 Manuel utilisateur

ESAB

ESAB Buddy Arc 145 Manuel utilisateur

CIGWELD

CIGWELD 636804 Guide rapide

Red-D-Arc

Red-D-Arc DC-400 Manuel utilisateur

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manuel utilisateur

Elettro

Elettro HI-MIG 3000 SYNERGIC Manuel utilisateur

WIA

WIA Weldmatic 270 CP132-2 Manuel utilisateur

Sonics

Sonics H520T Manuel utilisateur

Miller

Miller Big Blue 400D Manuel utilisateur

NewArc

NewArc RT2000 Guide de démarrage rapide

Hypertherm

Hypertherm powermax1000 Manuel utilisateur

Everlast

Everlast POWER MTS 221STi Manuel utilisateur

Kipor

Kipor KDE180XW Manuel utilisateur
